Antenna
Thread Starter
Pro
Joined: Nov 2014
Posts: 506
Likes: 75
Antenna
Hi
My antenna goes up but wont go down. You can hear motor wanting to take it down. You can push it down and the last few inches it will go down but you can hear antenna motor go on and off. I removed fuse so it wont kill my battery.
It work all day till we got home
I have a 1984 corvette
Thanks
My antenna goes up but wont go down. You can hear motor wanting to take it down. You can push it down and the last few inches it will go down but you can hear antenna motor go on and off. I removed fuse so it wont kill my battery.
It work all day till we got home
I have a 1984 corvette
Thanks
Le Mans Master
Joined: Mar 2004
Posts: 5,107
Likes: 171
From: Dublin CA
There is a plastic for lack of a better word..chain inside the antenna. This has broken. You have two choices. Some have purchased rebuild kits and replaced the chain....others have bought and replaced the whole unit.
Thread Starter
Pro
Joined: Nov 2014
Posts: 506
Likes: 75
Hi
If plastic chain is broken would it also not allow it to move both ways. I just removed fuses to stop it from running all the time when radio is not on.
I have it up all the time and when you put fuse back in you hear motor running until you turn on radio. When you shut off car antenna motor is running so then i take fuse out. My understanding there is a plug at back of corvette i can unplug so I dont have to remove fuse. My question is it the motor or do a buy a kit only
Thanks
If plastic chain is broken would it also not allow it to move both ways. I just removed fuses to stop it from running all the time when radio is not on.
I have it up all the time and when you put fuse back in you hear motor running until you turn on radio. When you shut off car antenna motor is running so then i take fuse out. My understanding there is a plug at back of corvette i can unplug so I dont have to remove fuse. My question is it the motor or do a buy a kit only
Thanks
Heel & Toe
Joined: Oct 2015
Posts: 21
Likes: 1
From: Santa Barbara CA
Hi
If plastic chain is broken would it also not allow it to move both ways. I just removed fuses to stop it from running all the time when radio is not on.
I have it up all the time and when you put fuse back in you hear motor running until you turn on radio. When you shut off car antenna motor is running so then i take fuse out. My understanding there is a plug at back of corvette i can unplug so I dont have to remove fuse. My question is it the motor or do a buy a kit only
Thanks
If plastic chain is broken would it also not allow it to move both ways. I just removed fuses to stop it from running all the time when radio is not on.
I have it up all the time and when you put fuse back in you hear motor running until you turn on radio. When you shut off car antenna motor is running so then i take fuse out. My understanding there is a plug at back of corvette i can unplug so I dont have to remove fuse. My question is it the motor or do a buy a kit only
Thanks
There is one small gamble with just the antenna kit, and that's if the plastic ribbon brakes and shreds in little pieces, it may not all pull out when you pull the mast off. If that's the case, which is rare, you will need to pull the motor.
Last edited by SB96CE; Aug 29, 2017 at 11:54 PM.
Le Mans Master
Joined: Jul 2004
Posts: 6,227
Likes: 697
From: Clifton Park, NY ............Clearwater, FL ... 85 Original Owner
I just did this two weeks ago.. Antenna went up one day to work, turned the radio off, and antenna stayed up, but the motor ran. There is a plastic ribbon that brakes inside the mast. You can do this repair from the top of the car, and the motor does not need to be removed(and it's cheap); There are even kits for $30 if you do some research. That being said, if your motor in constantly running, it sounds a little fishy. Mine only cycled on/off.
There is one small gamble with just the antenna kit, and that's if the plastic ribbon brakes and shreds in little pieces, it may not all pull out when you pull the mast off. If that's the case, which is rare, you will need to pull the motor.
There is one small gamble with just the antenna kit, and that's if the plastic ribbon brakes and shreds in little pieces, it may not all pull out when you pull the mast off. If that's the case, which is rare, you will need to pull the motor.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Melting Slicks
Joined: Jan 2008
Posts: 2,054
Likes: 120
From: AZ
Done this twice in my '84, since 1985. While one side of the nylon-ish ribbon will emerge when the mast is pulled out, the other section remains inside the antenna housing. the motor may run or be intermittant, but the breakage is partially due to age and partially from old lube with plenty of dirt.
I removed the whole assembly, drilled out the case's rivets, thoroughly cleaned and relubed the internals, then used the kit's bolts to replace the rivets, knowing that I did a complete job. the hardest part is R/R of the assembly, which I accessed by partially dropping the L muffler.
There's plenty of how-tos, with pictures and this is relatively simple for a handy owner.
With the redone audio system, I wired in an antenna shutoff switch as I rarely listen to the broadcast drivel.
I removed the whole assembly, drilled out the case's rivets, thoroughly cleaned and relubed the internals, then used the kit's bolts to replace the rivets, knowing that I did a complete job. the hardest part is R/R of the assembly, which I accessed by partially dropping the L muffler.
There's plenty of how-tos, with pictures and this is relatively simple for a handy owner.
With the redone audio system, I wired in an antenna shutoff switch as I rarely listen to the broadcast drivel.
Race Director
Joined: Feb 2002
Posts: 11,610
Likes: 1,053
From: Compound in the Grove, Ga.
2026 Corvette of the Year Finalist - Unmodified
2025 C4 of the Year Winner - Unmodified
2024 C4 of the Year Finalist - Unmodified
2020 C3 of the Year Finalist - Unmodified
2019 C4 of Year Finalist (performance mods)
2018 C4 of Year Finalist
2015 C4 of the Year Finalist
St. Jude Donor '16
Done this twice in my '84, since 1985. While one side of the nylon-ish ribbon will emerge when the mast is pulled out, the other section remains inside the antenna housing. the motor may run or be intermittant, but the breakage is partially due to age and partially from old lube with plenty of dirt.
I removed the whole assembly, drilled out the case's rivets, thoroughly cleaned and relubed the internals, then used the kit's bolts to replace the rivets, knowing that I did a complete job. the hardest part is R/R of the assembly, which I accessed by partially dropping the L muffler.
There's plenty of how-tos, with pictures and this is relatively simple for a handy owner.
With the redone audio system, I wired in an antenna shutoff switch as I rarely listen to the broadcast drivel.
I removed the whole assembly, drilled out the case's rivets, thoroughly cleaned and relubed the internals, then used the kit's bolts to replace the rivets, knowing that I did a complete job. the hardest part is R/R of the assembly, which I accessed by partially dropping the L muffler.
There's plenty of how-tos, with pictures and this is relatively simple for a handy owner.
With the redone audio system, I wired in an antenna shutoff switch as I rarely listen to the broadcast drivel.
Just did the one on my 95, had about 6 inches of the cable left in the assembly. I was able to remove the assembly by removing the tire/wheel and wheel well.
Heel & Toe
Joined: Oct 2015
Posts: 21
Likes: 1
From: Santa Barbara CA
There are a few instructions online on how to do this. I do not know what the design differences are between the mid 80s and early 90s, but on mine(96), the only thing holding the mast to the motor is a retaining nut and a ground/retaining sleeve.
1)Protect your car's paint around the antenna
2)Remove rubber antenna grommet from the top of the car
3)remove black antenna sleeve retaining nut
4)turn radio on to extend antenna or extend antenna manually
5)pull up on antenna to pop the mast out of the motor(may need a swift tug)
6)Extract antenna mast and broken piece noting the direction for the ribbon cable. The old antenna sleeve will come out with it.
7)When you have confirmed all the old plastic ribbon is removed, have someone feed the new antenna with radio on, in with new sleeve and turn the radio off. The motor will take up the antenna. It may take several times
A link below to CF discussion
https://www.corvetteforum.com/forums...tructions.html
1)Protect your car's paint around the antenna
2)Remove rubber antenna grommet from the top of the car
3)remove black antenna sleeve retaining nut
4)turn radio on to extend antenna or extend antenna manually
5)pull up on antenna to pop the mast out of the motor(may need a swift tug)
6)Extract antenna mast and broken piece noting the direction for the ribbon cable. The old antenna sleeve will come out with it.
7)When you have confirmed all the old plastic ribbon is removed, have someone feed the new antenna with radio on, in with new sleeve and turn the radio off. The motor will take up the antenna. It may take several times
A link below to CF discussion
https://www.corvetteforum.com/forums...tructions.html
Last edited by SB96CE; Aug 31, 2017 at 12:07 AM.
Team Owner
Joined: Aug 2005
Posts: 34,988
Likes: 515
From: Riverside County Southern California
Co-winner 2020 C4 of the Year - Modified
2018 Corvette of Year Finalist
2017 C4 of Year
2016 C7 of Year Finalist
St. Jude Donor '09 thru '20
There are a few instructions online on how to do this. I do not know what the design differences are between the mid 80s and early 90s, but on mine(96), the only thing holding the mast to the motor is a retaining nut and a ground/retaining sleeve.
1)Protect your car's paint around the antenna
2)Remove rubber antenna grommet from the top of the car
3)remove black antenna sleeve retaining nut
4)turn radio on to extend antenna or extend antenna manually
5)pull up on antenna to pop the mast out of the motor(may need a swift tug)
6)Extract antenna mast and broken piece noting the direction for the ribbon cable. The old antenna sleeve will come out with it.
7)When you have confirmed all the old plastic ribbon is removed, have someone feed the new antenna with radio on, in with new sleeve and turn the radio off. The motor will take up the antenna. It may take several times
A link below to CF discussion
https://www.corvetteforum.com/forums...tructions.html
1)Protect your car's paint around the antenna
2)Remove rubber antenna grommet from the top of the car
3)remove black antenna sleeve retaining nut
4)turn radio on to extend antenna or extend antenna manually
5)pull up on antenna to pop the mast out of the motor(may need a swift tug)
6)Extract antenna mast and broken piece noting the direction for the ribbon cable. The old antenna sleeve will come out with it.
7)When you have confirmed all the old plastic ribbon is removed, have someone feed the new antenna with radio on, in with new sleeve and turn the radio off. The motor will take up the antenna. It may take several times
A link below to CF discussion
https://www.corvetteforum.com/forums...tructions.html
All posts are correct with great advice, but
#5 should say jerk it up with all you got. if you just pull, you will be doing that for an eternity.
The rest is easy
I just installed the antenna switch and it was easy and it is great.
Now with smart phones, memory sticks and satellite radio terrestrial radio is obsolete as long you have your network available
Le Mans Master
Joined: Jul 2004
Posts: 6,227
Likes: 697
From: Clifton Park, NY ............Clearwater, FL ... 85 Original Owner
With a coupe, you take off rear hatch molding. The plug is there. Not sure with yours
Last edited by Cruisinfanatic; Sep 2, 2017 at 11:17 AM.
Thread Starter
Pro
Joined: Nov 2014
Posts: 506
Likes: 75
Hi
I just got my antenna
it has no gears on plastic chain
instruction tell me to remove motor and drill rivet
and remove old one and install new chain. The antenna is all one piece not in section like my old one was. Anyone done one like that before
thanks
I just got my antenna
it has no gears on plastic chain
instruction tell me to remove motor and drill rivet
and remove old one and install new chain. The antenna is all one piece not in section like my old one was. Anyone done one like that before
thanks
Last edited by rat123; Sep 7, 2017 at 07:54 PM.
Race Director
Joined: Apr 2002
Posts: 10,036
Likes: 346
From: Anaheim CA
The picture is of the TIP of the antenna. You reuse the rest of the pieces.
Try this link:
http://forums.corvetteforum.com/c4-t...post1585811362
Try this link:
http://forums.corvetteforum.com/c4-t...post1585811362
