ABS module repair/replacement for a 2000 coupe
Thread Starter
Pro
Joined: Jan 2008
Posts: 631
Likes: 100
From: Naples FL
ABS module repair/replacement for a 2000 coupe
I have the ABS and Service Traction Control messages so I checked the codes and found C1255, I believe this is the EBCM does anyone know where I can get it repaired please?
Drifting
Joined: May 2020
Posts: 1,663
Likes: 702
From: Baton Rouge, Louisiana, metro area
Other than the code, do you have any driving symptoms? From what I understand, only the car’s ABS capabilities are impaired when this happens.
I have a ‘99 BTW. Just wondering….
I have a ‘99 BTW. Just wondering….
Drifting
Joined: Aug 2014
Posts: 1,402
Likes: 394
From: Virginia
St. Jude Donor '18
You can try resetting the code, and then exercising your ABS/TCS system. Take it out to a parking lot, and do some panic stops, and spin the rear tires with everything turned on. Keep resetting the code, and exercising the system. There is a chance you can rejuvenate it.
I have a 2000 C5 with only 22K miles on it. It doesn't get driven often. But I always spin the tires on the garage floor each time I start it up, and move it, to keep the system exercised. Occasionally I get the same code, but knock on wood, with a little exercise, it goes off and stays off.
I have a 2000 C5 with only 22K miles on it. It doesn't get driven often. But I always spin the tires on the garage floor each time I start it up, and move it, to keep the system exercised. Occasionally I get the same code, but knock on wood, with a little exercise, it goes off and stays off.
Burning Brakes
Joined: Feb 2022
Posts: 897
Likes: 987
From: NW Burbs of Chi-Town
2025 C5 of the Year Finalist - Modified
I have a 98. The whole EBCM thing is less than ideal on our cars. I was just reading about grounding gremlins on these cars:
https://www.corvetteforum.com/forums...tion-long.html
Worth a shot to check the grounds and connector's before you drop $1k into a used EBCM.
May the force be with you!
https://www.corvetteforum.com/forums...tion-long.html
Worth a shot to check the grounds and connector's before you drop $1k into a used EBCM.
May the force be with you!
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Le Mans Master
Joined: Dec 2017
Posts: 5,602
Likes: 3,322
From: Virginia
2021 C5 of the Year Finalist - Modified
St. Jude Donor '21-'22
Ah man, that sucks! You can try the suggestions above, but more than likely you'll be paying $1000K+ for used unit with no warranty. Sorry this happened to you.
Race Director
Joined: Oct 2004
Posts: 12,864
Likes: 4,667
Some codes on the 2000 models can be repaired, according to some posts I've read here thru the years. However, and this has also my experience reading the posts thru the years, the C1255 H C code is not one of them. As one post put it, the C1255 code is "the kiss of death" for the EBCM. Good luck finding a good used one. I believe there's a stickie that tells how to swap most all of the electronics over to the '01-up SWPS, EBCM, etc. Don't expect it to be cheap!! Best of luck to you........
Melting Slicks
Joined: Sep 2018
Posts: 2,839
Likes: 174
From: Mid-Michigan
If you have the mechanical skill, you could update to 01-04 ebcm:
https://www.corvetteforum.com/forums...m-success.html
https://www.corvetteforum.com/forums...m-success.html
Administrator
Joined: Mar 2001
Posts: 368,384
Likes: 24,790
From: In a parallel universe. Currently own 2014 Stingray Coupe.
C7 of the Year - Modified Finalist 2021
MO Events Coordinator
St. Jude Co-Organizer
St. Jude Donor '03 thru '26
NCM Sinkhole Donor
CI 5, 8 & 11 Veteran
Moved to C5 Tech.
