sway bar links?
Thread Starter
Racer
Joined: Jul 2010
Posts: 391
Likes: 67
From: Oak Point Texas formerly okc
St. Jude Donor '16
sway bar links?
I am a novice on suspension. I was looking at the rear end just inspecting and noticed these boots which are attached the rear sway bar? are cracked. The car is 20 years old and I was cracked at 20 as well. So are these links on the sway bar? Should I worry about it or not? There are lots of comments on sway bars, but I could not find anything about these little links.
Instructor
Joined: May 2005
Posts: 146
Likes: 13
From: San Jose CA
Those plastic end links were a recognized weakness that were replaced with metal ones in later years of the C5. I'd suggest just replacing them regardless of how the boots look. Doubtful you'll feel a difference in performance with the stock anti-sway bar, but for $30 each from Cultrag, it's a reasonable upgrade to a known weakness.
Instructor
Joined: May 2005
Posts: 146
Likes: 13
From: San Jose CA
"Stabilizer bar end link" is probably the most accurate name. The GM Part number is 20822934. You'll need 4, one for each corner.
Cultrag is usually the best place (least expensive, best customer service) to buy original GM Parts:
http://www.cultragfactoryparts.com/oe-gm/20822934
They're also a forum sponsor.
Cultrag is usually the best place (least expensive, best customer service) to buy original GM Parts:
http://www.cultragfactoryparts.com/oe-gm/20822934
They're also a forum sponsor.
Last edited by craig-o; Aug 14, 2016 at 08:50 PM. Reason: Adding detail
Team Owner
Joined: May 2001
Posts: 36,836
Likes: 244
From: Dear Karma, I have a list of people you missed.
St. Jude Donor '08-'09-'10-'11-'12-'13-'14-'15-'16
Dale for $19.94 ea I replaced mine with the MS50823 Mevotech units from Rock Auto. They appear to be of good quality and I've been pleased with them.
If you like I can give a you Rock Auto discount code good for an additional 5% off, good through August 21st.
LMK
http://www.rockauto.com/en/moreinfo....sn=411&jsn=411
If you like I can give a you Rock Auto discount code good for an additional 5% off, good through August 21st.
LMK
http://www.rockauto.com/en/moreinfo....sn=411&jsn=411
Thread Starter
Racer
Joined: Jul 2010
Posts: 391
Likes: 67
From: Oak Point Texas formerly okc
St. Jude Donor '16
[QUOTE=LoneStarFRC;1592849504]Dale for $19.94 ea I replaced mine with the MS50823 Mevotech units from Rock Auto. They appear to be of good quality and I've been pleased with them.
Thanks folks. Learning something new about the c5 everyday. I ordered the rear ones from Cultrag yesterday.
Is there any trick I need to be aware of when installing them. It seems pretty straight forward.
Thanks folks. Learning something new about the c5 everyday. I ordered the rear ones from Cultrag yesterday.
Is there any trick I need to be aware of when installing them. It seems pretty straight forward.
Tech Contributor
Joined: Dec 1999
Posts: 32,910
Likes: 2,402
From: Anthony TX
CI 6,7,8,9,11 Vet
St. Jude Donor '08
You need to put a small wrench or socket on the hex end of the stud after you thread the nut on to keep the stud from turning when you tighten it. Other than that, Its as easy as falling off a log!
Last edited by Bill Curlee; Aug 15, 2016 at 10:39 AM.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Team Owner
Joined: May 2001
Posts: 36,836
Likes: 244
From: Dear Karma, I have a list of people you missed.
St. Jude Donor '08-'09-'10-'11-'12-'13-'14-'15-'16
Melting Slicks
Joined: Nov 2009
Posts: 2,922
Likes: 219
From: West Branch, MI
Melting Slicks
Joined: Nov 2009
Posts: 2,922
Likes: 219
From: West Branch, MI
Heh... I think the first one is Easy as pie, then Easy as falling off a log, then Easy as taking candy from a baby, and lastly an Easy girl (I think there might be multiples saying for the gal). Just havin' some fun with my close by neighbor.
Thread Starter
Racer
Joined: Jul 2010
Posts: 391
Likes: 67
From: Oak Point Texas formerly okc
St. Jude Donor '16
When you replace these things I have these questions:
Car jacked up?
Wheel on or off?
Sway Bar connected or free from the brackets?
such a novice I am.......
I have loosened the nuts but these things seem really jammed in there.
Car jacked up?
Wheel on or off?
Sway Bar connected or free from the brackets?
such a novice I am.......
I have loosened the nuts but these things seem really jammed in there.
Instructor
Joined: May 2005
Posts: 146
Likes: 13
From: San Jose CA
I did it at the same time as a brake job, so car lifted, wheels off, suspension just hanging. I did NOT disconnect the mounting brackets.
No idea if taking wheels off is necessary, but with them off and the car in the air, there was no tension/friction at all to get these out and replaced.
No idea if taking wheels off is necessary, but with them off and the car in the air, there was no tension/friction at all to get these out and replaced.
Thread Starter
Racer
Joined: Jul 2010
Posts: 391
Likes: 67
From: Oak Point Texas formerly okc
St. Jude Donor '16
Got them done, but they were easier to remove by loosening the sway bar bracket. These things had been on there for 20 years and so were a little stubborn. But got em done! Thanks to all.
