Default Jack help please!

Ok so I'm not new to working on cars, but I am new to working on my Corvette. Appreciate the help with stupid newb questions.

I'm installing an exhaust setup on Saturday. A buddy of mine has a lift. My question is, where exactly should I place the lift pads?

My second question is, what is the best advice for me when I want to use a floor back at home? Do you have to buy pads for a floor jack? Or use corvette specific pucks, will a hockey puck work?

I've searched a little and honestly haven't found much info.

Do you have to open all latches, doors, hood, & hatch to lift it or jack it up?
Reply
Old May 19, 2016 | 03:06 PM
  #2
runner140*'s Avatar
runner140*
Le Mans Master
20 Year Member
Veteran: Army
Liked
Community Favorite

Joined: Mar 2004
Posts: 8,700
Likes: 298
From: Ft. Lauderdale Fl
Default

Originally Posted by Fayeilding
Ok so I'm not new to working on cars, but I am new to working on my Corvette. Appreciate the help with stupid newb questions.

I'm installing an exhaust setup on Saturday. A buddy of mine has a lift. My question is, where exactly should I place the lift pads?

My second question is, what is the best advice for me when I want to use a floor back at home? Do you have to buy pads for a floor jack? Or use corvette specific pucks, will a hockey puck work?

I've searched a little and honestly haven't found much info.

Do you have to open all latches, doors, hood, & hatch to lift it or jack it up?
Use jacking pucks...either purchased or made from hockey pucks and a loop bolt. Do a search at the top for "preferred jacking locations".
Reply
Old May 19, 2016 | 03:14 PM
  #3
jmohn's Avatar
jmohn
Advanced

Joined: May 2013
Posts: 97
Likes: 10
From: Minnesota
Default

You do NOT have to open doors, hatches, etc. when jacking -- these cars are RIGID.
Reply
Old May 19, 2016 | 03:18 PM
  #4
Fayeilding's Avatar
Fayeilding
Thread Starter
Advanced

Joined: Apr 2016
Posts: 92
Likes: 2
Default

Thanks to both of you!
Reply
Old May 19, 2016 | 03:19 PM
  #5
BungBlaster's Avatar
BungBlaster
Advanced

Joined: Mar 2014
Posts: 66
Likes: 0
From: Coppell Texas
Default

Originally Posted by Fayeilding
Ok so I'm not new to working on cars, but I am new to working on my Corvette. Appreciate the help with stupid newb questions.

I'm installing an exhaust setup on Saturday. A buddy of mine has a lift. My question is, where exactly should I place the lift pads?

My second question is, what is the best advice for me when I want to use a floor back at home? Do you have to buy pads for a floor jack? Or use corvette specific pucks, will a hockey puck work?

I've searched a little and honestly haven't found much info.

Do you have to open all latches, doors, hood, & hatch to lift it or jack it up?
Luckily I have a friend with a C5 that showed me how when I bought my first vette. I have worked on all my own cars most of my life but vettes are really engineered for specific ways to lift. You should use the lifting pads that have the either the eye bolt (with the hockey puck) or the urethane with some way for them to key in to your frame. There are four slotted holes under the car located just to the rear of the front tire and just in front of the rear tire. It will make sense once you have the lift pad in your hand and you are looking under the car. The problem with pads that don't have a way to key in is that your car could slide off of them....

As to the doors, hood and hatch open my friends with c5's all said that it is not necessary to have anything open and that you have less chance of messing something up if you leave the doors closed since it is more ridged that way.
Attached Images

Last edited by BungBlaster; May 19, 2016 at 03:23 PM.
Reply
Old May 19, 2016 | 03:20 PM
  #6
BungBlaster's Avatar
BungBlaster
Advanced

Joined: Mar 2014
Posts: 66
Likes: 0
From: Coppell Texas
Default

Pics
Attached Images
Reply
Old May 19, 2016 | 03:22 PM
  #7
BungBlaster's Avatar
BungBlaster
Advanced

Joined: Mar 2014
Posts: 66
Likes: 0
From: Coppell Texas
Default

Pic 2
Attached Images
Reply
Old May 19, 2016 | 03:22 PM
  #8
BungBlaster's Avatar
BungBlaster
Advanced

Joined: Mar 2014
Posts: 66
Likes: 0
From: Coppell Texas
Default

Pic 3
Attached Images
Reply
Corvette Stories

The Best of Corvette for Corvette Enthusiasts

story-0

Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!

 Joe Kucinski
story-1

150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter

 Joe Kucinski
story-2

8 Coolest Corvette Pace Cars (and Replicas) of All Time

 Verdad Gallardo
story-3

Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)

 Joe Kucinski
story-4

Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!

 Verdad Gallardo
story-5

Top 10 Corvettes Coming to Mecum Indy 2026!

 Brett Foote
story-6

Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!

 Michael S. Palmer
story-7

10 Revolutionary 'Corvette Firsts' Most People Don't Know

 Joe Kucinski
story-8

5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2

 Michael S. Palmer
story-9

2027 Corvette vs The World: Every C8 vs Its Closest Competitor

 Joe Kucinski
Old May 19, 2016 | 03:23 PM
  #9
Jeff T.'s Avatar
Jeff T.
Race Director
15 Year Member
St. Jude 10 Year Donor
Liked
Community Favorite

Joined: Jul 2007
Posts: 17,719
Likes: 1,210
From: Aiken, SC
St. Jude Donor '13 thru '26
Default

I made my own from hockey pucks...

Reply
Old May 19, 2016 | 03:24 PM
  #10
UM Rebel's Avatar
UM Rebel
Drifting
15 Year Member

Joined: Apr 2007
Posts: 1,517
Likes: 159
From: Lafayette Louisiana
Default

I use a golf ball. Fits perfectly in cradle of my jack and the corner jack points. Golf ***** are easier to find in South Louisiana than hockey pucks.
Reply
Old May 19, 2016 | 03:29 PM
  #11
BungBlaster's Avatar
BungBlaster
Advanced

Joined: Mar 2014
Posts: 66
Likes: 0
From: Coppell Texas
Default

Check these links they have good info.

https://www.corvetteforum.com/forums...-question.html

https://www.corvetteforum.com/forums...g-c6-pics.html
Reply
Old May 19, 2016 | 03:44 PM
  #12
Jeff T.'s Avatar
Jeff T.
Race Director
15 Year Member
St. Jude 10 Year Donor
Liked
Community Favorite

Joined: Jul 2007
Posts: 17,719
Likes: 1,210
From: Aiken, SC
St. Jude Donor '13 thru '26
Default

Originally Posted by UM Rebel
I use a golf ball. Fits perfectly in cradle of my jack and the corner jack points. Golf ***** are easier to find in South Louisiana than hockey pucks.
LOL, I'll bet!!
Reply
Old May 19, 2016 | 04:13 PM
  #13
JR-01's Avatar
JR-01
Le Mans Master

Joined: Sep 2013
Posts: 8,900
Likes: 1,074
From: Wisconsin
Default

Originally Posted by UM Rebel
I use a golf ball. Fits perfectly in cradle of my jack and the corner jack points. Golf ***** are easier to find in South Louisiana than hockey pucks.
Titleist?
Reply
Old May 19, 2016 | 04:58 PM
  #14
Fed Up's Avatar
Fed Up
"My Dad's a TV Repairman"
Supporting Lifetime
Veteran: Army
10 Year Member

Joined: Jul 2014
Posts: 471
Likes: 153
From: San Diego
Default



Originally Posted by UM Rebel
I use a golf ball. Fits perfectly in cradle of my jack and the corner jack points. Golf ***** are easier to find in South Louisiana than hockey pucks.
You! You'll never be a member at Bushwood!
Reply
Old May 19, 2016 | 05:04 PM
  #15
04vette81's Avatar
04vette81
Racer

Joined: May 2013
Posts: 458
Likes: 135
From: Rhode Island
Default

Originally Posted by BungBlaster
Pic 3
This is how i learn best, Pictures! I never knew the jacking locations for the pucks.
Reply
Old May 19, 2016 | 07:02 PM
  #16
BungBlaster's Avatar
BungBlaster
Advanced

Joined: Mar 2014
Posts: 66
Likes: 0
From: Coppell Texas
Default

Originally Posted by 04vette81
This is how i learn best, Pictures! I never knew the jacking locations for the pucks.
Same here. Can't understand it if I can't see it or touch....😎
Reply
Old May 19, 2016 | 10:47 PM
  #17
D Griff's Avatar
D Griff
Intermediate

Joined: Oct 2014
Posts: 48
Likes: 5
From: Charlotte North Carolina
Default

http://smile.amazon.com/Corvette-Jac...words=C5+pucks

I bought these pucks, they "permanently" clip on to the jacking locations so you don't have to worry about attaching, having the pucks with you when needed, etc. I just leave them on the car always. $50 is kind of pricy, but the convenience is worth it, IMO.
Reply

Get notified of new replies

To Jack help please!

Old May 20, 2016 | 09:32 AM
  #18
JR-01's Avatar
JR-01
Le Mans Master

Joined: Sep 2013
Posts: 8,900
Likes: 1,074
From: Wisconsin
Default

Originally Posted by D Griff
http://smile.amazon.com/Corvette-Jac...words=C5+pucks

I bought these pucks, they "permanently" clip on to the jacking locations so you don't have to worry about attaching, having the pucks with you when needed, etc. I just leave them on the car always. $50 is kind of pricy, but the convenience is worth it, IMO.
I bought these, a little cheaper.:http://www.southerncarparts.com/lock...ks-p-4024.html

It really is one of the best accessories one can get for a C5. Get 'em and forget 'em.
Reply
Old May 20, 2016 | 02:39 PM
  #19
UM Rebel's Avatar
UM Rebel
Drifting
15 Year Member

Joined: Apr 2007
Posts: 1,517
Likes: 159
From: Lafayette Louisiana
Default

Originally Posted by JR-01
Titleist?
Of course!
Reply
Old May 20, 2016 | 03:01 PM
  #20
doneworking's Avatar
doneworking
Heel & Toe

Joined: May 2014
Posts: 16
Likes: 0
From: Sparks Nevada
Default

Those same slots in the frame are used to tie the car down on a trailer also. I bought the t- hooks from northern tool and hardware for 5 or 6 bucks each.
