TPMS Learning
Le Mans Master
Joined: Jun 2009
Posts: 6,528
Likes: 752
From: South Dakota
Training can be done at 0 pressure.
Some people even try training them before they mount new sensors in the wheels to make sure they work. It is also easier to get the magnet on them when they are held in your hand. If you mark each sensor for which position you trained them for, you can mount them on the correct wheel tire for that position and when you put them on the car they are already trained.
Some people even try training them before they mount new sensors in the wheels to make sure they work. It is also easier to get the magnet on them when they are held in your hand. If you mark each sensor for which position you trained them for, you can mount them on the correct wheel tire for that position and when you put them on the car they are already trained.
Thread Starter
Racer
Joined: May 2008
Posts: 298
Likes: 8
From: Quad Cities Iowa
I've been trying perform the learning process but haven't been having much luck. I've been using a 15 lb "pick-up" Neodymium magnet like this one:
Do I need to use a horse-shoe magnet like this instead?
Do I need to use a horse-shoe magnet like this instead?
Thread Starter
Racer
Joined: May 2008
Posts: 298
Likes: 8
From: Quad Cities Iowa
Thread Starter
Racer
Joined: May 2008
Posts: 298
Likes: 8
From: Quad Cities Iowa
This guy?
http://forums.corvetteforum.com/c5-t...rts-house.html
||--Genuine GM 97-00 Corvette to 01-04 Corvette TPMS Conversion--||
PKC5TPMS - $429.99 (Special Discounted Price)
This kit includes the following:
(1) #1 Key FOB
(1) #2 Key FOB
(1) Remote Control Door Lock Receiver
(1) Remote Control Door Lock Receiver Connector
(4) Tire Pressure Monitoring Sensors (TPMS)
(4) Tire Pressure Monitoring Sensor Mounting Nuts
This kit retails for $685.42 and includes everything you need to convert your TPMS and key FOB’s in your 1997-2000 Corvette to the 2001-2004 Corvette. This is done to change the future costs or current costs of the more expensive 1997-2000 Corvette TPMS and key FOB’s to the lesser expensive 2001-2004 Corvette TPMS and key FOB’s. Click on the link below to purchase.
http://store.gmpartshouse.com/partlo...subcat1=175054
http://forums.corvetteforum.com/c5-t...rts-house.html
||--Genuine GM 97-00 Corvette to 01-04 Corvette TPMS Conversion--||
PKC5TPMS - $429.99 (Special Discounted Price)
This kit includes the following:
(1) #1 Key FOB
(1) #2 Key FOB
(1) Remote Control Door Lock Receiver
(1) Remote Control Door Lock Receiver Connector
(4) Tire Pressure Monitoring Sensors (TPMS)
(4) Tire Pressure Monitoring Sensor Mounting Nuts
This kit retails for $685.42 and includes everything you need to convert your TPMS and key FOB’s in your 1997-2000 Corvette to the 2001-2004 Corvette. This is done to change the future costs or current costs of the more expensive 1997-2000 Corvette TPMS and key FOB’s to the lesser expensive 2001-2004 Corvette TPMS and key FOB’s. Click on the link below to purchase.
http://store.gmpartshouse.com/partlo...subcat1=175054
Thread Starter
Racer
Joined: May 2008
Posts: 298
Likes: 8
From: Quad Cities Iowa
looks like you can get a set of new 1997-2000 TPMS for $145
http://www.oewheelsllc.com/TPMS-Sens...ssure-Sensor_2
http://www.oewheelsllc.com/TPMS-Sens...ssure-Sensor_2
Last edited by tb30570; Jun 22, 2013 at 09:52 AM.
Pro
Joined: Apr 2006
Posts: 647
Likes: 22
From: Norwalk CT and Boynton Beach FL
Just ordered New tires (non run flats) and 4 new TPMS (delco) as my exisitng sensors are 10 years old but still work. Before I mount the tires I wanted to program/learn the new sensors. Turns out, one would NOT learn so it is defiective and I had to order a new one. A good reason to program/learn those suckers before you get them installed on the rims and it is a lot easier to do the learning/programming while you are just sitting in the drivers seat.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
2027 Corvette vs The World: Every C8 vs Its Closest Competitor
Joe Kucinski
10 Most Common Corvette Problems of the Last 20 Years!
Joe Kucinski
Instructor
Joined: Jul 2003
Posts: 181
Likes: 2
Le Mans Master
Joined: Jun 2008
Posts: 5,284
Likes: 235
From: Rockledge FL
You absolutely want to train before install. You would hate to install them just to discover one wont work and have to unmount the tire all over again. I just used a silver sharpie to mark them and train all 4. The handed them over to the tire shop who mounted the tires.
Advanced
Joined: Oct 2015
Posts: 56
Likes: 2
Instead of wasting time looking for and buying an expensive donut magnet it's WAY cheaper to get ANY strong magnet and a socket from a basic socket wrench set and put the magnet on the socket ratchet end. Those donut magnets aren't easy to find at local stores / hardware places and anyone that works on their own car has at least a basic socket set or can borrow a socket. Works like a charm and puts a magnetic field around and over the entire valve stem, not just the sides.
Last edited by keepinmyc5alive; Oct 27, 2015 at 07:19 PM.
Burning Brakes
Joined: Jul 2013
Posts: 1,008
Likes: 57
From: Kensington MD
Question regarding the magnet. I assume the ring/donut magnet is recommended in order to get a sufficient magnetic field around the sensor. Would a powerful rare earth magnet (like out of a dead hard drive) work if just placed adjacent to the valve stem?
Advanced
Joined: Oct 2015
Posts: 56
Likes: 2
Just get a regular plain old magnet from around the house as long as it's small and sufficiently strong, then put it on ratchet end side of a steel socket from a socket set and you've got your circular magnet. Works perfectly and no need for a special 'donut' magnet. Start at driver left front and go clockwise and wait for horn sound as you do each sensor. 45 seconds per wheel = plenty of time.
Last edited by keepinmyc5alive; Oct 31, 2015 at 11:18 PM.
Team Owner
Joined: Jul 2006
Posts: 22,141
Likes: 4,156
From: Kannapolis NC
Hard drive magnet works fine.
Burning Brakes
Joined: Jul 2013
Posts: 1,008
Likes: 57
From: Kensington MD
So...if the TPMS learning procedure fails, as in no horn beep from magnet at LF sensor, no DIC change from "LEARN L FRONT TIRE" after 45 sec, I assume that means the LF sensor (or its battery) is dead?
Burning Brakes
Joined: Jul 2013
Posts: 1,008
Likes: 57
From: Kensington MD
So, instead of LF as the DIC asks, just use another wheel? I guess the computer has no idea which wheel is actually being reset. I tried magnet between stem and wheel, outside of stem, and with socket as suggested earlier. Will try another wheel.
What do most folks do when getting new tires, BTW--just assume that their current TPMS sensors are good and don't need replacing? Bring another set and replace batteries in old set for the next time new tires are put on?
What do most folks do when getting new tires, BTW--just assume that their current TPMS sensors are good and don't need replacing? Bring another set and replace batteries in old set for the next time new tires are put on?
