Default Headlights

I just traded my Jeep for a 76 Stingray, so I’m new to the Corvette world. When we made the deal the guy told me the headlights were really slow coming up and going down, but last I couldn’t get the right side light to go down at all. The left one opens and closes slowly, but it does go down. Where do I start?
#2 it has a few small issues and I am going to need some parts. Where are some good places to buy parts?

Last edited by Doordudimus; 12-07-2017 at 06:37 AM.
Doordudimus is offline   Reply With Quote
Old 12-07-2017, 08:07 AM   #2
rsparks64
CF Senior Member

rsparks64's Avatar

Member Since: Oct 2013
Location: Maryland
Posts: 841
Thanked 33 Times in 30 Posts
Default

Quote:
Originally Posted by Doordudimus View Post
I just traded my Jeep for a 76 Stingray, so I’m new to the Corvette world. When we made the deal the guy told me the headlights were really slow coming up and going down, but last I couldn’t get the right side light to go down at all. The left one opens and closes slowly, but it does go down. Where do I start?
#2 it has a few small issues and I am going to need some parts. Where are some good places to buy parts?
Welcome. You should search the forum there is a lot of valuable information here. Also, there are specific sections where certain questions are best posted. Your car is a third generation, referred to as C3, and that is a section you should frequent and would be a good place to post your question.

You will be harassed if you do not post a picture of your new car so get some ready.

Enjoy the car and remember to save the wave.
rsparks64 is offline   Reply With Quote
Old 12-07-2017, 08:15 AM   #3
Vetteman Jack
Moderator
Support Corvetteforum!
MO Events Coordinator
St. Jude Co-Organizer
St. Jude Donor '03-'04-'05-'06-'07-'08-'09-'10-'11-'12-'13-'14-'15-'16-'17
NCM Sinkhole Donor
CI 5, 8 & 11 Veteran

Vetteman Jack's Avatar

Member Since: Mar 2001
Location: Heart of Missouri Currently Own: 2003 Milestone Edition. Previously Owned: '79, '79, '84, '89, '94, '95, '99 and '00
Posts: 248,557

Thanked 2,487 Times in 2,214 Posts
Default

Moved to C3 Tech.
Vetteman Jack is online now   Reply With Quote
Old 12-07-2017, 08:48 AM   #4
Vet76te
CF Senior Member

Vet76te's Avatar

Member Since: Sep 2005
Location: B'ham Alabama
Posts: 899
Thanks: 0
Thanked 8 Times in 3 Posts
Default

The most common culprit for headlights that stay up or work very slow would be a “headlight vacuum relay”. It’s a fairly easy job to replace and the part cost around $35 to $50.

Search this forum and you will see plenty of details on how to test and diagnose the entire system and specifically the headlight relay.
Vet76te is offline   Reply With Quote
Old 12-07-2017, 09:38 AM   #5
Alan 71
CF Senior Member

Alan 71's Avatar

Member Since: Sep 2006
Location: Westminster Maryland
Posts: 28,871
Thanks: 0
Thanked 2,251 Times in 1,994 Posts
Default

Hi D,
Welcome!
First post!

There are various reasons the head lights open and close slowly or not at all. There are 2 ways to approach fixing this:

You can make a guess at what the problem is and start buying replacement parts until you finally get to the point you buy the part that actually is causing the trouble. (Maybe you're lucky and you buy that part first, are you?)
OR
You can read over the trouble shooting information that's readily available and using a small vacuum pump with a gauge, like a 'mity-vac', test each component of the headlight system and buy the part you need.

In either case good luck!

The parts...
Are these parts ordinary Chevrolet parts that your local parts store might have or are they 76 Corvette only parts?
If they're Corvette parts you might try:
ZIP Products
Corvette Central
Paragon Corvette Reproductions
Willcox
Regards,
Alan
Alan 71 is offline   Reply With Quote
The Following User Says Thank You to Alan 71 For This Useful Post:
Doordudimus (12-08-2017)
Old 12-07-2017, 10:35 AM   #6
Willcox Corvette
Premium Supporting Vendor
St. Jude Donor '08-'09-'10-'11-'12-'13-'14-'15

Willcox Corvette's Avatar

Member Since: Aug 2006
Location: Jeffersonville Indiana 812-288-7103
Posts: 60,722
Thanked 799 Times in 722 Posts
Default

This may help you some and if you have more questions post back.








Willcox




18243
Willcox Corvette is offline   Reply With Quote
The Following User Says Thank You to Willcox Corvette For This Useful Post:
Doordudimus (12-08-2017)
Old 12-07-2017, 10:48 AM   #7
Doordudimus
Junior Member
Thread Starter

Member Since: Dec 2017
Location: Winston-salem NC
Posts: 3
Thanked 0 Times in 0 Posts
Default

Quote:
Originally Posted by rsparks64 View Post
Welcome. You should search the forum there is a lot of valuable information here. Also, there are specific sections where certain questions are best posted. Your car is a third generation, referred to as C3, and that is a section you should frequent and would be a good place to post your question.

You will be harassed if you do not post a picture of your new car so get some ready.

Enjoy the car and remember to save the wave.
Thanks for the info on my car. The Vette world is new to me, so any information on them will be appreciated and absorbed.
Doordudimus is offline   Reply With Quote
Old 12-07-2017, 10:50 AM   #8
Doordudimus
Junior Member
Thread Starter

Member Since: Dec 2017
Location: Winston-salem NC
Posts: 3
Thanked 0 Times in 0 Posts
Default

Thanks for the help guys! I am excited about my new car, and the possibilities it has.
Doordudimus is offline   Reply With Quote
Old 12-07-2017, 12:01 PM   #9
Easy Mike
CF Senior Member
Support Corvetteforum!
Cruise-In II Veteran

Easy Mike's Avatar

Member Since: Jun 2000
Location: The Bluegrass State
Posts: 34,997
Thanks: 0
Thanked 589 Times in 541 Posts
Default

Quote:
Originally Posted by Doordudimus View Post
...The Vette world is new to me, so any information on them will be appreciated and absorbed...








These will hold your interest. Plenty to "absorb".

Last edited by Easy Mike; 12-07-2017 at 12:02 PM.
Easy Mike is offline   Reply With Quote
Old 12-07-2017, 12:14 PM   #10
Peterbuilt
CF Senior Member

Peterbuilt's Avatar

Member Since: Aug 2006
Location: mount holly NC
Posts: 4,593
Thanked 192 Times in 177 Posts
Default Hi and Welcome!

Hi Mark,
Here's a 'How-to' that you can print out to help ypu test each component.
http://www.corvette-101.com/vacuum.htm

Last edited by Peterbuilt; 12-07-2017 at 12:18 PM.
Peterbuilt is online now   Reply With Quote
The Following User Says Thank You to Peterbuilt For This Useful Post:
Doordudimus (12-08-2017)
Old 12-07-2017, 12:29 PM   #11
derekderek
CF Senior Member

Member Since: Jul 2015
Location: Westville NJ
Posts: 1,311
Thanked 89 Times in 85 Posts
Default

Also start with the free repairs. WD40 the moving parts on headlight doors and start trimming back the ends of the vacuum hoses about a half inch so the stretched ends leak less. Some may split open when you reattach, but if so they were done anyway...
derekderek is offline   Reply With Quote
The Following User Says Thank You to derekderek For This Useful Post:
Doordudimus (12-08-2017)
Old 12-07-2017, 03:13 PM   #12
mobird
CF Senior Member

mobird's Avatar

Member Since: Mar 2016
Posts: 552
Thanked 42 Times in 34 Posts
Default

Really good tip for these cars: Go to harbor freight and get a cheap hand vacuum pump. Pretty sure mine was like $15 and it came with a ton of different fittings to fit all sizes of vacuum lines.


Seems like everything on these cars run on vacuum (the headlights, the wipers, the air system, etc...). Slow moving headlights probably indicates a vacuum leak. The 3 main spots where it leaks are: a cracked line, holes in the vacuum canister, or (as mentioned above) the vacuum relay.


Congrats on the new car!
mobird is offline   Reply With Quote
The Following User Says Thank You to mobird For This Useful Post:
Doordudimus (12-08-2017)
Old 12-08-2017, 08:59 AM   #13
Alan 71
CF Senior Member

Alan 71's Avatar

Member Since: Sep 2006
Location: Westminster Maryland
Posts: 28,871
Thanks: 0
Thanked 2,251 Times in 1,994 Posts
Default

Hi D,
If you think you be doing some 'other' work on your new 76 you may want to consider purchasing these 2 sources of information:

The '1976 GM Chassis Service Manual'. This was used at the deale'rs service departments by the techs.

The '1976 GM Assembly Instruction Manual" often referred to as the AIM. This was used in the assembly plant in St.Louis.

While these books don't contain the answer to EVERY question many folks find them helpful when working on their car.
They're available from larger Corvette vendors and on line.
Regards,
Alan

Here are the 2 for 71 cars to give you an idea of what to look for.
