Onstar antenna and I think maybe also a limited amount of electronics associated with it.
?????
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Team Owner
Joined: May 2004
Posts: 82,175
Likes: 1,319
From: McKinney TX
St. Jude Donor '21-'22-'23-'24
Race Director
Joined: Dec 2013
Posts: 12,502
Likes: 3,631
Onstar antenna, and will even notice that the solid black on the windshield is specific to hide the box.
smaller solid black section when the car does not come with onstar instead,
As for XM antenna, was a wart on the halo on the 2005 model, and then moved inside the side rear view mirror instead from 2006 upwards.
smaller solid black section when the car does not come with onstar instead,
As for XM antenna, was a wart on the halo on the 2005 model, and then moved inside the side rear view mirror instead from 2006 upwards.
Team Owner
Joined: Dec 2003
Posts: 57,408
Likes: 164
From: queensbury ny
As for XM antenna, was a wart on the halo on the 2005 model, and then moved inside the side rear view mirror instead from 2006 upwards.
Dano523 is offline Report Post
Dano523 is offline Report Post
Race Director
Joined: Dec 2013
Posts: 12,502
Likes: 3,631
Onstar module (VCIM) on the early models was in the rear hatch passenger hatch chubby area under the lid behind the carpet on the front side. On the early Z06 model since the battery was installed in the cubby campartment, the VCIM was installed under the passenger set instead. On the later models, it was moved to under the dash behind the glove box for all the models since with it mounted up in the dash behind the gloove box, not longer blocked either the power passenger seat module if such was to be installed, nor the battery location on dry sump motors.
As for the XM module, its located in the hatch area behind the carpet at the wheel hub on the hatches, and behind the center waterfall cover between the seats on the convertibles.
As for the XM module, started out as analog unit in the first C6's, and then with the Sirius XM buy out, went to digital instead. So if you need to updated the module if you do have a old analog module in the car (which will not work with XM now), the correct update module is a SIR-GM1.
http://www.onlinecarstereo.com/CarAu...FQqSaQod1K0Omg
As for the XM module, its located in the hatch area behind the carpet at the wheel hub on the hatches, and behind the center waterfall cover between the seats on the convertibles.
As for the XM module, started out as analog unit in the first C6's, and then with the Sirius XM buy out, went to digital instead. So if you need to updated the module if you do have a old analog module in the car (which will not work with XM now), the correct update module is a SIR-GM1.
http://www.onlinecarstereo.com/CarAu...FQqSaQod1K0Omg
Last edited by Dano523; Jul 21, 2015 at 12:21 PM.
Thread Starter
Heel & Toe
Joined: Jun 2015
Posts: 17
Likes: 1
Thanks !
thanks for all of the info. Now can you tell me how to stop it from falling off of the plastic tabs that hold it to the windshield. sometimes, when I am driving, after hitting a few bumps in the road. its just falls off, hanging by the wire that runs under the roof panel. very annoying !
Advanced
Joined: Aug 2014
Posts: 80
Likes: 1
From: Dutchess County NY
thanks for all of the info. Now can you tell me how to stop it from falling off of the plastic tabs that hold it to the windshield. sometimes, when I am driving, after hitting a few bumps in the road. its just falls off, hanging by the wire that runs under the roof panel. very annoying !
Last edited by sftl97; Jul 23, 2015 at 05:29 PM.
