Tesla charging explained


Old 02-09-2019, 02:22 PM
  #1
ThePirate
CF Senior Member
Thread Starter

ThePirate's Avatar

Member Since: Apr 1999
Location: God's Waiting Room
Posts: 10,489
Thanks: 0
Thanked 4 Times in 3 Posts
Default Tesla charging explained

https://teslamotorsclub.com/blog/201...ime-explained/



Battery-Electric Fast-Charging Versus Time Explained

February 7, 2019[color]TMC Staff[/color][color]Analysis[/color][color]16 Comments[/color]






If BEV charging really an issue?

One often reads statements by ICE drivers that they will not buy a BEV until it can be charged as fast as ICE cars can be filled with gasoline; they often state a 5-minutes target fill time. I do not recall ever spending only 5 minutes at a gasoline station. I estimate 15 minutes as the minimum time I used to be at a gasoline station, and it was usually longer. I stop my Tesla Model 3 Long Range on long trips for personal reasons more often than needed to charge car. Tesla navigation on the screen tells me how long to charge at each Supercharger to minimize travel time; I often charge longer than that for personal reasons.

It is a fact that fast-charging (kW) a BEV battery is not at a constant speed as is the case for filling an ICE gasoline tank. In this document I examine the filling rate for fast charging of a BEV.

Consider three BEVS with maximum charge rate of 120 kW, 250 kW and 350 kW with batteries of the same battery chemistry and, therefore the same shape of the charging-power curve. If the 120-kW BEV is the Tesla Model 3 Long Range BEV (TM3LR) with about 75-kWh usable battery capacity, the power-proportional usable battery capacities for the other two cars would be about 155 kWh and 220 kWh. (I use 250 kW power because Tesla has indicated that will be the maximum power for near-future Superchargers. I use 350 kW because Electrify America is starting to install some stations with that maximum power.)

Using the mathematical formula for charging power in my previous study for charging the TM3LR using a Tesla Supercharger and TM3LR charging-power data I get the following approximate charging curves for the three BEVs:

The two higher kWh BEVs probably would not have as high efficiency as the 75-kWh BEV. The batteries would weigh more and the cars would be larger.Assume the following realistic efficiencies:



  • BEV kWh 75 155 220
  • Miles/kWh 4 3 2.5
The corresponding three curves for miles gained versus charging time using a Supercharger are:

The vertical line is about the half-way the time to full.

Note that a 75-kWh BEV with 4 miles/kWh efficiency would get about 150 miles added in twenty minutes. As the three curves show, when driving a BEV on a long trip it is not wise to fill the battery to near full; that should be done overnight at home or a hotel. Of course, the level-2 charging stations power at those locations will range from 6 kW to 19 kW, which have much longer level power curves, but the curves do tail off before reaching full. A constant 10 kW would take about 7.5 hours to fill the 75-kWh battery from empty to full, about 15.5 hours to fill the 155-kWh battery from empty to full and about 22 hours to fill the 220-kwh battery from empty to full.

It is not wise to charge from a high state of charge (SOC) to near full on a long trip because the average charging power is much lower than when starting at a low SOC. Here is such a Supercharging curve for the TM3LR starting charging at 68% SOC:

In the future, there may be new battery chemistry that possibly include super-capacitors for BEVs that charge much faster or without tailing off as quickly as shown below:



[color]Comments[/color]
Yesterday at 4:14 AMThe average person is not accustomed to starting every day with a full tank of fuel. It doesn't take long to realize that with a 300 mile range every morning, fast charging is only rarely necessary. I have traveled 12000 miles since last August and only needed to fast charge twice.

[color]Rating: 5[/color]Reply

SaghostYesterday at 5:02 AM
Odie said:At decent petrol pumps the average pumping speed is between 30 to 40 liters (europe mainland here, sorry!) per minute, truck-pumps are much faster. This means that for an average ICE with 60 to 70 liters tank the actual pumping time already is close to 2 minutes. Add 1 minute for opening and closing the tank and handling the plastic glove and add a few minutes for walking to the cashier, queueing/paying and walking back. I would guess that the average pitstop is more closer to 5 minutes, 10 at most. However, if you grab a coffee or a snack then the total pitstop time quickly increases to 15 or 20 minutes.

For Joe Average charging only becomes acceptable when they will see 1 to 1 comparable charging times, meaning having the equivalent of 70 liters diesel/petrol in about 10 to 15 minutes. According to the calculations in the article (and real world experience) we are not here yet. Is this a problem? For BEV early adopters who like BEV's and who like to spend some extra time for the greater good: no. For Joe Average who has no reason to move from ICE to BEV and only makes this move because "I have to, the Government is making me, ICEs are getting banned/expensive" this is still a problem.

We can reason that supercharging to the equivalent of a full tank is almost never required (just charge up to a SoC that is needed to get to your destination and slow charge there over night) but for a roadtripping Joe Average this is not really an argument: he or she just wants to fill it up as quickly as possible to the max range the tank/battery allows.[color]Expand Quote[/color]That's a false equivalence. Admittedly, it's one that has been heavily promoted by folks who don't like or fear EVs.

There's no real reason the fast charge rate is a key performance parameter for an EV. Folks are thinking about that because they are trying to fit the EV into their existing "stop for fuel and wait once a week" paradigm.

A properly developed EV architecture won't require that, though. Charging at home or work means never waiting for a charge except for longer road trips.

With that in mind, I think once they experience electric driving you'll seer a lot of Joe Average people willing to trade rare longer charging stops on long road trips for instant torque, lower maintenance and running costs, a full tank every morning, and all the other EV features.

The EV doesn't have to beat an ICE on every single trait to be adopted - it just has to present a substantially better overall package based on what each consumer wants - and there are several inherent advantages to EVs to help offset the weaknesses.[color]Show More[/color]
[color]Rating: 4[/color]Reply

tonybeldingYesterday at 7:52 AM[color]Another factor that some seem to overlook is that you don't have to "babysit" your car and monitor it while charging. However, I've had those same kinds of conversations with EV skeptics before. They usually go something like this:[/color]

[color]Electric cars will never get any traction until you can take road trips with them.[/color]

[color]You know you can put 180 miles of range into the car in 20 minutes at a Supercharger station, right?[/color]

[color]20 minutes? That's outrageous! I'd never be able to drive 1000 miles in a day if I had to stop for 20 minutes every 180 miles.[/color]

[color]1000 miles, really? The most I ever drove in a day was 650, and I hated it and never wanted to do that again. I can drive 500 without much stress, though.[/color]

[color]Oh yeah, well let me tell you about... [insert story about an epic Cannonball-like marathon trip they did one time many years ago] And we couldn't have done that in an electric car, so that proves they're not acceptable to anyone, anywhere![/color]

[color]But you know Tesla has sold hundreds of thousands of cars, right? People are shelling out hard-earned money for them.[/color]

[color][color]Oh, a handful of irrational fanboys like you, sure... But normal people will never accept something like that.[/color][/color]

[color]I give up.[/color]
[color]Rating: 3[/color]Reply

jboy210Yesterday at 10:08 AMAs I have gotten older I found I need to have a bathroom break every couple of hours. So Superchargers are perfect for me when I take trips.

In daily use I come home and plug in my phone and car, have dinner, watch TV, and go to bed. Magically the car and phone are charged when I get up. What could be simpler?

The whole concept of going somewhere near my home to get gas is now foreign to me, as are issues with gas stations. They might be closed, be out of the fuel grade/type I need, have a long line of cars, or .... Superchargers, and my garage plugs never close, and there is never a line.
[color]Rating: 3[/color]Reply

OdieYesterday at 4:27 AMThe option to charge at home and start with a full battery is unprecedented and is one of the big advantages of EV's over ICE. Even with my current Volkswagen GTE (still awaiting my M3 delivery here in Mainland Europe) the current 50 kilometers (during wintertime) is enough for my daily commute to work, where I can charge again for the return trip. In summer the range is about 65 to 70 kilometers and this allows me to make a return trip on a single charge. I only see petrol stations during weekend trips and I can't wait to say goodbye to the ara of legacy ICEs.
[color]Rating: 2[/color]Reply

SO16Yesterday at 8:56 AMmswlogo said:You need to Amortize all your time at a gas station vs all your time charging (home + SC). I think, all in all, it comes out about even.
SC will get better though.Seeing as how I use SC stops as food stops, the time spent as superchargers is a good thing.
[color]Rating: 2[/color]Reply

SO16Yesterday at 8:26 AMtonybelding said:
[color]1000 miles, really? The most I ever drove in a day was 650, and I hated it and never wanted to do that again. I can drive 500 without much stress, though.[/color]

[color]Oh yeah, well let me tell you about... [insert story about an epic Cannonball-like marathon trip they did one time many years ago] And we couldn't have done that in an electric car, so that proves they're not acceptable to anyone, anywhere![/color][color].[/color][color]Expand Quote[/color]I would just respond with: “If you would rather have more convenience during the cannonball run you “might” do once in a lifetime (or even once per year) vs having more convenience the rest of the year with a full tank every morning, that’s fine. If I absolutely HAD to do the cannonball run, I’d just rent a gas car.”
[color]Rating: 1[/color]Reply

mswlogoYesterday at 2:33 PMjboy210 said:I wonder how much people in 1910 made the same type of arguments about convenience when Ford brought mass produced cars to the masses. After all gas stations where not ubiquitous especially in the country where many home were still lit by candles and lamps. They had to go to a tank out back, grab a bucket, put it under a tap, filled it and carried it to your car. Then they split a lot of it on the side of the car and your seats trying to fill the tank which you say on.

Sounds like too much work, and the car make noise and smell. Roads are dirt with ruts and impassable by car when it rained. Just give me a good old horse. He can get me wherever I want and gaze on the flowers on the side of the road. And he has pulling power to get through a muddy road. Sure most of us lived our entire lives within a 12 mile radius, but who would want to go any further than their horse can find his way home?
[color]Expand Quote[/color]And the Horse had Advanced Summon mode and Self Parking too !!! You could probably Uber your horse out for the day and make few bucks too.
[color]Rating: 1[/color]Reply

TechOpsThursday at 10:39 PMThe label for Energy Density should use the units W•h/kg.
[color]Rating: 0[/color]Reply

OdieYesterday at 1:24 AMAt decent petrol pumps the average pumping speed is between 30 to 40 liters (europe mainland here, sorry!) per minute, truck-pumps are much faster. This means that for an average ICE with 60 to 70 liters tank the actual pumping time already is close to 2 minutes. Add 1 minute for opening and closing the tank and handling the plastic glove and add a few minutes for walking to the cashier, queueing/paying and walking back. I would guess that the average pitstop is more closer to 5 minutes, 10 at most. However, if you grab a coffee or a snack then the total pitstop time quickly increases to 15 or 20 minutes.

For Joe Average charging only becomes acceptable when they will see 1 to 1 comparable charging times, meaning having the equivalent of 70 liters diesel/petrol in about 10 to 15 minutes. According to the calculations in the article (and real world experience) we are not here yet. Is this a problem? For BEV early adopters who like BEV's and who like to spend some extra time for the greater good: no. For Joe Average who has no reason to move from ICE to BEV and only makes this move because "I have to, the Government is making me, ICEs are getting banned/expensive" this is still a problem.

We can reason that supercharging to the equivalent of a full tank is almost never required (just charge up to a SoC that is needed to get to your destination and slow charge there over night) but for a roadtripping Joe Average this is not really an argument: he or she just wants to fill it up as quickly as possible to the max range the tank/battery allows.[color]Show More[/color]
[color]Rating: 0[/color]

Last edited by ThePirate; 02-09-2019 at 02:25 PM.
ThePirate is online now
Old 02-09-2019, 02:40 PM
  #2
GCD1962
CF Senior Member

Member Since: Feb 2004
Location: CT
Posts: 13,681
Thanked 69 Times in 64 Posts
Default

Who cares, too much to read. Stick with a gas engine
GCD1962 is offline
Old 02-09-2019, 03:45 PM
  #3
themonk
CF Senior Member

themonk's Avatar

Member Since: Jul 2006
Location: Calgary, AB. There's a reason why white was the only color offered on every year Corvette. Proud Canadian German Jamaican!
Posts: 80,352
Thanked 583 Times in 373 Posts
St. Jude Donor '09, '12-'13-'14-'15-'16-'17
Default

Cliffs: I a ain't readin' all of that, I'll keep my fossil fuel burning cars for the time being.
themonk is offline
Old 02-09-2019, 08:09 PM
  #4
Humanoid 2.0
CF Senior Member

Humanoid 2.0's Avatar

Member Since: Jul 2004
Location: .... NJ
Posts: 75,697
Thanked 29 Times in 29 Posts
Cruise-In VII Veteran
St. Jude Donor '05-'06-'07-'08-'09-'10-'11-'12-'13-'14-'15-'16-'17-'18

Default

Originally Posted by themonk View Post
Cliffs: I a ain't readin' all of that, I'll keep my fossil fuel burning cars for the time being.
Going to agree with the Canuck, and who the **** spends 15 mins at a gas station, 5 mins for me to fill up.

Last edited by Humanoid 2.0; 02-09-2019 at 08:09 PM.
Humanoid 2.0 is offline
Old 02-09-2019, 08:46 PM
  #5
calwldlife
CF Senior Member

calwldlife's Avatar

Member Since: Jan 2007
Location: Southern Cal Ca
Posts: 39,374
Thanked 77 Times in 76 Posts
Default

i had to take a nap half way through.
how did it come out?
calwldlife is offline
Old 02-09-2019, 10:26 PM
  #6
NY09C6
CF Senior Member

NY09C6's Avatar

Member Since: Sep 1999
Location: Texas
Posts: 6,790
Thanks: 0
Thanked 205 Times in 144 Posts
Default

He lost me at 15 min to fill up a gas car. Totally false.
NY09C6 is offline
Old 02-09-2019, 10:30 PM
  #7
ratflinger
NCM Grand Opening Veteran
Support Corvetteforum!

ratflinger's Avatar

Member Since: Sep 2005
Location: Obscurification is a practicable art!
Posts: 14,622
Thanked 38 Times in 31 Posts
St. Jude Donor '11, '17
Default

ratflinger is online now
Old 02-10-2019, 07:53 AM
  #8
MY03C5Z
CF Senior Member

MY03C5Z's Avatar

Member Since: May 2004
Location: Trump 2020 🇱🇷 Keep America Great!
Posts: 5,722
Thanked 83 Times in 70 Posts
Default

Originally Posted by NY09C6 View Post
He lost me at 15 min to fill up a gas car. Totally false.
lol...same here. I can fill my truck and be gone in 5 minutes easy.
MY03C5Z is online now
Old 02-10-2019, 08:06 AM
  #9
Meh
CF Senior Member

Meh's Avatar

Member Since: Apr 2006
Location: Monterey, CA
Posts: 25,792
Thanked 35 Times in 20 Posts
Default

This is obviously a negative for electric cars. Trying to justify it doesn't make it go away.

Meh is offline
Old 02-10-2019, 08:18 AM
  #10
grandpawmoses
CF Senior Member

grandpawmoses's Avatar

Member Since: Feb 2014
Location: Center of the Universe, Alabama
Posts: 7,285
Thanked 68 Times in 33 Posts
Default

Heck, I can fill up with gas and get an oil change in 25 minutes.
grandpawmoses is online now
Old 02-10-2019, 08:24 AM
  #11
TwoSmoke
CF Senior Member

TwoSmoke's Avatar

Member Since: May 2010
Location: Sugarcane town Florida
Posts: 12,849
Thanks: 0
Thanked 28 Times in 22 Posts
Default

Plus I only fill up one time a week at most.

Would suck having to worry about charging an EV every damn day.

Talk about going back to the Stone Ages.
TwoSmoke is online now
Old 02-10-2019, 09:22 AM
  #12
Nutmeg
CF Senior Member

Member Since: Aug 2010
Posts: 2,111
Thanks: 0
Thanked 0 Times in 0 Posts
Default

I saw the other week Porsche announced a quicker charing time with their soon to be released EV, the Taycan.

The Taycan is to be able to charge 60 miles in 4 minutes. This is when one of their fast chargers are used. Charging at home will take longer.

Soon after Porsches announcement, Tesla announced that they will be releasing new, fast charging abilities. I can imagine Tesla will be similar in charging time.

Last edited by Nutmeg; 02-10-2019 at 09:22 AM.
Nutmeg is offline
Old 02-10-2019, 09:24 AM
  #13
Badger97
CF Senior Member

Member Since: Jun 2012
Location: WI
Posts: 4,029
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Originally Posted by grandpawmoses View Post
Heck, I can fill up with gas and get an oil change in 25 minutes.
No kidding. That and check the lights, the air filter, inflate all four tires, replace a cabin filter. I can do all that on my lunch break plus take 30 minutes to buy food an eat. 15 minutes to fill a tank of gas? In what, a bus?
Badger97 is offline
Old 02-10-2019, 09:49 AM
  #14
Bruze
CF Senior Member

Bruze's Avatar

Member Since: Mar 2014
Location: Finger Lakes, NYS
Posts: 7,527
Thanked 764 Times in 625 Posts
Default

Electric/coal-powered cars are not the wave of the future.

The realities of coal-powered cars in the north.
Bruze is online now
Old 02-10-2019, 10:19 AM
  #15
roadbike56
CF Senior Member
Support Corvetteforum!

roadbike56's Avatar

Member Since: Oct 2011
Location: Holly Springs NC
Posts: 6,298
Thanked 722 Times in 549 Posts
St. Jude Donor '16-'17
Default

The only way EVs are going to take over is by huge advances in battery technology that do not exist today or by government intervention. There's no way the current technology takes over in a free market economy. However I expect both the advances and the intervention to occur.
roadbike56 is offline
Old 02-10-2019, 11:33 AM
  #16
Dale1990
CF Senior Member

Dale1990's Avatar

Member Since: Apr 2002
Location: Waukesha WI
Posts: 5,491
Thanked 8 Times in 8 Posts
St. Jude Donor '15
Default

15 minutes to get gas? I guess we've found jackwagons that camp out at the pumps and cause traffic backups at gas stations.

Geez. Just yesterday I had to put in 30 gallons (ie. more than any comparable car would need) and was done in under 10 minutes.
Dale1990 is offline
Old 02-10-2019, 11:36 AM
  #17
vette6799
CF Senior Member

vette6799's Avatar

Member Since: Aug 1999
Location: Ann Arbor, MI
Posts: 27,762
Thanked 3 Times in 2 Posts
St. Jude Donor '11-'12-'13-'14-'15-'16-'17-'18-'19
Default

Originally Posted by Nutmeg View Post
I saw the other week Porsche announced a quicker charing time with their soon to be released EV, the Taycan.

The Taycan is to be able to charge 60 miles in 4 minutes. This is when one of their fast chargers are used. Charging at home will take longer.

Soon after Porsches announcement, Tesla announced that they will be releasing new, fast charging abilities. I can imagine Tesla will be similar in charging time.
It was actually BMW and Porsche and it was three times faster than Tesla.

In a few years as battery tech improves, charging will not be an issue. Unless you are on a road trip, your garage will become your gas station for all practical purposes.
vette6799 is offline
Old 02-10-2019, 11:39 AM
  #18
vette6799
CF Senior Member

vette6799's Avatar

Member Since: Aug 1999
Location: Ann Arbor, MI
Posts: 27,762
Thanked 3 Times in 2 Posts
St. Jude Donor '11-'12-'13-'14-'15-'16-'17-'18-'19
Default

Originally Posted by roadbike56 View Post
The only way EVs are going to take over is by huge advances in battery technology that do not exist today or by government intervention. There's no way the current technology takes over in a free market economy. However I expect both the advances and the intervention to occur.
There are many new battery technologies being explored today. It may take a few more years, but huge improvements will happen. Solid, relatively low maintenance ICE tech didn't happen overnight.
vette6799 is offline
Old 02-10-2019, 11:42 AM
  #19
Bruze
CF Senior Member

Bruze's Avatar

Member Since: Mar 2014
Location: Finger Lakes, NYS
Posts: 7,527
Thanked 764 Times in 625 Posts
Default

Originally Posted by roadbike56 View Post
The only way EVs are going to take over is by huge advances in battery technology that do not exist today or by government intervention. There's no way the current technology takes over in a free market economy. However I expect both the advances and the intervention to occur.
There is and has been government intervention, otherwise the EVs wouldn't even exist today. Free markets/people prefer IC engines.

The government's involvement is the subsidizing (giving taxpayer money to EV manufacturers) of EVs, bringing the cost down so at least the Greenie's will buy them. Otherwise the sticker price would be way too high.
Bruze is online now
Old 02-10-2019, 11:45 AM
  #20
BOTYNV1
CF Senior Member

BOTYNV1's Avatar

Member Since: Oct 2006
Location: Title town, Champs live here.
Posts: 54,533
Thanked 83 Times in 61 Posts
St. Jude Donor '09-'10-'11-'12-'13-'14-'15-'16-'17-'18-'19

Default

15 minutes I can put 70 gallons in and do a full DOT pre-trip, take a leak, grab some food and a drink and still have a few minutes to spare.
BOTYNV1 is offline

Thread Tools
Search this Thread
Quick Reply: Tesla charging explained


Sponsored Ads
Vendor Directory

Contact Us - About Us - Archive - Advertising - Cookie Policy - Privacy Statement - Terms of Service

© 2019 MH Sub I, LLC dba Internet Brands

We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.

  • Ask a Question
    Get answers from community experts
Question Title:
Description:
Your question will be posted in:
