ABS module repair/replacement for a 2000 coupe
Thread Starter
Pro
Joined: Jan 2008
Posts: 631
Likes: 100
From: Naples FL
ABS module repair/replacement for a 2000 coupe
I have the ABS and Service Traction Control messages so I checked the codes and found C1255, I believe this is the EBCM does anyone know where I can get it repaired please?
Drifting
Joined: May 2020
Posts: 1,661
Likes: 701
From: Baton Rouge, Louisiana, metro area
Other than the code, do you have any driving symptoms? From what I understand, only the car’s ABS capabilities are impaired when this happens.
I have a ‘99 BTW. Just wondering….
I have a ‘99 BTW. Just wondering….
Drifting
Joined: Aug 2014
Posts: 1,392
Likes: 388
From: Virginia
St. Jude Donor '18
You can try resetting the code, and then exercising your ABS/TCS system. Take it out to a parking lot, and do some panic stops, and spin the rear tires with everything turned on. Keep resetting the code, and exercising the system. There is a chance you can rejuvenate it.
I have a 2000 C5 with only 22K miles on it. It doesn't get driven often. But I always spin the tires on the garage floor each time I start it up, and move it, to keep the system exercised. Occasionally I get the same code, but knock on wood, with a little exercise, it goes off and stays off.
I have a 2000 C5 with only 22K miles on it. It doesn't get driven often. But I always spin the tires on the garage floor each time I start it up, and move it, to keep the system exercised. Occasionally I get the same code, but knock on wood, with a little exercise, it goes off and stays off.
Burning Brakes
Joined: Feb 2022
Posts: 883
Likes: 971
From: NW Burbs of Chi-Town
2025 C5 of the Year Finalist - Modified
I have a 98. The whole EBCM thing is less than ideal on our cars. I was just reading about grounding gremlins on these cars:
https://www.corvetteforum.com/forums...tion-long.html
Worth a shot to check the grounds and connector's before you drop $1k into a used EBCM.
May the force be with you!
https://www.corvetteforum.com/forums...tion-long.html
Worth a shot to check the grounds and connector's before you drop $1k into a used EBCM.
May the force be with you!
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
2027 Corvette vs The World: Every C8 vs Its Closest Competitor
Joe Kucinski
10 Most Common Corvette Problems of the Last 20 Years!
Joe Kucinski
5 MOST and 5 LEAST Popular Corvette Model Years in History!
Joe Kucinski
2027 Corvette Buyer's Guide: Everything You Need to Know!
Joe Kucinski
Le Mans Master
Joined: Dec 2017
Posts: 5,548
Likes: 3,293
From: Virginia
2021 C5 of the Year Finalist - Modified
St. Jude Donor '21-'22
Ah man, that sucks! You can try the suggestions above, but more than likely you'll be paying $1000K+ for used unit with no warranty. Sorry this happened to you.
Race Director
Joined: Oct 2004
Posts: 12,859
Likes: 4,656
Some codes on the 2000 models can be repaired, according to some posts I've read here thru the years. However, and this has also my experience reading the posts thru the years, the C1255 H C code is not one of them. As one post put it, the C1255 code is "the kiss of death" for the EBCM. Good luck finding a good used one. I believe there's a stickie that tells how to swap most all of the electronics over to the '01-up SWPS, EBCM, etc. Don't expect it to be cheap!! Best of luck to you........
Melting Slicks
Joined: Sep 2018
Posts: 2,779
Likes: 174
From: Mid-Michigan
If you have the mechanical skill, you could update to 01-04 ebcm:
https://www.corvetteforum.com/forums...m-success.html
https://www.corvetteforum.com/forums...m-success.html
Administrator
Joined: Mar 2001
Posts: 367,657
Likes: 24,662
From: In a parallel universe. Currently own 2014 Stingray Coupe.
C7 of the Year - Modified Finalist 2021
MO Events Coordinator
St. Jude Co-Organizer
St. Jude Donor '03 thru '25
NCM Sinkhole Donor
CI 5, 8 & 11 Veteran
Moved to C5 Tech.
