454 Alternator bracket

I am in the process of getting the 454 ready to install in my 72. I have the Alternator bracket that attaches to the head. Does anyone have a picture of the upper bracket installed.This is a non PS car and I am not hooking up the AC at this time. So it would be alternator only.Drivers side. Yes I have the short water pump. Thanks

May 14, 2011 | 03:43 PM

ajrothm

Le Mans Master

Joined: May 2006

Posts: 9,993

Likes: 1,136

From: League City Tx

I have plenty of pics but they are for a PS car and the brackets are completely different. Sorry man.

May 14, 2011 | 06:51 PM

johnmb

Racer

Joined: Mar 2008

Posts: 434

Likes: 0

From: Triangle Area NC

Yep, same here...sorry!

May 14, 2011 | 11:28 PM

Ben Lurkin

Le Mans Master

Joined: Dec 2006

Posts: 5,557

Likes: 9

From: Oquirrh Mountains

St. Jude Donor '09

Go here:

http://www.zip-corvette.com/ProductD...GR-SR&CTitle=&

click on the two technical diagrams on the right-hand side of the page. They should get you going.

May 17, 2011 | 10:08 PM

RickyBerg

Pro

Joined: Aug 2010

Posts: 698

Likes: 8

From: Stockholm Sweden

Quote:

Originally Posted by mrfw

This is how it looks on my car with PS.

Maybe the picture can be to some help..

May 17, 2011 | 11:34 PM

Ironcross

Race Director

Joined: Nov 2002

Posts: 12,142

Likes: 54

From: Taylor Michigan

1968

The OE cast iron lower bracket bolts to the head, the upper adjusting arm attaches to the intake.....notice this is a non power car and the reference to the waterpump is easy, All correct Vettes use the short waterpump.....If this is a transplant engine with a long pump it could be from a passenger car as some years use the long pump....

May 17, 2011 | 11:49 PM

Ironcross

Race Director

Joined: Nov 2002

Posts: 12,142

Likes: 54

From: Taylor Michigan

92 bucks!

By the way, the Zip bracket that 'Ben references is correct...however at 92 bucks its highway robbery....Camaros use the same bracket and are only 1/2 the price .......

May 18, 2011 | 09:19 AM

Zip Corvettes

Platinum Supporting Vendor

Joined: Sep 2001

Posts: 3,665

Likes: 340

Quote:

Originally Posted by Ironcross

By the way, the Zip bracket that 'Ben references is correct...however at 92 bucks its highway robbery....Camaros use the same bracket and are only 1/2 the price .......

This is not the same bracket that is on a Camaro. A Camaro bracket will fit the Chevelle, Nova and maybe even a truck and El Camino, but it does not fit the Corvette.
I realize that it may seem expensive compared to what you USED to be able to buy them for a swap meets and 15 years ago when you could get them from GM. Although we do not make it, it took a small company to pay to have the molds built and to have these cast. That in itself is very expensive, so while they may be more than what they were 2 decades ago, it would be worse if no companies decided to make the investment to make these parts anymore, then you would looking for a used one where someone knows you can't buy these new and they would be $500, just like the big block A/C expansion tanks were until DeWitts decided to reproduce them. There is no such thing as Corvette Tax, there are just not allot of Corvettes so the price of producing the parts get spread out over less parts than say a Camaro whos parts also fit several other vehicle lines and the price gets spread over 10 times the amount of parts.
Justin

Corvette Stories

The Best of Corvette for Corvette Enthusiasts

Every Corvette Grand Sport Explained! (C2, C4, C6, C7, & C8)

Joe Kucinski

Grand Sport & Grand Sport X Launch Alongside All-New 535hp LS6 V8!

Michael S. Palmer

5 Reasons Bad Drivers Crash & 5 Ways to Avoid a Costly Mistake!

Joe Kucinski

7 Bolt-On Upgrades From Extreme Online Store to Level Up Your C6 Corvette

Pouria Savadkouei

How Likely Are These Five 2027 Corvette Rumors to Be True?

Brett Foote

9 Best Corvettes You Can Buy for Half Price (& 1 You Should NEVER Buy!)

Joe Kucinski

8 Very Best Corvettes of Amelia Island 2026

Joe Kucinski

Top 10 WORST Corvette Engineering Failures of All Time!

Joe Kucinski

10 Records the C8 Corvette Generation Has SMASHED (& 1 Glaring Failure)

Joe Kucinski

7 Wildest Corvette Concepts Ever Made

Brett Foote

May 18, 2011 | 09:22 AM

Zip Corvettes

Platinum Supporting Vendor

Joined: Sep 2001

Posts: 3,665

Likes: 340

Quote:

Originally Posted by mrfw

The brackets for P/S and non P/S were different because the pulleys on the alt were different. The P/S big block car the alt was driven only by the PS where as a non PS car the alt was driven from the crank and waterpump pulley. So you really can't mix and match the setup, you have to go with one or the other depending on you application. If you need help please do not hesitate to call us.
Thanks
Justin

May 18, 2011 | 09:59 AM

#10

BBCorv70

Melting Slicks

Joined: Apr 2007

Posts: 3,189

Likes: 111

From: Tolland CT

The bracket for non power steering application is #3882810.

A photo here...

http://cgi.ebay.com/ebaymotors/1966-...45037824807052

Looks like it's available..

BTW: If you have an AIM, look at LS5 option pages. The non PS alternator installation is illustrated there.

Last edited by BBCorv70; May 18, 2011 at 10:12 AM.

May 18, 2011 | 10:34 AM

#11

scottyp99

Le Mans Master

Joined: Mar 2008

Posts: 5,948

Likes: 71

From: Oxford MA-----You just lost the game!!!!

Wow, big-block with no power steering, you must have pretty big arm muscles!!!

Scott

May 18, 2011 | 11:05 AM

#12

DRIVESHAFT

Drifting

Joined: Aug 2005

Posts: 1,682

Likes: 3

From: League City TX

Quote:

Originally Posted by J.Abbott

This is not the same bracket that is on a Camaro. A Camaro bracket will fit the Chevelle, Nova and maybe even a truck and El Camino, but it does not fit the Corvette.

The Camaro bracket fits just fine........until you close the hood. Dont ask me how I know this.

May 18, 2011 | 11:06 AM

#13

BBCorv70

Melting Slicks

Joined: Apr 2007

Posts: 3,189

Likes: 111

From: Tolland CT

Quote:

Originally Posted by scottyp99

Wow, big-block with no power steering, you must have pretty big arm muscles!!!

Scott

Not necessarily. Mine didn't originally have power steering or power brakes. Steering wasn't hard if the car was moving. Parking was a bit of a pain. No power brakes was like trying to stop a train...

May 18, 2011 | 11:55 AM

#14

scottyp99

Le Mans Master

Joined: Mar 2008

Posts: 5,948

Likes: 71

From: Oxford MA-----You just lost the game!!!!

Quote:

Originally Posted by BBCorv70

Ya know, now that I think of it, I have had cars with manual steering, and they weren't so bad, I think I am imagining a power steering car with the power steering conked out.....very hard to steer, if it's ever happened to you, you know what I'm talking about! Sorry to highjack the thread, just consider this a bump, and I will now go away, since I have nothing constructive to offer. See ya!

Scott

May 18, 2011 | 01:16 PM

#15

Ironcross

Race Director

Joined: Nov 2002

Posts: 12,142

Likes: 54

From: Taylor Michigan

I have 3 of these, a 67 and 2 68`s.....all factory stock except for the transplants....and all use a cast iron bracket attached to the left head....as my yellow Vette does.....so whats different all the engines are the same size externally?

......

.I cant find a solo picture of the lower brackets but is in the Zip catalogue noted in an above thread

May 18, 2011 | 01:18 PM

#16

DRIVESHAFT

Drifting

Joined: Aug 2005

Posts: 1,682

Likes: 3

From: League City TX

Quote:

Originally Posted by Ironcross

The non-Corvette bracket mounts the alternator higher.

May 18, 2011 | 02:24 PM

#17

Ironcross

Race Director

Joined: Nov 2002

Posts: 12,142

Likes: 54

From: Taylor Michigan

Quote:

Originally Posted by scottyp99

Wow, big-block with no power steering, you must have pretty big arm muscles!!!

Scott

thats what they say,.......

May 18, 2011 | 03:03 PM

#18

Zip Corvettes

Platinum Supporting Vendor

Joined: Sep 2001

Posts: 3,665

Likes: 340

Quote:

Originally Posted by Ironcross

......

.I cant find a solo picture of the lower brackets but is in the Zip catalogue noted in an above thread

They look identical if you are looking at them on the engine. Yes the same bolt holes on the engine. The issue is the Camaro bracket puts the alternator in a different spot then it does on the Corvette.
