72 Vert Lite RestoMod Project
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Nice build.
How bad are the splines on your steering shaft.
Normally, when you install a Borgeson PS box, you have to shorten the steering column shaft a bit. Most of the time, it's shortened by tapping the shaft up into the column a bit.
But in your case could you just cut the splined end of the shaft above the damaged splines and reuse your stock column?
Just thinking out loud.
PS: my buddies Scott and Rick are currently doing the Van Steel suspension in Scott's 72. Definetly top shelf products and people at Van Steel.
Bill
How bad are the splines on your steering shaft.
Normally, when you install a Borgeson PS box, you have to shorten the steering column shaft a bit. Most of the time, it's shortened by tapping the shaft up into the column a bit.
But in your case could you just cut the splined end of the shaft above the damaged splines and reuse your stock column?
Just thinking out loud.
PS: my buddies Scott and Rick are currently doing the Van Steel suspension in Scott's 72. Definetly top shelf products and people at Van Steel.
Bill
The splines were pretty beat up. I didn't think about cutting and then re-splining the shaft...that might have worked considered it needed to be reduced several inches. Oh well, I probably saw it as an excuse to buy more shiny things.
I rec'd the FR column yesterday and it is really cool so I'm kinda happy I went that route.
Yep, I'm a VS fan, I met Paul and the guys at Carlisle last year, great group.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
I liked their (VS) fitment better than the Sharkbite. Althoiugh SB looks cool under foot I wasn't a fan of the articulating suspension. Once I started working with VS I was sold. Their customer service is top notch.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
I spent several weeks messing around with...wait for it...THE RAG JOINT! Turns out the rag joint that was provided by Borgeson does not fit the Flaming River column (both were supposed to be 1" x 48 spline on the columne end). So I went ahead and ordered the 1x48 U joint from Flaming River with a double D on the box side and thought that would be it. Well, I was dead wrong because the FR U joint DD was slightly smaller than the output shaft on the Borg.
I had to get the grinder out and knock off some metal on the box to get it to fit properly. Yet again another learning experience. I have since added a set of digital calipers to the tool box. Here is a picture of everything finally put together.
I had to get the grinder out and knock off some metal on the box to get it to fit properly. Yet again another learning experience. I have since added a set of digital calipers to the tool box. Here is a picture of everything finally put together.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
While the car is at Black Wolf I'm thinking about what to do next. I believe it should be the interior next but I also need to do some body work on this car to fix various cracks etc.
So I'm asking...what should I do next???
So I'm asking...what should I do next???
Pro
Joined: Nov 2001
Posts: 534
Likes: 6
From: Cave Creek AZ
Interior, then drive it all summer, then work on the body in the fall/winter.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Every 2027 Corvette Engine Explained
Joe Kucinski
Designer Imagines A Corvette That Looks More Like a Corvette Than the Corvette
Verdad Gallardo
10 Ugly Corvettes That We Still Kinda Love
Joe Kucinski
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Thanks for input...I believe I have settled into that decision at this point. I have plenty of time to think about it because it will take 2-3 weeks before the car is ready to come home...really wish I had a larger work space...I could've tackled the engine pull my self...oh well.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
It has been a number of weeks since my last post so I am happy to be able to share some progress with everyone...and some new challenges. I went down to the shop today to take some pics of the motor finally resting comfortably on it's mounts for the first time in seven months. Man it looks good in there with the new hardware surrounding it. Can't wait to hear it and drive it.
We did run into a problem with header fitment and the Borgeson PS box...just a little tight and touching (although barely) in two spots. No problem we'll modify the tubes slightly so they do not touch...like this
...lol. Spray those areas with hi-temp and away we go. May even wrap these headers down to the kick out for extra heat abatement and look...haven't decided.
I hope to have some more photos in few weeks of the finished product...
...ya right, I should be so lucky.
We did run into a problem with header fitment and the Borgeson PS box...just a little tight and touching (although barely) in two spots. No problem we'll modify the tubes slightly so they do not touch...like this
...lol. Spray those areas with hi-temp and away we go. May even wrap these headers down to the kick out for extra heat abatement and look...haven't decided.I hope to have some more photos in few weeks of the finished product...
...ya right, I should be so lucky.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
It's been about a month since my last update but things are moving slower than anticipated with the engine install. No real issues, the shop is simply crazy busy so they are taking more time to complete things.
I finally received my rocker moldings from Paragon after a 4 month wait so I dropped by the shop to deliver them and see how things are progressing. I was delighted to see that they have installed the headers and the March performance serp pullies. I suspect it will take another two to three weeks...can't wait. Losing prime driving weather but I'm betting that rebuilt 454 will make me forget all about it.
I finally received my rocker moldings from Paragon after a 4 month wait so I dropped by the shop to deliver them and see how things are progressing. I was delighted to see that they have installed the headers and the March performance serp pullies. I suspect it will take another two to three weeks...can't wait. Losing prime driving weather but I'm betting that rebuilt 454 will make me forget all about it.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Been a while since I updated this...been on vacation, work etc. Anyway, I visited the shop this morning and things are coming along although slowly. They have all the major components installed and believe we're no more than two weeks out from bringing the car home. They have the sidepipes installed as well and I have to say they look really good against the yellow. Some pics:
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Yes, its called a KwikLift (Kwik-Lift.com). Mine is Powder Coated black. I also added the 2x6s to the sliding tray to add some additional lift for my bottle jack. There is no way I could do the work without this system given my car port constraints.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Quick update, I heard the motor fire for the first time in 9 months. Man did it sound nice. The car will be headed to the alignment shop and then back home this coming week.
I'll take a bunch of photos when it's back in the driveway this coming weekend. Man I can't wait...I'm like a kid at xmass.
I'll take a bunch of photos when it's back in the driveway this coming weekend. Man I can't wait...I'm like a kid at xmass.
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Alright, alright, alright...the car is back home!!!
But getting it there is a story in and of itself so I'll spare the details. At the end of the day Chris from Black Wolf drove the car to my house on a Sunday. Wow! that thing thumps now. I will be taking some videos of the car with engine running this weekend and posting here so y'all can hear it.
After Chris tuned the carb he suggested I swap it for new since the carb on there is a bit cagey and not particularly easy to set up. Probably do that later cuz it runs ok now the way it is. The next thing I will be doing is dropping the headers and taking them down to Jet Hot for coating inside and out. I decided to do that because the coating Doug's used is worth two cents. These suckers are already showing rust in spots and the under hood heat is a bit high. The Jet Hot should settle that heat down somewhat and I can get closer the flat black powder coated egg crate.
Couple of specs on what went into this engine build:
Turned the fly wheel, new single stage clutch, motor rebuilt by Springfield Machining, Edelbrock E-Street BBC aluminum heads, Erson Custom Grind Cam (222/226 550 Lift) Edelbrock water pump, Dewitts rad & E fans, March Performance serpentine, and MSD ignition.
But getting it there is a story in and of itself so I'll spare the details. At the end of the day Chris from Black Wolf drove the car to my house on a Sunday. Wow! that thing thumps now. I will be taking some videos of the car with engine running this weekend and posting here so y'all can hear it. After Chris tuned the carb he suggested I swap it for new since the carb on there is a bit cagey and not particularly easy to set up. Probably do that later cuz it runs ok now the way it is. The next thing I will be doing is dropping the headers and taking them down to Jet Hot for coating inside and out. I decided to do that because the coating Doug's used is worth two cents. These suckers are already showing rust in spots and the under hood heat is a bit high. The Jet Hot should settle that heat down somewhat and I can get closer the flat black powder coated egg crate.
Couple of specs on what went into this engine build:
Turned the fly wheel, new single stage clutch, motor rebuilt by Springfield Machining, Edelbrock E-Street BBC aluminum heads, Erson Custom Grind Cam (222/226 550 Lift) Edelbrock water pump, Dewitts rad & E fans, March Performance serpentine, and MSD ignition.
Burning Brakes
Joined: Oct 2002
Posts: 914
Likes: 14
From: Aberdeen, Scotland
Nice build, a few questions
Firstly what a nice build. Thanks for the pics. I wish I would have gone w a VS coil over set up, but actually with some help from VBP, its handling well.
What wheels / tires are you running?
What carb/intake and hood do you have? I have clearance issues and was thinking of going Holley
Lastly who is Black Wolf? I really need a good carb dude for my newly build BBC.
My car is in Md,
Thanks Chris
What wheels / tires are you running?
What carb/intake and hood do you have? I have clearance issues and was thinking of going Holley
Lastly who is Black Wolf? I really need a good carb dude for my newly build BBC.
My car is in Md,
Thanks Chris
Thread Starter
Pro
Joined: Jan 2011
Posts: 586
Likes: 10
From: Alexandria VA
Firstly what a nice build. Thanks for the pics. I wish I would have gone w a VS coil over set up, but actually with some help from VBP, its handling well.
What wheels / tires are you running?
What carb/intake and hood do you have? I have clearance issues and was thinking of going Holley
Lastly who is Black Wolf? I really need a good carb dude for my newly build BBC.
My car is in Md,
Thanks Chris
What wheels / tires are you running?
What carb/intake and hood do you have? I have clearance issues and was thinking of going Holley
Lastly who is Black Wolf? I really need a good carb dude for my newly build BBC.
My car is in Md,
Thanks Chris
The wheel and tire set ups are 17x8 / 18x9.5 Boss 338 Gunmetal 245/45/17 and 285/40/18 Nitto NT555. I believe they are 5.5" back space but I can't recall.
The hood is an L88 I believe (came with the car). The intake is a Holley Street Performance and the funny thing is we don't know the carb OEM. No name on it anywhere. The air cleaner sits down over the carb and with the L88 hood I have tons of clearance.
Black Wolf Automotive Specialists located in Woodbridge VA. They are fantastic to work with and I'm sure Chris can schedule some time to work on the Carb for you...he is really good. http://www.blackwolfauto.com/
Last edited by Ranger24; Jul 4, 2015 at 09:45 PM.
Race Director
Joined: Apr 2005
Posts: 11,556
Likes: 52
From: SoCal Twin Turbo, Any Questions?
St. Jude Donor '06-'07
Ranger,
Thanks for cluing me in to your project. I just read it from start to finish. I will be giving your friends over at Black Wolf a call as I recently had an issue with the shop I was planning on using
We aren't too far from each-other. I'd love to come check out your car
Bob
Thanks for cluing me in to your project. I just read it from start to finish. I will be giving your friends over at Black Wolf a call as I recently had an issue with the shop I was planning on using
We aren't too far from each-other. I'd love to come check out your car
Bob
