ECS blower build
#241
Race Director
Member Since: Dec 2010
Location: Atlanta, GA
Posts: 10,426
Received 1,261 Likes
on
1,056 Posts
2020 Corvette of the Year Finalist (performance mods)
C5 of Year Winner (performance mods) 2019
did you have the intake off at anytime between the blower install and now?... I pinched the wire to my opsu like a doofus when I put my intake back on one time... freaked me the heck out but I knew it was something I did
#242
Drifting
Thread Starter
I changed the filter: Didn't fix it
I changed the OPS: Didn't fix it
I'm about to test the OPS connector to make sure its not shorted. I hate to say it but if that is fine, I'm looking at oil pump relief valve failure?????
**** me
#243
Drifting
Thread Starter
Tested the wires leading to the OPS.
Key On - Grey wire has 5 volts - this is good
Key On - Tan wire has 0 volts - this is good
Ground is good
Tested OPS with compressed air and key on - Gauge moved
Looks like my pump is the cause...tear down begins tomorrow
Which pump:
MELLING HIGH VOLUME, HIGH PRESSURE OIL PUMP 10296 ($149)
MELLING STANDARD VOLUME, HIGH PRESSURE OIL PUMP 10295 ($115)
Key On - Grey wire has 5 volts - this is good
Key On - Tan wire has 0 volts - this is good
Ground is good
Tested OPS with compressed air and key on - Gauge moved
Looks like my pump is the cause...tear down begins tomorrow
Which pump:
MELLING HIGH VOLUME, HIGH PRESSURE OIL PUMP 10296 ($149)
MELLING STANDARD VOLUME, HIGH PRESSURE OIL PUMP 10295 ($115)
Last edited by nullpointer; 04-18-2015 at 03:30 PM.
#244
Race Director
Member Since: May 2004
Location: Raleigh, NC
Posts: 16,664
Received 1,194 Likes
on
1,053 Posts
St. Jude Donor '15
Tested the wires leading to the OPS.
Key On - Grey wire has 5 volts - this is good
Key On - Tan wire has 0 volts - this is good
Ground is good
Tested OPS with compressed air and key on - Gauge moved
Looks like my pump is the cause...tear down begins tomorrow
Which pump:
MELLING HIGH VOLUME, HIGH PRESSURE OIL PUMP 10296 ($149)
MELLING STANDARD VOLUME, HIGH PRESSURE OIL PUMP 10295 ($115)
Key On - Grey wire has 5 volts - this is good
Key On - Tan wire has 0 volts - this is good
Ground is good
Tested OPS with compressed air and key on - Gauge moved
Looks like my pump is the cause...tear down begins tomorrow
Which pump:
MELLING HIGH VOLUME, HIGH PRESSURE OIL PUMP 10296 ($149)
MELLING STANDARD VOLUME, HIGH PRESSURE OIL PUMP 10295 ($115)
Most things I've read say the high volume pump is too much with a stock pan and can suck it dry.. so personally I'd do standard volume/high pressure. But someone else probably knows better than me!
#245
Drifting
Thread Starter
Yea, I'm not the happiest camper. I got to hear/drive it for 30 minutes, so that's good motivation. I think I will go with the standard volume, high pressure because its cheaper and I have also heard that. My jack died too, so I need a new one of those. Can't drive the car onto blocks to get it on the lift, so I have to get creative.
I just keep telling myself, one more week, then we dyno and it's done
I just keep telling myself, one more week, then we dyno and it's done
#246
Drifting
Thread Starter
#247
Race Director
Member Since: May 2004
Location: Raleigh, NC
Posts: 16,664
Received 1,194 Likes
on
1,053 Posts
St. Jude Donor '15
Oil is either not getting to the pump, being blocked somewhere before making it to the sensor, or not being pumped at all for whatever reason.. as best I can tell anyways
#248
Race Director
Member Since: Dec 2010
Location: Atlanta, GA
Posts: 10,426
Received 1,261 Likes
on
1,056 Posts
2020 Corvette of the Year Finalist (performance mods)
C5 of Year Winner (performance mods) 2019
I have the 10295 and have been happy with it so far
#250
Drifting
Thread Starter
Tore the car down today, not too bad this time around. Took ~6 hours working slow and not making a mess. Also manged to keep the driver side header in place, move it and the starter to get the flywheel lock in place. Saves some time and a ton of swearing.
The pump relief valve was stuck, thus my oil problems
The pump relief valve was stuck, thus my oil problems
Last edited by nullpointer; 01-03-2016 at 07:35 PM.
#251
Drifting
Thread Starter
#252
Race Director
Member Since: May 2004
Location: Raleigh, NC
Posts: 16,664
Received 1,194 Likes
on
1,053 Posts
St. Jude Donor '15
Tore the car down today, not too bad this time around. Took ~6 hours working slow and not making a mess. Also manged to keep the driver side header in place, move it and the starter to get the flywheel lock in place. Saves some time and a ton of swearing.
The pump relief valve was stuck, thus my oil problems
The pump relief valve was stuck, thus my oil problems
#254
Melting Slicks
I didn't read through the whole thread but when putting it back together,Watch when you bolt the pickup tube to oil pump that you don't pinch the o-ring,Seen it many times and happened to myself.Good luck.OK seen where you mentioned the o-ring
Last edited by DRIVER456; 04-20-2015 at 06:28 AM.
#255
Drifting
Thread Starter
Well long story short, pick up tube was clogged. Cleaned it out, and we're all good. It was some "fiberish" material, no idea what it was. Got to meet a local CF member and check out his sweet C5. Win win in my book, can't wait to finish wiring and get her tuned
#256
Drifting
Thread Starter
I'm trying to track down what wire I need for power only when I put my headlights on. If anyone knows what wire I would use, please chime in. It's easy enough to find key on power, but to switch the gauges I would like to use the headlights being on.
#257
Melting Slicks
use one of the wires off of the trunk button... i forget which one it is but it will allow you to use the dimmer and they will turn on with the running lights. just use a test light to figure out which one it is
#258
Drifting
Thread Starter
#259
Le Mans Master
I had a feeling it was clogged mine did the same thing
#260
Drifting
Thread Starter
Over the last few days I've split up my time into wiring the gauges (boost / fuel pressure), and wiring the meth kit. Finished it all up tonight. Next I need to relocate my line lock and wide band, then interior is done. Getting there
