Door help requested.
Hey.. How do set the depth adjustment on the door?
Every other car I have ever seen had a movable striker pin in the jamb that went in and out to set this. Mine (both sides, actually) appears to not move at all. They screw out.. They screw back in. But they do not move.
Is there something I'm missing here?
Car is an 85, if it matters..
Every other car I have ever seen had a movable striker pin in the jamb that went in and out to set this. Mine (both sides, actually) appears to not move at all. They screw out.. They screw back in. But they do not move.
Is there something I'm missing here?
Car is an 85, if it matters..
Last edited by confab; Jul 2, 2018 at 05:26 PM.
Race Director
Joined: Aug 2000
Posts: 11,470
Likes: 764
I've really never had mine apart, but on my 85, I could not adjust the door depth using the striker pins. the pins appear to screw into a fixed nut on the inner body door jamb. i'm guessing those pins are in a fixed position. you might get some minor adjustment on the striker receiver mechanism that's mounted internal to the door jamb, but I doubt it's much. I could not get my pins to move, up/down, in/out - fore/aft uses spacers for positioning. I was only able to adjust my doors fore/aft and with a slight radial movement using the door hinge adjustments. I've spent hours adjusting my driver's door - it's OK on the close and latch function, but barely. it's been problematic since I bought the car in 1995. takes a little extra effort to close and latch my drivers door. it's something I live with. the passenger side is perfect - open, close, alignment, etc..
if you look at the way the car is painted around the striker pins, it appears the striker pins were in position and masked prior the painting the car. it appears to be the case on my 85 since a good part of the spacers are painted, but the striker pin itself is not. the way I read it, the pins are fixed there was no intent to use them for any kind of door adjustment - ???
if you look at the way the car is painted around the striker pins, it appears the striker pins were in position and masked prior the painting the car. it appears to be the case on my 85 since a good part of the spacers are painted, but the striker pin itself is not. the way I read it, the pins are fixed there was no intent to use them for any kind of door adjustment - ???
Last edited by Joe C; Jul 3, 2018 at 12:42 AM.
Thread Starter
Melting Slicks
Joined: Nov 2013
Posts: 3,451
Likes: 336
From: Greater Cincinnati Area.
Racer
Joined: Sep 2017
Posts: 429
Likes: 18
From: Slinger Wisconsin
There are 2 adjustments inside the door behind the trim panel, one in front and one towards the rear. If you start adjusting these be careful, don't immediately slam the door.
close it slowly to be sure it isn't going to hit the frame and shatter the window.
Race Director
Joined: Aug 2000
Posts: 11,470
Likes: 764
not sure i'm using the right terminology here -- I guess i'm trying to say, how far in, or out, the door itself is toward the center line of the car, or how the outer door skin lines up with the rear quarter panel when viewing down the side of the car. the window seal tightness is a separate adjustment, and is controlled by internal door glass/regulator adjustments. when I did my door adjustment, i started at the rear door edge, or door gap, since the quarter panel is in a fixed position, and worked forward. all adjustment were made with the door hinge assemblies. I set the rear door gap, and aligned my body side molding cavities (horizontally). my front door gap is set with the hood and front fender panel adjustments.
Last edited by Joe C; Jul 3, 2018 at 01:36 AM.
Instructor
Joined: Sep 2014
Posts: 243
Likes: 23
From: Vancouver WA
If the door only misaligns with the front gill lower panel, that panel can be adjusted to be flush with the door. If the rear of the door misaligns with the rear quarter panel then I don’t know how that is adjusted.
Thread Starter
Melting Slicks
Joined: Nov 2013
Posts: 3,451
Likes: 336
From: Greater Cincinnati Area.
I dunno either? I see nothing there.
