Quick one
Thread Starter
1st Gear
Joined: Feb 2026
Posts: 1
Likes: 0
Quick one
So I am on the fence about doing Z51 or not. The feature I like most on Z51 is the eLSD. However, I don’t know what the non-Z51 diff will be. Does anyone have info on that? I have to assume it won’t be a 1 legger, so is it just a traditional mechanical limited slip? Or is the only real difference the gearing? Any help is appreciated. Thanks.
Moderator
Joined: Feb 2006
Posts: 39,057
Likes: 17,925
From: DFW Area TX
The non-Z51 has a mechanical limited slip differential. The Z51 has the eLSD. If you also have MSRC, you get Performance Traction Management (PTM). PTM requires both Z51 and MSRC. As you noted, gearing is also different.
.........................nonZ51.. Z51
.........................------..------
First gear............... 2.91 .. 2.91
Second gear.............. 1.76 .. 1.76
Third gear............... 1.22 .. 1.22
Fourth gear.............. 0.88 .. 0.88
Fifth gear............... 0.65 .. 0.65
Sixth gear............... 0.51 .. 0.51
Seventh gear............. 0.40 .. 0.40
Eighth gear.............. 0.33 .. 0.33
Transfer ratio........... 4.89 .. 5.17
Overall ratios:
.........................nonZ51.. Z51
.........................------..------
First gear...............14.23 ..15.04
Second gear.............. 8.61 .. 9.10
Third gear............... 5.97 .. 6.31
Fourth gear.............. 4.30 .. 4.55
Fifth gear............... 3.18 .. 3.36
Sixth gear............... 2.49 .. 2.64
Seventh gear............. 1.96 .. 2.07
Eighth gear.............. 1.61 .. 1.71
.........................nonZ51.. Z51
.........................------..------
First gear............... 2.91 .. 2.91
Second gear.............. 1.76 .. 1.76
Third gear............... 1.22 .. 1.22
Fourth gear.............. 0.88 .. 0.88
Fifth gear............... 0.65 .. 0.65
Sixth gear............... 0.51 .. 0.51
Seventh gear............. 0.40 .. 0.40
Eighth gear.............. 0.33 .. 0.33
Transfer ratio........... 4.89 .. 5.17
Overall ratios:
.........................nonZ51.. Z51
.........................------..------
First gear...............14.23 ..15.04
Second gear.............. 8.61 .. 9.10
Third gear............... 5.97 .. 6.31
Fourth gear.............. 4.30 .. 4.55
Fifth gear............... 3.18 .. 3.36
Sixth gear............... 2.49 .. 2.64
Seventh gear............. 1.96 .. 2.07
Eighth gear.............. 1.61 .. 1.71
Z51 Z51 Performance Package, includes (J55) Z51 performance brakes, (FE3) Z51 performance suspension, (NPP) performance exhaust, (GM7) performance rear axle ratio, (G96) Electronic Limited Slip Differential (eLSD), (T0A) Z51 rear spoiler, front splitter, (QUD) 245/35ZR19 front and 305/30ZR20 rear, blackwall, high performance tires and (V08) heavy-duty cooling system
CF Community Team
Joined: Apr 2016
Posts: 14,106
Likes: 7,400
From: Pittsburgh
2025 C6 of the Year Finalist - Unmodified
2024 C6 of the Year Finalist - Unmodified
2023 C6 of the Year Finalist - Unmodified
2022 C6 of the Year Finalist - Unmodified
2021 C6 of the Year Finalist - Unmodified
Well done Zymurgy!
Safety Car
Joined: Jan 2005
Posts: 4,500
Likes: 1,449
From: Pittsburgh PA
2025 C8 Stingray of the Year Finalist - Unmodified
2024 C8 of the Year Finalist - Unmodified
Good luck with the search function. I'm not sure if the question of "Is the Z51 worth it?" has ever been asked.
Drifting
Joined: Jul 2004
Posts: 1,659
Likes: 684
From: Pingree Grove IL
If you plan to keep the car a long time, doesn’t matter which one you buy as far as resale value. But, when I look at used C8 on Autotrader, I tend to look for at least the C8 with z51. I’m sure I’m not the only one that does this.
Drifting
Joined: Nov 2012
Posts: 1,670
Likes: 1,404
From: Central Ohio
I would do the opposite unless the tires have already been changed to A.S. tires, brake pads replaced to reduce dust and had the not so attractive Z51 spoiler (IMO) changed or deleted.
CF Community Team
Joined: Nov 2005
Posts: 5,217
Likes: 2,868
From: Charlotte N.C.
I've seen dozens of "I would only buy the Corvette if it had Z-51" VS "the Z-51 is worthless if you don't track" arguments. I am in the have to have Z-51 and mag ride camp.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Moderator
Joined: Feb 2006
Posts: 39,057
Likes: 17,925
From: DFW Area TX
Thanks, the key is to force it to use the Courier New font which is uniform character width. Most other fonts are proportional, so each letter has a unique width. And you have to use the periods because multiple spaces are ignored.
Instructor
Joined: Sep 2010
Posts: 132
Likes: 180
From: Hopkinsville Kentucky
2025 C8 of the Year Finalist - Modified
Z51 package: different gearing, stiffer suspension, rear spoiler front splitter, few more settings in Track mode, performance exhaust, bigger breaks and rotors, softer tires and added radiator (cooling).
with the stiffer suspension I would suggest you get mag ride.
If pushing the car on a track z51 is a must have.
If not, you maybe wasting your money and have the chance of more issues.
some just want bragging rights and I can understand that.
Good luck
with the stiffer suspension I would suggest you get mag ride.
If pushing the car on a track z51 is a must have.
If not, you maybe wasting your money and have the chance of more issues.
some just want bragging rights and I can understand that.
Good luck
Racer
Joined: Aug 2024
Posts: 498
Likes: 361
From: West of Hotlanta
The only thing I would want from the Z51 package is the heavy duty cooling!
Edit to add, I have the performance exhaust on my non Z51 which would push me to buy the Z51 if it wasn't available separately.
Edit to add, I have the performance exhaust on my non Z51 which would push me to buy the Z51 if it wasn't available separately.
