Stencils
Thread Starter
Advanced
Joined: Aug 2009
Posts: 54
Likes: 0
From: Surf City NJ
Stencils
I am in the process of restoring my 73 and I can't seem to find the exact placement of frame, gas tank, and drive shaft stencil. I also need to find the color ink those stencils used for that year. From what I researched I believe the frame and gas tank were white and the drive shaft was yellow.
Kevin
Kevin
Le Mans Master
Joined: Sep 2002
Posts: 5,236
Likes: 898
From: Myrtle Beach SC
Kevin
Lyle chamberlain would know for sure...look him up on the forum here. I've researched late C3s and by then the frame stencil color was yellow. I have a few pics of early and they were white.
But you must also consider the letter size because it varied over the years from 1/2 inch to 1 inch.
Lyle chamberlain would know for sure...look him up on the forum here. I've researched late C3s and by then the frame stencil color was yellow. I have a few pics of early and they were white.
But you must also consider the letter size because it varied over the years from 1/2 inch to 1 inch.
Burning Brakes
Joined: Aug 2007
Posts: 897
Likes: 245
From: Green Valley Ca
Have you looked at the Chassis restoration kit by Quanta
Paint
www.gastanks.com/PAINT/departme...
I used the kit for 1970. It had everything that your asking
for.
Bob
Paint
www.gastanks.com/PAINT/departme...
I used the kit for 1970. It had everything that your asking
for.
Bob
Thread Starter
Advanced
Joined: Aug 2009
Posts: 54
Likes: 0
From: Surf City NJ
mark6669
First of you did a beautiful job on your 72 and the stencil locations helped, but what do the markings near the body mounts mean? Number of shims? And what do the yellow and blue markings on the rear mean? Sorry for all the questions but I can't buy a chassis detail kit for a 73 so I am trying to make mine as complete as possible. Any more pictures would be great.
Kevin
First of you did a beautiful job on your 72 and the stencil locations helped, but what do the markings near the body mounts mean? Number of shims? And what do the yellow and blue markings on the rear mean? Sorry for all the questions but I can't buy a chassis detail kit for a 73 so I am trying to make mine as complete as possible. Any more pictures would be great.
Kevin
Drifting
Joined: Oct 2009
Posts: 1,939
Likes: 199
From: Palm Bay Florida
mark6669
First of you did a beautiful job on your 72 and the stencil locations helped, but what do the markings near the body mounts mean? Number of shims? And what do the yellow and blue markings on the rear mean? Sorry for all the questions but I can't buy a chassis detail kit for a 73 so I am trying to make mine as complete as possible. Any more pictures would be great.
Kevin
First of you did a beautiful job on your 72 and the stencil locations helped, but what do the markings near the body mounts mean? Number of shims? And what do the yellow and blue markings on the rear mean? Sorry for all the questions but I can't buy a chassis detail kit for a 73 so I am trying to make mine as complete as possible. Any more pictures would be great.
Kevin
The numbers are for shims the diff markings are quality control at the axle plant & balance mark for drive shaft I dont have digital pictures of disassembly but I will see what else I can find.
Mark
Le Mans Master
Joined: Sep 2002
Posts: 5,236
Likes: 898
From: Myrtle Beach SC
mark6669
First of you did a beautiful job on your 72 and the stencil locations helped, but what do the markings near the body mounts mean? Number of shims? And what do the yellow and blue markings on the rear mean? Sorry for all the questions but I can't buy a chassis detail kit for a 73 so I am trying to make mine as complete as possible. Any more pictures would be great.
Kevin
First of you did a beautiful job on your 72 and the stencil locations helped, but what do the markings near the body mounts mean? Number of shims? And what do the yellow and blue markings on the rear mean? Sorry for all the questions but I can't buy a chassis detail kit for a 73 so I am trying to make mine as complete as possible. Any more pictures would be great.
Kevin
You could get away with a 72 stencil kit...not much changed but you would need the trim tag date code and a frame number to get a stencil made that is consistent with a 73 built car. I'm in process of doing that for my 78. I don't have my 73 NCRS guide but I think it might list the frame part number for automatic and manual transmission. Start there. Its the three-digit suffix that is tough to replicate.
