Rims question
Burning Brakes
Joined: Jan 2014
Posts: 1,078
Likes: 262
From: swoyersville pa
i busted out my rear inner fender lips with 315/30/18 hoosiers on the 18x10.5 c5 zo6 wheels, i wonder if i could have got away with 295/30/18's? F.Y.I. they fit the front of the base/z51 car fine, offset is close to each other and there really is not much of a front inner fender lip, its more of a BEAD, much stronger than in the rear of car.
Burning Brakes
Joined: Sep 2011
Posts: 960
Likes: 40
The C5 Z06 rear wheel will stick out 21mm on the rear of the C7. But that's not including a wider tire on the wheel.
Wheels can be found that stick out and wheels can be found that don't stick out.
Well, anyone looking for 18" wheels, the Forgestar F14F has them. Get the sizes on the Forgestar website and price them on the Howey Industries website. Front wheel offset should be 56mm to 52mm and rear wheel offset should be 79mm to 73mm
.
Wheels can be found that stick out and wheels can be found that don't stick out.
Well, anyone looking for 18" wheels, the Forgestar F14F has them. Get the sizes on the Forgestar website and price them on the Howey Industries website. Front wheel offset should be 56mm to 52mm and rear wheel offset should be 79mm to 73mm
.
Last edited by B Stead; Feb 26, 2015 at 01:52 AM.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
2027 Corvette vs The World: Every C8 vs Its Closest Competitor
Joe Kucinski
Burning Brakes
Joined: Jan 2014
Posts: 1,078
Likes: 262
From: swoyersville pa
the 17x9.5 front c5 z06 wheel is 54mm, the rear 18x10.5 is 58mm. i ran those last year( i wish i used a smaller than 315 on the rear, big trouble for me with 315/30/18 on rear. F.Y.I. not many know this but the c5 z06 front 17x9.5 fits great on the front of base c7(not z51 car), i now have z51 car, 17 will not work.
Burning Brakes
Joined: Jan 2014
Posts: 1,078
Likes: 262
From: swoyersville pa
i had two types of aftermarket c5 z06 wheels, they looked the same! but when you turn them over one set had the spokes curved out and the other spokes were flat( looking from backside of wheel) the flat spokes only fit the rear of the c7 but the curved ones fit front and rear of c7.
