Corvette World Challenge road race car
DESCRIPTION
former LG Motorsports World Challenge Corvette Road Race car
originally built and raced in World Challenge series by LG Motorsports
fully rebuilt frame up by AVI Racing in 2013
ACP Carbon fiber World Challenge body
ACP Lemans wing and aluminum uprights
ACP custom front splitter and undertray
1-3/4" 0.120" wall WC/SCCA/NASA regulation cage
Air jacks
Full Racepak IQ3 logger dash
Woodward steering column
2x 10lb fire suppression system
Custom ATI fuel cells w/bladders
Fuel surge tank w/ triple pumps
Tilton floor mounted race pedals
Custom Ultrashield aluminum race seat
custom front and rear tow hooks
Engine:
Fully forged LS7 440cuin 650HP
less than 15 hours on engine and drivetrain
Brodix custom ported and polished heads
FAST intake - ported
100mm TB
GM Stage 3 cam
4 stage dry sump
Pratt and Miller C5R air to water oil cooler
tuned for E85
custom 2" headers w/3.5" dual side exhaust
Turn One racing power steering pump
Suspension:
Full Penske triple adjustables with remote canisters
LG billet drop spindles
SKF racing bearings
Spherical bushings - ALL
Race ball joints
Custom front and rear sway bars
Brakes:
Brembo billet racing calipers
15" front 14" rear
Brake ducts w/ switch
fully adjustable brake bias control
front/rear bias gauges
Trans/Driveline:
Rockland T56 Transzilla close ratio DOG BOX racing transmission
fully balanced and blueprinted Bill by ZR51 Performance
MGW short shifter
Unitrax Stage 4 Diff w/ OS Giken 3:73 gears
Trans and diff coolers
QuarterMaster 7 1/4" triple disc racing clutch w/ QM race slave cylinder
Carbon fiber drive shaft with solid couplers front and rear
Wheels:
Forgeline lightweight race wheels
11" front
13" rear
Car runs and looks great. Graphics removed with fresh flat black paint. Ready to go.
Serious inquiries only. NO TEST PILOTS PLEASE!
Dropbox link to more pics and videos
https://www.dropbox.com/sh/9mw8h73on...GMaXfUE_a?dl=0
Call Wayne at 480.369.0074 for more info.
