Audio upgrade
This winter I’m planning on updating the old dated Bose system in my 01 coupe. I plan on adding new door speakers, rear speakers and a sub mounted down in the center hatch cubby, removing the factory cd changer. I’ve got a few questions about fit.
I’ve seen people mainly doing a 6.5 & 3.5 in the doors. Can you fit an 8 and a 3.5 in the doors?
I’ve seen some people say depth in the rear is an issue. Does anyone know what the max mounting depth is while still using the factory covers?
I’ve seen people mainly doing a 6.5 & 3.5 in the doors. Can you fit an 8 and a 3.5 in the doors?
I’ve seen some people say depth in the rear is an issue. Does anyone know what the max mounting depth is while still using the factory covers?
Safety Car
Joined: Jan 2019
Posts: 4,308
Likes: 3,455
From: Somewhere, Florida
St. Jude Donor '20-'21-'22-'23-'24
Yes, you can fit an 8 up front.
Personally, what I did was an 8 up front and a 1" compression driver, and no rear stage. You don't really need rear fill in a cabin this small. And there's PLENTY of depth up front to mess with.
Personally, what I did was an 8 up front and a 1" compression driver, and no rear stage. You don't really need rear fill in a cabin this small. And there's PLENTY of depth up front to mess with.
Thread Starter
Racer
Joined: Aug 2020
Posts: 485
Likes: 370
From: Basehor, KS
2022 C5 of the Year Finalist - Modified
2021 C5 of the Year Finalist - Modified
2020 C6 of the Year Finalist - Modified
Doing the 8s up front, is their still room to do a set of 3.5s? Do you need adapters?
My plan right now would be the 8s and 3.5 in the doors, 6.5s in the rear and a 10 in the center hatch. I don’t need the crazy bass anymore. I just want crisp clean sounds all around.
My plan right now would be the 8s and 3.5 in the doors, 6.5s in the rear and a 10 in the center hatch. I don’t need the crazy bass anymore. I just want crisp clean sounds all around.
Safety Car
Joined: Jan 2019
Posts: 4,308
Likes: 3,455
From: Somewhere, Florida
St. Jude Donor '20-'21-'22-'23-'24
Plenty of room. I went with shallow neodymium 8s because I didn't know up front how much depth there was, but once I learned.... there's tons. I made my own adapter crudely out of some scrap plywood by tracing the old 6.5 adapter I had and cutting a bigger hole. The spacers on the screws that hold the compression driver on the second pic were only necessary because I upgraded to a bigger driver:
Original setup using Metra 6.5 adapter:
Traced that onto some scrap plywood and cut a bigger 8" hole:
Bigger compression driver for more loud, because I'm about that life:
Original setup using Metra 6.5 adapter:
Traced that onto some scrap plywood and cut a bigger 8" hole:
Bigger compression driver for more loud, because I'm about that life:
