Exhaust Manifold
Thread Starter
Navigator
Joined: Sep 2023
Posts: 9
Likes: 0
Exhaust Manifold
I’ve got a 73 with a L48 my left side manifold is cracked I’d like to find a good used set of #3989036 manifolds . I’ve found RH ones but no LH does anyone know a good scours for used parts. Sec question is there a good quality set of short headers that will work without modifying stock exhaust
Team Owner
Joined: Mar 2002
Posts: 44,639
Likes: 1,827
From: Huntsville AL
First, there is no such thing as a LH 3989036 manifold, this manifold is interchangeable for both RH and LH sides and is marked 3989036 RH.
The correct 1973 Corvette w/ 350 engine manifold is 3932461 RH and is installed on both the RH & LH side of the engine. I just verified this on my original 1973 w/ L82 engine.
Also interesting is the 1985 GM parts manual doesn't list this PN in any of the 57-82 manifolds, it shows the 372243 for 66-68 RH & LH, 68-71 RH, 72-80 RH & LH. I'm assuming this is a replacement PN manifold.
The correct 1973 Corvette w/ 350 engine manifold is 3932461 RH and is installed on both the RH & LH side of the engine. I just verified this on my original 1973 w/ L82 engine.
Also interesting is the 1985 GM parts manual doesn't list this PN in any of the 57-82 manifolds, it shows the 372243 for 66-68 RH & LH, 68-71 RH, 72-80 RH & LH. I'm assuming this is a replacement PN manifold.
Burning Brakes
Joined: Oct 2013
Posts: 1,114
Likes: 520
From: McClellandtown, Pa.
I’ve got a 73 with a L48 my left side manifold is cracked I’d like to find a good used set of #3989036 manifolds . I’ve found RH ones but no LH does anyone know a good scours for used parts. Sec question is there a good quality set of short headers that will work without modifying stock exhaust
Just making sure, I see you have 1974 as part of your forum ID. You mention you have a 73 L48 and are looking for exhaust manifolds with part#3989036. That is the part number for ‘a 74 L48 w/o AIR (smog). That means these manifolds won’t be tapped for the smog tubes. If indeed you have a ‘73 you’ll need manifolds with part number#3932461. These of course will be tapped for the smog tubes, because ALL ‘73’s have AIR.
Check (google)Bairs Corvettes in Linesville, Pa.
Hope this helps,
Tooch
Race Director
Joined: May 2006
Posts: 18,692
Likes: 2,572
Hi Cmh1974,
Just making sure, I see you have 1974 as part of your forum ID. You mention you have a 73 L48 and are looking for exhaust manifolds with part#3989036. That is the part number for ‘a 74 L48 w/o AIR (smog). That means these manifolds won’t be tapped for the smog tubes. If indeed you have a ‘73 you’ll need manifolds with part number#3932461. These of course will be tapped for the smog tubes, because ALL ‘73’s have AIR.
Check (google)Bairs Corvettes in Linesville, Pa.
Hope this helps,
Tooch
Just making sure, I see you have 1974 as part of your forum ID. You mention you have a 73 L48 and are looking for exhaust manifolds with part#3989036. That is the part number for ‘a 74 L48 w/o AIR (smog). That means these manifolds won’t be tapped for the smog tubes. If indeed you have a ‘73 you’ll need manifolds with part number#3932461. These of course will be tapped for the smog tubes, because ALL ‘73’s have AIR.
Check (google)Bairs Corvettes in Linesville, Pa.
Hope this helps,
Tooch
Melting Slicks
Joined: Feb 2018
Posts: 2,321
Likes: 720
From: Marietta GA
I found a used set with the correct P/ N RH on eBay. If the studs are still on the manifolds you will need to remove them before installing them on your 73 engine. I am a pretty old guy and it took me about 10 seconds to break the first stud off using a 3/8 inch socket. Use a torch with map gas to heat up the stud before Turing it just a little, a guy on YouTube kept adding candle wax, so I did the same. After f- cking up the first stud, I took it really slow. Look for the YouTube video so you don’t brake any of the studs. I had mine power coated and they look extremely good.
Thread Starter
Navigator
Joined: Sep 2023
Posts: 9
Likes: 0
First, there is no such thing as a LH 3989036 manifold, this manifold is interchangeable for both RH and LH sides and is marked 3989036 RH.
The correct 1973 Corvette w/ 350 engine manifold is 3932461 RH and is installed on both the RH & LH side of the engine. I just verified this on my original 1973 w/ L82 engine.
Also interesting is the 1985 GM parts manual doesn't list this PN in any of the 57-82 manifolds, it shows the 372243 for 66-68 RH & LH, 68-71 RH, 72-80 RH & LH. I'm assuming this is a replacement PN manifold.
The correct 1973 Corvette w/ 350 engine manifold is 3932461 RH and is installed on both the RH & LH side of the engine. I just verified this on my original 1973 w/ L82 engine.
Also interesting is the 1985 GM parts manual doesn't list this PN in any of the 57-82 manifolds, it shows the 372243 for 66-68 RH & LH, 68-71 RH, 72-80 RH & LH. I'm assuming this is a replacement PN manifold.
thank you
Race Director
Joined: Nov 2006
Posts: 13,178
Likes: 7,784
From: Sunshine Coast, Queensland, Australia
2025 C3 of the Year Finalist - Modified
2024 C3 of the Year Finalist- Modified
2022 C3 of the Year Finalist - Modified
Cruise-In VIII Veteran
All the small blocks in the late 60"s and through the 70's are 2 inch outlets. To get 2 1/2 inch manifolds you need to look at aftermarket replacements or , if my memory is correct, 63-64 high performance small block vette.
I went with ceramic coated aftermarket manifolds that I then port matched and mildly ported.
I went with ceramic coated aftermarket manifolds that I then port matched and mildly ported.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Team Owner
Joined: Mar 2002
Posts: 44,639
Likes: 1,827
From: Huntsville AL
The GM 3932461 RH exhaust manifold is 2" outlet
GM 3846563 (LH) and 3797902 (RH) are examples of 2 1/2" exhaust manifolds. 65-67 C2's that were equipped with RPO N14 (side mount exhaust) all had 2 1/2" exhaust manifolds (someone correct me if I'm wrong).
GM 3846563 (LH) and 3797902 (RH) are examples of 2 1/2" exhaust manifolds. 65-67 C2's that were equipped with RPO N14 (side mount exhaust) all had 2 1/2" exhaust manifolds (someone correct me if I'm wrong).
Last edited by Mr D.; Sep 7, 2023 at 08:16 AM.
Team Owner
Joined: Mar 2002
Posts: 44,639
Likes: 1,827
From: Huntsville AL
Team Owner
Joined: Mar 2002
Posts: 44,639
Likes: 1,827
From: Huntsville AL
For what it's worth if you find a used set of 2 1/2" Ram Horns be prepared to open the wallet for them. Reproduction 2 1/2" Ram Horns are $400 EA which IMO is outrageous. I sold a set that came off my 65 N14 car for $300 a few months ago, they had been setting on a shelf for 12 years.
Race Director
Joined: Mar 2017
Posts: 11,923
Likes: 4,495
From: Virginia
Or you could by repros with 2 1/2 outlets. If the part number is wrong anyway, it should only matter that it works.
One possible example (call to confirm 2 1/2 outlet, and consider ceramic coating, even though it doesn't look stock).
https://www.jegs.com/i/JEGS/555/30110/10002/-1
One possible example (call to confirm 2 1/2 outlet, and consider ceramic coating, even though it doesn't look stock).
https://www.jegs.com/i/JEGS/555/30110/10002/-1
Dr. Detroit
Joined: Mar 2012
Posts: 10,095
Likes: 4,026
From: New Braunfels Texas
I’ve got a 73 with a L48 my left side manifold is cracked I’d like to find a good used set of #3989036 manifolds . I’ve found RH ones but no LH does anyone know a good scours for used parts. Sec question is there a good quality set of short headers that will work without modifying stock exhaust
Jebby
