I bought a '02 coupe last winter. Tire pressures were not showing on the DIC. I just put on new wheels, sensors, tires ..... and still nothing shows. Discount Tire tried a relearn, but no- go. Is there a trick? Helpful advice would be appreciated. Thx.
I bought a '02 coupe last winter. Tire pressures were not showing on the DIC. I just put on new wheels, sensors, tires ..... and still nothing shows. Discount Tire tried a relearn, but no- go. Is there a trick? Helpful advice would be appreciated. Thx.
From: In a parallel universe. Currently own 2014 Stingray Coupe.
C7 of the Year - Modified Finalist 2021
MO Events Coordinator
St. Jude Co-Organizer
St. Jude Donor '03 thru '25
NCM Sinkhole Donor
CI 5, 8 & 11 Veteran
Just about any strong magnet will work (a speaker magnet works fine). Or you might just check with your local Chevy dealer and see if they would program them for you. It only takes about three minutes if they know what they are doing. I had problems getting my sensors to program once (using the factory programming tool - magnet) and I stopped by my local dealer and they actually got them to work for no charge.
When I bought my tires and supplied new sensors, the shop told me they tried several times to train the new sensors. but could not do it. I asked them if they used a magnet and they said, "What?" They had never set the sensors on a C5 corvette before and did not know how to do it. I bought a magnet and did it at home in two minutes.
I've been on the road this week. Just got home last night, got a magnet, and followed the C5 Utube video this AM. I can't get the DIC to bring up 'tire training'. I can get it to FOB training, but when I 'hit the options button once' (per the video), nothing happens. I can't get from FOB training to tire training.
Also, when i push the 'gages' button and toggle through, i get oil pressure, volts, etc .... but tire pressure does not display.
Suggestions?
Suggestions anyone?
Last edited by jost6453; May 10, 2018 at 02:01 PM.
And how do I pull the codes? Sounds like I need a scan tool. Is this something an auto parts store can do?
It's easy to pull codes.
The "diagnostic display" mode is entered with the following procedure:
Turn on the ignition but don't start the engine.
Press the "reset" button to turn off any warning messages
Press and hold "options" and
While holding "options", press "fuel" four times within a 10-second period.
Inititially, the on-board diagnostics go into the "automatic" mode which shows each module's DTCs in a pre-set sequence:
10 PCM Powertrain Control Module page 6-357 - 6-361
28 TCS Traction Control system ABS on page 5-86
?? RTD Real Time damping page 3-136 (I do not have this option)
40 BCM Body Control Module page 8-405 UTD Page 8-727
60 IPC Instrument Panel Cluster page 8-508
80 radio page 8-213
99 HVAC Heater Vent-Air Conditioning page 1-118
A0 LDCM Left Door Control module page 8-904 to 8-951
A1 RDCM Right Door Control Module page 8-904 to 8-951
AC SCM Seat Control module page 8-1064 -8-1082
B0 RFA Remote Function Actuation page 8-676
Post your codes here and someone will be along shortly to assist you.
Wow.... didn't know it was that easy to get the codes. Here's what I found. Not sure why the door control modules would have anything to do with TPMS. I hope it all makes sense to someone!
Last edited by jost6453; May 10, 2018 at 04:20 PM.
Should be the last sensor that reports when you pull codes.
It says 'NO CODES'
BTW .... its possible I have 'memory' issues that I've not detected. I purchased the car last Nov and am just now starting to drive it regularly. I'm the only driver so really don't use the memory stuff. I just get in and go. But everything else seems to work fine. But it's a beautiful Electron Blue and I'd really like to get everything functioning as intended. I hope someone has the 'fix'.
When you scan through the options button for the car, do the place holder for the tire pressures not show up at all or do they show up but no pressure or XX shows for the pressure???
Since the car never showed pressures and you cannot get the TPMS programming to show up it may be that a previous owner had the TPMS RPO programmed out of the BCM so they didn't have to spend money on new sensors......
The RFA serves as the receiver for both the TPMS and the keyless entry FOB's. Do the FOB's lock/unlock the door???
the place holders do not do not show at all. The fobs do lock and unlock the doors.
With no place holders showing and not being able to get to the TPMS programming option yet the FOBS still operate, I would strongly suspect that some previous owner deleted the TPMS RPO from the BCM to avoid having to purchase TPMS. It saved them having to look at TPMS error messages because the batteries in the TPMS had given out.
I agree, if you really want the pressures to be monitored, find someone with 'tech 2' to reprogram it.
