Engine Install
I have a few questions for when I put the fresh 402 back in the car.
I'll be dropping it in from the driver side.
Should I pre install the flywheel, clutch and QuickTime bellhousing?
I'm guessing I should pull my tall valve covers for the install too.
Drop it in with the accessory bracket already on? Or slap it in after?
Any good tips from experience to keep it smooth and easy?
I'll be dropping it in from the driver side.
Should I pre install the flywheel, clutch and QuickTime bellhousing?
I'm guessing I should pull my tall valve covers for the install too.
Drop it in with the accessory bracket already on? Or slap it in after?
Any good tips from experience to keep it smooth and easy?
Administrator
Joined: Mar 2001
Posts: 367,290
Likes: 24,572
From: In a parallel universe. Currently own 2014 Stingray Coupe.
C7 of the Year - Modified Finalist 2021
MO Events Coordinator
St. Jude Co-Organizer
St. Jude Donor '03 thru '25
NCM Sinkhole Donor
CI 5, 8 & 11 Veteran
Moved to C5 Tech.
Le Mans Master
Joined: Jul 2010
Posts: 5,954
Likes: 711
I have a few questions for when I put the fresh 402 back in the car.
I'll be dropping it in from the driver side.
Should I pre install the flywheel, clutch and QuickTime bellhousing?
I'm guessing I should pull my tall valve covers for the install too.
Drop it in with the accessory bracket already on? Or slap it in after?
Any good tips from experience to keep it smooth and easy?
I'll be dropping it in from the driver side.
Should I pre install the flywheel, clutch and QuickTime bellhousing?
I'm guessing I should pull my tall valve covers for the install too.
Drop it in with the accessory bracket already on? Or slap it in after?
Any good tips from experience to keep it smooth and easy?
Be careful when directing input shaft into engine. If this is like the car ur working on i can talk u through it.
Last edited by helga203; Jul 10, 2021 at 11:27 AM.
Drifting
Joined: Apr 2019
Posts: 1,562
Likes: 324
From: Morristown, TN
I would at least set the bellhousing in position. Mount clutch assembly prior to setting engine inside. Grease the input shaft tip with some high pressure grease to help it slip into the pilot bushing. The AC bracket can be installed just before setting the engine all the way in and on the mounts. Valve covers eh maybe since they are taller. A hand cranking leveling bar attachment is the easiest so you can adjust the engines position as you go down. You will already have the engine hoist out as far as it will extend.
