3" drive shaft ?

Any one using a 3" drive shaft ? Not half shafts but the main drive shaft

Apr 16, 2015 | 08:12 AM

The Money Pit

Melting Slicks

Joined: Jun 2002

Posts: 2,844

Likes: 99

From: Orrtanna Pa.

I had one made years ago. The 406 was getting up there in power, and I felt I needed the added insurance in the driveline. Think it was from Driveshaft Specialties.

Apr 16, 2015 | 08:37 AM

diehrd

Thread Starter

Safety Car

Joined: Jan 2009

Posts: 4,000

Likes: 299

From: New York

thank you I should have asked sooner lol .. I am having one made @ 3" .. I was just concerned with tunnel clearance and back at the diffy .. Thank you !!!

Apr 16, 2015 | 11:49 AM

76Rat

Racer

Joined: Jun 2013

Posts: 484

Likes: 43

From: NJ

I am using a 3 1/2" aluminum shafts for the driveshaft and half shafts. Had to clearance the trans tunnel to get the driveshaft to fit. Half shafts were no problem

Last edited by 76Rat; Apr 16, 2015 at 11:52 AM. Reason: mispelled words

Apr 16, 2015 | 02:27 PM

C3 Stroker

Safety Car

Joined: Oct 2004

Posts: 3,926

Likes: 739

From: Youngstown Ohio

I have a 3" aluminum driveshaft. It fits, just center it in the tunnel.

Apr 16, 2015 | 04:40 PM

lurch59

Pro

Joined: May 2013

Posts: 672

Likes: 31

From: Rapid City South Dakota

The half shafts need to be bigger and stronger than the driveshaft due to the increased torque on them due to the gear multiplication effect of the differential.

Last edited by lurch59; Apr 16, 2015 at 04:41 PM. Reason: clarified
