Old 03-22-2009, 06:07 PM   #1
superspeeder
Junior Member

superspeeder's Avatar

Member Since: Mar 2009
Default TPI firing order

Is this firing order same on 88 TPI?
Click the image to open in full size.
I removed the distributor, distributor cap, spark plug wires and now I but them back together according to this picture and when I crank it nothing happens.
Distributor rotor can be assembled only two ways because there is a pin inside the bottom drive gear? If the firing order is same on 88 TPI can it just be timing? Can a slightest turn of the distributor mess up ignition?
Please help!
superspeeder is offline   Reply With Quote
Old 03-22-2009, 06:18 PM   #2
CAJUN C4
CF Senior Member

CAJUN C4's Avatar

Member Since: Feb 2000
Location: MANDEVILLE, LA La
Default

Yes it is.
CAJUN C4 is offline   Reply With Quote
Old 03-22-2009, 06:25 PM   #3
superspeeder
Junior Member

superspeeder's Avatar

Member Since: Mar 2009
Default

Quote:
Originally Posted by CAJUN C4 View Post
Yes it is.
Is it possible to mess up the ignition timing that the car even don't start anymore whit slightest turn on the distributor cap?
superspeeder is offline   Reply With Quote
Old 03-22-2009, 06:29 PM   #4
CorvetteMike2004
CF Senior Member
Support Corvetteforum!

CorvetteMike2004's Avatar

Member Since: Oct 2007
Default dist.

Are you sure its not 180 degrees off?
CorvetteMike2004 is offline   Reply With Quote
Old 03-22-2009, 06:34 PM   #5
floridamale
CF Senior Member

floridamale's Avatar

Member Since: Jan 2008
Location: Vero Beach Florida
Default

Find TDC #1 compression stroke position the rotor pointing at #1 cylinder or one tooth on the dizzy before . Should get you close enough to fire it up. You can also check your timing mark on the harmonic balancer should line up around zero on the tab. If you have pulled the dizzy you need to be sure that the rod it fits into look in the hole lines up with the bottom of dizzy, that drives the dizzy.
floridamale is offline   Reply With Quote
Old 03-22-2009, 08:24 PM   #6
coupeguy2001
CF Senior Member

coupeguy2001's Avatar

Member Since: Sep 2006
Location: Phoenix AZ
Send a message via AIM to coupeguy2001
Default timing

The rod on the bottom of the dist. turns the oil pump. if you have any oil pressure at all while cranking and the dist. is sitting on the manifold, your problem is base timing.
1. the #1 cyl. rockers have to be loose, engine on #1 tdc
2. the rotor in the dist. points to #1
3. the timing mark on the harmonic dampener is at the pointer.
4. THE DISTRIBUTOR IS PLUGGED IN......HELLO!

If any of the above is off, your timing chain could have jumped a tooth.
coupeguy2001 is offline   Reply With Quote
Old 03-22-2009, 08:36 PM   #7
c4cruiser
CF Senior Member
NCM Sinkhole Donor
Support Corvetteforum!

c4cruiser's Avatar

Member Since: Dec 1999
Location: Lacey, Washington RVN '68-'69
Default

Quote:
Originally Posted by superspeeder View Post
Is this firing order same on 88 TPI?
Click the image to open in full size.
I removed the distributor, distributor cap, spark plug wires and now I but them back together according to this picture and when I crank it nothing happens.
Distributor rotor can be assembled only two ways because there is a pin inside the bottom drive gear? If the firing order is same on 88 TPI can it just be timing? Can a slightest turn of the distributor mess up ignition?
Please help!
When you install the distributor with the rotor in place, the contact on the rotor should point towards the #1 wire as shown on the diagram. It's real easy to be a tooth or two off on the gear and that can throw timing way off and result in a no start.

As mentioned, bring #1 piston to TDC and pull the distributor. To find TDC, remove the #1 plug and cover the hole with your thumb. Spin the engine until you feel compression and you see the timing mark on the crank damper align with the 0 degree mark on the metal tab. You will probably need to clean the tab and use some paint or chalk to mark the line on the damper.

When you feel that, drop the distributor in so the contact on the rotor points to the #1 teminal on the cap and bolt the distributor down. Install the cap, #1 plug and the wire. Disconnect the tan/black wire leading to the distributor and start the engine. Set the timing with a timing light to 6 degrees BTDC or whatever timing value it says on the Emission Control Information Label. Then reconnect the tan/black wire.
c4cruiser is offline   Reply With Quote
Old 03-22-2009, 10:33 PM   #8
floridamale
CF Senior Member

floridamale's Avatar

Member Since: Jan 2008
Location: Vero Beach Florida
Default

When I replaced the gear bottom of dizzy I noticed the harmoinc blancer had slipped, so you have to do both look at tab & TDC #1. Easy way to fine TDC is if you have a compression gague. TDC compression is absoult though no matter what is showing on timing tab.
floridamale is offline   Reply With Quote
Old 03-22-2009, 10:55 PM   #9
c4cruiser
CF Senior Member
NCM Sinkhole Donor
Support Corvetteforum!

c4cruiser's Avatar

Member Since: Dec 1999
Location: Lacey, Washington RVN '68-'69
Default

If the outer ring of the balancer slips, it will be difficult to set timing with a timing light. Electronic timing control won't allow for too much of a variance beyond the initial setting of 6 degrees.

Even if you do get TDC from compression or watching the rocker arms on #1 cylinder, the timing mark on the balancer ring is still going to have to at the mark on the tab to get it right.
c4cruiser is offline   Reply With Quote
Old 03-22-2009, 11:15 PM   #10
Iroc57
CF Senior Member

Iroc57's Avatar

Member Since: May 2007
Location: Warwick RI
Default

Quote:
Originally Posted by superspeeder View Post
Is this firing order same on 88 TPI?
Click the image to open in full size.
I removed the distributor, distributor cap, spark plug wires and now I but them back together according to this picture and when I crank it nothing happens.
Distributor rotor can be assembled only two ways because there is a pin inside the bottom drive gear? If the firing order is same on 88 TPI can it just be timing? Can a slightest turn of the distributor mess up ignition?
Please help!
Once again this f%&ing diagram shows up and screws up someones timing. Ignore the "#1" on the distributor in the diagram. Drop your dist in with the pump drive engaged( the base will sit all the way down). You may have to lift and rotate the rotor to do this. Then bring #1 cyl on compression by feeling with your finger and line up the timing mark with 0. Wherever the rotor is pointing is now #1 so put the wires on clockwise from there 18436572 and fire it up.

Then time it with a light(est wire disconnected) to 6BTDC.

Oh yeah....burn that diagram when you are done
Iroc57 is offline   Reply With Quote
Old 03-23-2009, 04:28 PM   #11
superspeeder
Junior Member

superspeeder's Avatar

Member Since: Mar 2009
Default

I managed to fire it up today. Idle was a bit rough, but I think I should wait until engine warms up and then set timing with timing light. I will do that day after tomorrow because my car is jacked up right now for lowering...
Anyway, thanks guys!!!
superspeeder is offline   Reply With Quote
Old 03-23-2009, 04:54 PM   #12
Kubs
CF Senior Member
St. Jude Donor '09-'10-'11
Support Corvetteforum!

Kubs's Avatar

Member Since: Oct 2007
Location: Akron Ohio
kubs363 Kubs63
Default

Quote:
Originally Posted by superspeeder View Post
Click the image to open in full size.
This is how my dad taught me to count! 18436572
Kubs is offline   Reply With Quote
Old 03-23-2009, 05:15 PM   #13
Yorcci
CF Senior Member

Yorcci's Avatar

Member Since: Oct 2008
Location: Jyväskylä
Default

Quote:
Originally Posted by superspeeder View Post
Is this firing order same on 88 TPI?
If you happen to forget that firing order, it's written on the stock intake manifold, between the egr valve and fuel pressure regulator

See the picture:

Click the image to open in full size.
Yorcci is offline   Reply With Quote
Old 03-23-2009, 09:05 PM   #14
Iroc57
CF Senior Member

Iroc57's Avatar

Member Since: May 2007
Location: Warwick RI
Default

Quote:
Originally Posted by superspeeder View Post
I managed to fire it up today. Idle was a bit rough, but I think I should wait until engine warms up and then set timing with timing light. I will do that day after tomorrow because my car is jacked up right now for lowering...
Anyway, thanks guys!!!
You can tweak the dist to get it smoother before you put the light on it. Don't sweat the temp for base timing...it won't change anything
Iroc57 is offline   Reply With Quote
Old 03-23-2009, 09:07 PM   #15
Iroc57
CF Senior Member

Iroc57's Avatar

Member Since: May 2007
Location: Warwick RI
Default

Quote:
Originally Posted by Kubs View Post
This is how my dad taught me to count! 18436572
I actually remembered it when I did the 5.7 in my son's IROC after 15 years without turning a wrench...some things stick
Iroc57 is offline   Reply With Quote
