I hate headlight motors.
Thread Starter
Team Owner
Joined: Aug 2000
Posts: 40,156
Likes: 45
From: San Pedro CA
I hate headlight motors.
Who ever the **** was that invented this idea needs to rot in hell.
First....This torx...
Is a sumnabitch to reach... I don't have a Snapon socket that is both small enough and good enough quality to break that one free. Top that off, thanks to the fact my 92 has 162k miles, the screws, tho looking all nice and clean, are corroded to death.
Secondly, that POS "cotter pin"... I can't get that bastard out to save my life. It's [expletive deleted] superglued in there.
I can't drill it... damned pin is the strongest cotter pin I have ever seen. I can't hammer it, it won't move. Nothing. Not even a millimeter. I have pounded on it like a crazy man... a 1lb sledge with a steel drift and the bastard won't [expletive deleted] move!!!! It's spent 2 nites soaking in PB Blaster... and it STILL WON'T [expletive deleted] MOVE.
I am about ready to take a sledge to the entire POS. Any suggestions before I kill the [expletive deleted]?
First....This torx...
Is a sumnabitch to reach... I don't have a Snapon socket that is both small enough and good enough quality to break that one free. Top that off, thanks to the fact my 92 has 162k miles, the screws, tho looking all nice and clean, are corroded to death.
Secondly, that POS "cotter pin"... I can't get that bastard out to save my life. It's [expletive deleted] superglued in there.
I can't drill it... damned pin is the strongest cotter pin I have ever seen. I can't hammer it, it won't move. Nothing. Not even a millimeter. I have pounded on it like a crazy man... a 1lb sledge with a steel drift and the bastard won't [expletive deleted] move!!!! It's spent 2 nites soaking in PB Blaster... and it STILL WON'T [expletive deleted] MOVE.
I am about ready to take a sledge to the entire POS. Any suggestions before I kill the [expletive deleted]?
Last edited by bogus; May 8, 2007 at 12:16 AM. Reason: spelling error.
Burning Brakes
Joined: Nov 2005
Posts: 1,211
Likes: 2
From: Dumas Arkansas
I agree, I spent more time trying to remove that stupid cotter pin that it about drove me crazy. One came out easier than the other but still.
Are you trying to install new bushings's or is your motor gone?
Spray some WD 40 over the cottor or liquid wrench.
Are you trying to install new bushings's or is your motor gone?Spray some WD 40 over the cottor or liquid wrench.
Last edited by slicked25; May 8, 2007 at 12:42 AM.
Team Owner
Joined: May 2002
Posts: 24,337
Likes: 25
From: San Diego , CA Double Yellow DirtBags 1985..Z51..6-speed
You should get one of those new fangled color cameras.
As for the headlight motors, if you throw enough money at them, they flip like John Kerry.
You're welcome.
You should clean out your garage so you can fit a car in there and curse in privacy.
As for the headlight motors, if you throw enough money at them, they flip like John Kerry.
You're welcome.
You should clean out your garage so you can fit a car in there and curse in privacy.
Thread Starter
Team Owner
Joined: Aug 2000
Posts: 40,156
Likes: 45
From: San Pedro CA
Except... perhaps... Thanks for absolutely nothing... you...
Thread Starter
Team Owner
Joined: Aug 2000
Posts: 40,156
Likes: 45
From: San Pedro CA
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Team Owner
Joined: Jun 2001
Posts: 26,196
Likes: 0
From: Orlando FL
St. Jude Donor '08-'09
Nothing the backside of a 1/2" Craftsman ratchet can't fix.
The trick is to have two of them. One for beating on stuff, the other to actually use as intended. It's much better than a hammer
The trick is to have two of them. One for beating on stuff, the other to actually use as intended. It's much better than a hammer
Le Mans Master
Joined: Jun 2001
Posts: 6,694
Likes: 3
From: Less Talk, More WOT | Houston TX
If it won't budge, get a bigger hammer til it does...
Tech Contributor
Joined: Aug 2006
Posts: 9,933
Likes: 103
From: Peoria Arizona.. Resident Gold Cylon
Bogus when you figure it out let us know. Is there away to get a small vise grip on the bottom end to wiggle front and backwards while you tap from above? I assume you going to replace that POS pin anyway? Hope this helps? Good luck looks like a total PITA.
Team Owner
Joined: Oct 2000
Posts: 96,443
Likes: 9
From: Fort Knox, KY
Cruise-In IV Veteran
Cruise-In VI Veteran
Cruise-In VII Veteran
Cruise-In VIII Veteran
Remove the entire headlight door assembly and put it on a bench. It'll make working on things easier. Use an awl to scratch the alignment pattern so you'll be able to mate it up when it comes time to bolt it back in place.
The dowel pin has rusted in place. I had one do the same thing. I used a nail punch to tap mine out. It actually fractured, then it fell out. You can buy replacement pins at the hardware store. Just take your old one in as a reference to size it up.
The dowel pin has rusted in place. I had one do the same thing. I used a nail punch to tap mine out. It actually fractured, then it fell out. You can buy replacement pins at the hardware store. Just take your old one in as a reference to size it up.
Last edited by onedef92; May 8, 2007 at 01:06 PM.
Team Owner
Joined: Jun 2001
Posts: 26,196
Likes: 0
From: Orlando FL
St. Jude Donor '08-'09
I still havn't figure out how some engineer thought years and years of doing it one simple way wasn't good enough. Whats wrong with all the years of just about any car ever made that have them just pop up out of the hood? Who's bright idea was it to say... "you know what, lets change EVERYTHING, lets make the lights ROTATE 180* with a big motor on it that will break every so many years! That would be awesome!!"
that engineer needs to be shot.
The person that signed off on the design needs to be shot too.
that engineer needs to be shot.
The person that signed off on the design needs to be shot too.
Team Owner
Joined: Oct 2000
Posts: 96,443
Likes: 9
From: Fort Knox, KY
Cruise-In IV Veteran
Cruise-In VI Veteran
Cruise-In VII Veteran
Cruise-In VIII Veteran
I still havn't figure out how some engineer thought years and years of doing it one simple way wasn't good enough. Whats wrong with all the years of just about any car ever made that have them just pop up out of the hood? Who's bright idea was it to say... "you know what, lets change EVERYTHING, lets make the lights ROTATE 180* with a big motor on it that will break every so many years! That would be awesome!!"
that engineer needs to be shot.
The person that signed off on the design needs to be shot too.
that engineer needs to be shot.
The person that signed off on the design needs to be shot too.
Racer
Joined: Mar 2006
Posts: 251
Likes: 1
From: New Mexico
Bogus when you figure it out let us know. Is there away to get a small vise grip on the bottom end to wiggle front and backwards while you tap from above? I assume you going to replace that POS pin anyway? Hope this helps? Good luck looks like a total PITA
Looks like I will be doing mine next.,....
Team Owner
Joined: Sep 2002
Posts: 22,209
Likes: 12
From: OBAMA IS HITLER
Remove the entire headlight door assembly and put it on a bench. It'll make working on things easier. Use an awl to scratch the alignment pattern so you'll be able to mate it up when it comes time to bolt it back in place.
The cotter's pin has rusted in place. I had one do the same thing. I used a nail punch to tap mine out. It actually fractured, then it fell out. You can buy replacement pins at the hardware store. Just take your old one in as a reference to size it up.
The cotter's pin has rusted in place. I had one do the same thing. I used a nail punch to tap mine out. It actually fractured, then it fell out. You can buy replacement pins at the hardware store. Just take your old one in as a reference to size it up.
andy, do you have a small nail punch? or is the answer obviously yes and i asked an incredibly stupid question?
the position of that one screw you're referring to was designed by a true idiot. there's no way i could reach it direct, as depicted in the 1rst photo (and of course, it always works that way) so i used one of those "snake" screwdrivers and it worked like a charm.
Last edited by Red Tornado; May 8, 2007 at 12:00 PM.
Le Mans Master
Joined: Dec 2003
Posts: 5,768
Likes: 33
From: Van Steel Corvettes
St. Jude Donor '12-'13
I just redid mine a second time. Replaced the bearings, then the gears cracked and I replaced them with the broze units. I didn't remove that torx bit. I just removed the motor itself. The two on the bottom of the motor and the one on the back side. The one next to the frame is tight, but if you remove it last, and reinstall it first, it works like a charm. No clue on the pin, mine came out with little pressure. Heck I don't even have them on now. I'm going to see if I can find a small cotter pin that won't get in the way. Good luck...
Oh, a problem I ran into. Once you get the motors back on, get a screwdriver and a hammer. Place the screwdriver at the end of the shaft that comes out of the motor. Tap it a few times to make sure it's set in correctly. Mine had come out about a 1/8th inch and where binding which caused my gears to crack.
Oh, a problem I ran into. Once you get the motors back on, get a screwdriver and a hammer. Place the screwdriver at the end of the shaft that comes out of the motor. Tap it a few times to make sure it's set in correctly. Mine had come out about a 1/8th inch and where binding which caused my gears to crack.
Last edited by shakedown067; May 8, 2007 at 12:22 PM.
