Tachometer Woes
Thread Starter
Racer
Joined: Nov 2009
Posts: 489
Likes: 1
From: Suffolk Virginia
Tachometer Woes
I've been working on my dash, replacing lamps etc. on my '76. When I put it back together my tach didn't work. I bought a new board for it before installation, so I thought I screwed something up. So I bought a brand new tach, nothing. I'm thinking maybe a fuse. I have a bad rotator cuff and it's hard for me to get down there to check, so can anyone please tell me which fuse it is and what else is on that fuse. If something else is not working I'll know for sure.
thanks!
thanks!
Race Director
Joined: Nov 2006
Posts: 13,193
Likes: 7,791
From: Sunshine Coast, Queensland, Australia
2025 C3 of the Year Finalist - Modified
2024 C3 of the Year Finalist- Modified
2022 C3 of the Year Finalist - Modified
Cruise-In VIII Veteran
Tach works off but 3 wires. Power, Ground and Tach signal.
is the white wire connected to the distributor? Can you test said signal with with an ohm meter? May need a helper and fairly long leads on your meter. perhaps just run a temporary wire from tach connection at distributor to back of tach and see if it goes.
is the white wire connected to the distributor? Can you test said signal with with an ohm meter? May need a helper and fairly long leads on your meter. perhaps just run a temporary wire from tach connection at distributor to back of tach and see if it goes.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Thread Starter
Racer
Joined: Nov 2009
Posts: 489
Likes: 1
From: Suffolk Virginia
It did not work before. When I turn the ignition the needle moves slightly to zero. I looked at the distributor wire, its plugged in. I'll try to check it tomorrow night.
thanks for your input guys
thanks for your input guys
Le Mans Master
Joined: Jun 2019
Posts: 7,649
Likes: 2,466
From: Indiana
http://repairs.willcoxcorvette.com/1...-installation/
where did you buy tach boards?
Last edited by interpon; May 3, 2021 at 09:23 PM.
Le Mans Master
Joined: Jun 2019
Posts: 7,649
Likes: 2,466
From: Indiana
Thread Starter
Racer
Joined: Nov 2009
Posts: 489
Likes: 1
From: Suffolk Virginia
I just bought a whole new tach, its a t zero.
I finally found a clear picture of the fuse panel, 3rd fuse from bottom on right says gauges, I'll try that next.
Now that I think about it, I have a gauge in the center console, oil pressure I think, that's not working.
Feeling good about that fuse.
I'll let you know.
thanks!
I finally found a clear picture of the fuse panel, 3rd fuse from bottom on right says gauges, I'll try that next.
Now that I think about it, I have a gauge in the center console, oil pressure I think, that's not working.
Feeling good about that fuse.
I'll let you know.
thanks!
Last edited by psycho dad; May 3, 2021 at 10:29 PM.
Le Mans Master
Joined: Jun 2019
Posts: 7,649
Likes: 2,466
From: Indiana
so you had an old tach that did not work at all no movement.
you went in and changed the board (from willcox) and still no go.
you bought a new tachometer..but did you re use the new willcox board or did the new one come with it?
if you cannot zero it out (according to video with 12v and ground solid) ..i am still thinking board as you tried 2 tachs but not clear on what boards you got..
Le Mans Master
Joined: Jun 2019
Posts: 7,649
Likes: 2,466
From: Indiana
i hear ya on ripping out again but ot gets easier lol...im lucky 78 up much easier but yours looks cooler!
