Differential rebuild
Melting Slicks
Joined: Jul 2006
Posts: 2,291
Likes: 492
From: Salmon Arm, BC
You should check this out, Maybe someone local to you has some experience with them.
https://corvetteclubofontario.com/
https://corvetteclubofontario.com/
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Thread Starter
Instructor
Joined: Dec 2009
Posts: 146
Likes: 4
From: Penville On.
107000 miles on it. leaking oil from the pinion seal. 100 thou. end play on both side yokes. Side yokes are worn right down to C clips inside
. Gears look ok.
. Gears look ok.
Last edited by Jackk; May 28, 2024 at 08:42 PM.
Le Mans Master
Joined: Jun 2019
Posts: 7,654
Likes: 2,469
From: Indiana
..
link to mine with great advice and hand holding i got might save you some hassle.. still leak free and working perfect
https://www.corvetteforum.com/forums...ispreloading=1
Melting Slicks
Joined: Nov 2006
Posts: 3,409
Likes: 1,821
From: Apple Valley, MN
Thread Starter
Instructor
Joined: Dec 2009
Posts: 146
Likes: 4
From: Penville On.
I'm referring to the pin the the spider gears turn on inside the diff. The bolt that secures it in place is broken. Just the threaded part came out leaving the pin if you know what I mean.
Melting Slicks
Joined: Nov 2006
Posts: 3,409
Likes: 1,821
From: Apple Valley, MN
You need to turn the posi unit to allow the spider gears to move off their perches to be removed through the opening. Be sure to keep outward pressure on both side gears while you turn them or the gears will lock up. It is indeed a very tight envelope to work in.
Thread Starter
Instructor
Joined: Dec 2009
Posts: 146
Likes: 4
From: Penville On.
I have done as you suggest and removed the small spiders but I cannot get the bigger spiders with the clutch pack on to come out. The gear binds on the crown and carrier when you try to remove it.
Melting Slicks
Joined: Nov 2006
Posts: 3,409
Likes: 1,821
From: Apple Valley, MN
Those ride on roller bearings and should slide easily inward as there should be nothing in the way. There is a pair of “keepers” on each side that hold the stationary clutch plates and the ends are visible through a pair of quarter sized holes in the casting. You can try a little “persuasion” by tapping on those keepers to see if you can get the assembly to move.
