[Z06] Against the grain

Reply




Old 07-15-2018, 08:39 AM
  #341
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Tuner converted my graph over to STD correction. Numbers were 655whp and 540wtq. Just incase anyone was wondering.
jayyyw is offline
Reply With Quote
Old 07-15-2018, 10:43 AM
  #342
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

jayyyw is offline
Reply With Quote
Old Yesterday, 11:50 AM
  #343
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

After about 3 months of no word from Pat G, I decided to hit him up again. My e-mail fell through the cracks, understandable since he is so busy and I wasn't in a hurry. After a few questions, he sent me my specs. The cam he spec'd is pretty similar to the B3 I am running now, but different valve events to build some cylinder pressure and different lobes. I asked for more torque, same peak rpm, and similar or better peak HP. He pretty much hit the nail on the head. Excited to put this cam in and see what it does. It won't be soon, as I still want to get 2" headers, vacuum pump, and an electric water pump first. I likely won't have apples to apples before and afters with these parts. I will be installing them all at the same time to minimize dyno time.

Last edited by jayyyw; Yesterday at 11:51 AM.
jayyyw is offline
Reply With Quote
Old Yesterday, 12:21 PM
  #344
lamboworld
CF Senior Member

Member Since: Dec 2015
Location: Harrisburg NC
Posts: 830
Thanked 83 Times in 75 Posts
Default

Do you mind sharing what lobes and the valve evens? Really just curious if he choose the same lobes that I am using LSL/LXL. My car is going back to my tuner today for cam, head gaskets, E85 conversion, etc.. and I should have it back in a few weeks. Tell me more about the Vacuum pump. I see some of you guys using them and I don't really know why.

Last edited by lamboworld; Yesterday at 01:16 PM.
lamboworld is offline
Reply With Quote
Old Yesterday, 12:40 PM
  #345
Mordeth
CF Senior Member

Mordeth's Avatar

Member Since: Jun 2005
Location: Rochester NY
Posts: 2,024
Thanked 829 Times in 514 Posts
St. Jude Donor '10, '17
Default

Nice. Glad he came through. I'm very happy with the cam he spec'd for me. It quite literally did exactly what he predicted.

What vacuum pump are you going to use?
Mordeth is offline
Reply With Quote
Old Yesterday, 01:52 PM
  #346
JesC6Z
CF Senior Member

Member Since: Mar 2018
Posts: 417
Thanks: 0
Thanked 36 Times in 31 Posts
Default

Originally Posted by jayyyw View Post
After about 3 months of no word from Pat G, I decided to hit him up again. My e-mail fell through the cracks, understandable since he is so busy and I wasn't in a hurry. After a few questions, he sent me my specs. The cam he spec'd is pretty similar to the B3 I am running now, but different valve events to build some cylinder pressure and different lobes. I asked for more torque, same peak rpm, and similar or better peak HP. He pretty much hit the nail on the head. Excited to put this cam in and see what it does. It won't be soon, as I still want to get 2" headers, vacuum pump, and an electric water pump first. I likely won't have apples to apples before and afters with these parts. I will be installing them all at the same time to minimize dyno time.
Glad you heard from Pat. Youre in TX I see and hes not too far away from you. Have you considered him taking care of the tune also once the new cam is in? He took great care of my Z in regards to the tune. Pat knows his ****.
JesC6Z is offline
Reply With Quote
Old Yesterday, 02:58 PM
  #347
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Originally Posted by lamboworld View Post
Do you mind sharing what lobes and the valve evens? Really just curious if he choose the same lobes that I am using LSL/LXL. My car is going back to my tuner today for cam, head gaskets, E85 conversion, etc.. and I should have it back in a few weeks. Tell me more about the Vacuum pump. I see some of you guys using them and I don't really know why.
RPM B3 valve events:
IVO is 10.5 BTDC ( - indicates ATDC)
IVC is 52.5 ABDC
EVO is 66.0 BBDC
EVC is 12.0 ATDC ( - indicates BTDC)
Overlap is 22.5

Pat G cam:
IVO is 14.5 BTDC ( - indicates ATDC)
IVC is 48.5 ABDC
EVO is 64.5 BBDC
EVC is 14.5 ATDC ( - indicates BTDC)
Overlap is 29

As far as the lobes, all he said was that they are custom TSP370 lobes. .370 lobe lift which is .666 with the 1.8 rocker ratio.

The vacuum pump helps evacuate positive pressure in the crankcase. This helps the rotating assembly spin with less resistance, can help rings seal against the cylinders better (especially if you use low tension rings), and helps make more power in the upper rev range. The higher you spin the motor the more it helps.
jayyyw is offline
Reply With Quote
Old Yesterday, 02:59 PM
  #348
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Originally Posted by Mordeth View Post
Nice. Glad he came through. I'm very happy with the cam he spec'd for me. It quite literally did exactly what he predicted.

What vacuum pump are you going to use?
Me too. Great to hear you had success with his camshaft. I hear nothing but good things from everyone running his custom stuff.

I will be using the GZ Sportsman with the LS kit. Seems to be working well for the guys that run it.
jayyyw is offline
Reply With Quote
Old Yesterday, 03:01 PM
  #349
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Originally Posted by JesC6Z View Post

Glad you heard from Pat. Youre in TX I see and hes not too far away from you. Have you considered him taking care of the tune also once the new cam is in? He took great care of my Z in regards to the tune. Pat knows his ****.
I've heard nothing but great things about Pat G in regards to his tuning and cam spec'ing abilities. Fortunately, I have a solid tuner already so, no, I won't be using anyone else to continue tuning my car.
jayyyw is offline
Reply With Quote
Old Yesterday, 03:15 PM
  #350
JesC6Z
CF Senior Member

Member Since: Mar 2018
Posts: 417
Thanks: 0
Thanked 36 Times in 31 Posts
Default

Originally Posted by jayyyw View Post
I've heard nothing but great things about Pat G in regards to his tuning and cam spec'ing abilities. Fortunately, I have a solid tuner already so, no, I won't be using anyone else to continue tuning my car.


JesC6Z is offline
Reply With Quote
Old Yesterday, 04:21 PM
  #351
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Eventually, I'll be taking a whack at the tuning for myself. If you couldn't tell by now, I love to tinker, so tuning my own stuff is the next logical step.
jayyyw is offline
Reply With Quote
Old Yesterday, 04:32 PM
  #352
Josh B.
CF Senior Member

Josh B.'s Avatar

Member Since: Nov 2014
Location: Murrieta, CA
Posts: 2,408
Thanked 430 Times in 329 Posts
Default

Originally Posted by jayyyw View Post
Eventually, I'll be taking a whack at the tuning for myself. If you couldn't tell by now, I love to tinker, so tuning my own stuff is the next logical step.
It will be very interesting to see what happens with the power curve with this cam. When it comes to valve events it really moves things away from software and towards expertise, guys who have done so much that they know what works and what doesn't. What retarding or advancing certain events will do to the power curve. There are so few people in the industry I would give a "full value" to their cam advice, Pat G is one of the good ones. Most others I just take their advice at face value.

Tuners who spec cams is where it's at. They have seen so much that they know what works and what doesn't.
Josh B. is offline
Reply With Quote
The Following User Says Thank You to Josh B. For This Useful Post:
jayyyw (Yesterday)
Old Yesterday, 06:22 PM
  #353
double06
CF Senior Member

Member Since: May 2006
Location: Potomac MD
Posts: 1,957
Thanked 43 Times in 42 Posts
Default

I think the new cam might be 58 degrees ABDC on the intake closing to get the 29 degrees of overlap unless I am doing something wrong. I am coming up with 243 degrees on the intake on both I though somewhere you were 251 on the new one.
double06 is offline
Reply With Quote
Old Yesterday, 06:30 PM
  #354
lamboworld
CF Senior Member

Member Since: Dec 2015
Location: Harrisburg NC
Posts: 830
Thanked 83 Times in 75 Posts
Default

Probably a 242/258 111+4 or something close to that.
lamboworld is offline
Reply With Quote
Old Yesterday, 07:05 PM
  #355
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Close, 243/259 .666/.666 111+4
jayyyw is offline
Reply With Quote
Old Yesterday, 07:17 PM
  #356
lamboworld
CF Senior Member

Member Since: Dec 2015
Location: Harrisburg NC
Posts: 830
Thanked 83 Times in 75 Posts
Default

Originally Posted by jayyyw View Post
Close, 243/259 .666/.666 111+4
can they not round up the lift to .667.
lamboworld is offline
Reply With Quote
Old Yesterday, 07:21 PM
  #357
jayyyw
CF Senior Member
Thread Starter

Member Since: Jun 2015
Location: Austin Tx
Posts: 2,201
Thanked 192 Times in 180 Posts
Default

Originally Posted by lamboworld View Post


can they not round up the lift to .667.
haha
jayyyw is offline
Reply With Quote
Old Yesterday, 09:35 PM
  #358
Millenium Z06
CF Senior Member

Millenium Z06's Avatar

Member Since: Jun 2004
Location: Frisco TX Pants Shitingly Fast
Posts: 5,314
Thanked 121 Times in 106 Posts
Default

Bad *** Jayyyw
Millenium Z06 is offline
Reply With Quote
Old Yesterday, 10:47 PM
  #359
Turbo2L
CF Senior Member

Member Since: Apr 2012
Location: Birmingham Alabama
Posts: 1,566
Thanked 92 Times in 80 Posts
Default

Just get the 249/262 .675/.652 and call it good. That way I can know what power I'd make with more compression.
Turbo2L is online now
Reply With Quote
Old Today, 12:06 PM
  #360
Da Z06
CF Senior Member

Da Z06's Avatar

Member Since: Aug 2014
Location: TX
Posts: 772
Thanked 50 Times in 46 Posts
Default

Originally Posted by jayyyw View Post
RPM B3 valve events:
IVO is 10.5 BTDC ( - indicates ATDC)
IVC is 52.5 ABDC
EVO is 66.0 BBDC
EVC is 12.0 ATDC ( - indicates BTDC)
Overlap is 22.5

Pat G cam:
IVO is 14.5 BTDC ( - indicates ATDC)
IVC is 48.5 ABDC
EVO is 64.5 BBDC
EVC is 14.5 ATDC ( - indicates BTDC)
Overlap is 29

As far as the lobes, all he said was that they are custom TSP370 lobes. .370 lobe lift which is .666 with the 1.8 rocker ratio.

The vacuum pump helps evacuate positive pressure in the crankcase. This helps the rotating assembly spin with less resistance, can help rings seal against the cylinders better (especially if you use low tension rings), and helps make more power in the upper rev range. The higher you spin the motor the more it helps.
It will be close. Ill say cam vs cam 5-7RW and TQ, bringing the TQ a bit sooner which equals his bringing the mid-range up and a window of ~50rpms. The extra lift will contribute to that gain. I personally would prefer a later IVC point and extend the RPM band a bit, and carry the power longer on top and take advantage of the Hi-Ram and upper RPM power its all matter of preference, thought process and end state.

I'm trying 15.5/53.5 on my Hi-Ram combo and see how that works out. If does not performs as expected (very subjective) then I have another grind to toy with.

The vacuum pump and EWP will contribute to it for sure!
Da Z06 is offline
