Help! Lumbar support quit working!
Thread Starter
3rd Gear
Joined: Aug 2017
Posts: 3
Likes: 0
Help! Lumbar support quit working!
My targa is leaking and after the storm Tulsa just had (yes, I forgot to cover my baby!) The electric seat works but when I hit any 3 of the lumbar switches, no sound..... nothing.... the passenger side works and the fuse it good..... so..... switch or motor???
Intermediate
Joined: Apr 2012
Posts: 35
Likes: 0
From: Palm Bay, Florida
Scott
Thread Starter
3rd Gear
Joined: Aug 2017
Posts: 3
Likes: 0
I found a guy on Ebay that rebuilds them for $99..... is the switch very hard to get out? I'm kinda scared of breaking a plastic clip or something..... pretty sure it's the switch though bc I hit it a little yesterday and it started working..... which tells me the motor is still good..... checked it yesterday, and once again, nothing!
Intermediate
Joined: Apr 2012
Posts: 35
Likes: 0
From: Palm Bay, Florida
ok cool. I saw the switches on Ebay also for $100 to. So its the going rate to get them.
Its onloy a screw in the front of the seat and a screw on the side of the seat, and it comes right out. No big deal, less than 3 min. One connector at the rear of the switch unplugs from it. Then ya got it.
The switch itself has plastic tabs on the side of it holding it together. They just unsnap. then the PC board comes out.Im sure you will see that the board has a lot of crud and water erosion on it. Mine was looking terrible. Just cleaning it with alcohol helped a lot. I had to solder two broken lands to also fix mine.
ok?
Its onloy a screw in the front of the seat and a screw on the side of the seat, and it comes right out. No big deal, less than 3 min. One connector at the rear of the switch unplugs from it. Then ya got it.
The switch itself has plastic tabs on the side of it holding it together. They just unsnap. then the PC board comes out.Im sure you will see that the board has a lot of crud and water erosion on it. Mine was looking terrible. Just cleaning it with alcohol helped a lot. I had to solder two broken lands to also fix mine.
ok?
Thread Starter
3rd Gear
Joined: Aug 2017
Posts: 3
Likes: 0
Was worried about the metal clip inside the recliner lever..... but there is one phillips behind it, and do you know where the other is? Dang, all I've seen to purchase another one on Ebay was between $170 - $300!
Tech Contributor
Joined: Dec 1999
Posts: 32,910
Likes: 2,402
From: Anthony TX
CI 6,7,8,9,11 Vet
St. Jude Donor '08
If you want to troubleshoot,,,,, here is the schematic:
LUMBAR:
SEAT:
If you have a leak, I strongly recommend removing the seat and then the carpet and properly drying it out. If the SEAT POWER PLUG get wet,,
OH BOY will that cause all sorts of crazy stuff to happen!!
Been there done that..
PS>> If you just want a good used switch, Check out VETTENUTS (Marc) He has a fantastic C5/C6 wrecking yard.. Quality used parts.
Bill
LUMBAR:
SEAT:
If you have a leak, I strongly recommend removing the seat and then the carpet and properly drying it out. If the SEAT POWER PLUG get wet,,
OH BOY will that cause all sorts of crazy stuff to happen!! Been there done that..
PS>> If you just want a good used switch, Check out VETTENUTS (Marc) He has a fantastic C5/C6 wrecking yard.. Quality used parts.
Bill
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Intermediate
Joined: Apr 2012
Posts: 35
Likes: 0
From: Palm Bay, Florida
Yes you have to work with that clip a bit...talk to it nicely, it will come off. Yes there is a screw there. The other screw is on the front of the seat, very hard to see. Get a flash light.
Yes ebay and sometimes this site here sometimes has decent deals on the entire switch.
If you replace lands then this schematic is wonderful to help troubleshoot broken lands.
Thanks Bill!
Scott
Yes ebay and sometimes this site here sometimes has decent deals on the entire switch.
If you replace lands then this schematic is wonderful to help troubleshoot broken lands.
Thanks Bill!
Scott
