Track alignment cost?
Track Rat
Joined: Oct 2006
Posts: 6,466
Likes: 3,464
There is a lot more plastic to remove under the car in order to get to the adjusters. It also is kind of a pain to get the the forward legs of the rear control arms. I don't know if a dealer will charge more but I wouldn't have much confidence in someone that tries to knock it out in in an hour.
Team Owner
Joined: Feb 2013
Posts: 22,598
Likes: 14,555
Not the case... you have to pull the rear wheel liners to remove a crush box to get at the forward leg of the rear UCA. Then you have to remove washers under all the UCA contacts and put it back together. Then you do the traditional alignment.
Intermediate
Joined: Nov 2018
Posts: 38
Likes: 5
From: McDonough Ga
going to pick up my car today after getting the track alignment. The service rep asked me if I knew the cost. I said no and he said its around 700.00 but would help me out. I was pretty shocked. We will see final outcome. It seems one thing after another is disheartening about this car . they jacked up the price of the car 5k when i bought it. Now 700 track alignments? Hope its just the first one and not everyone or there will be a pretty Elkhart blue c8 for sale.. ill follow up with the cost. If its a 3 hour job I can be ok with that if charged accordingly.
Racer
Joined: Apr 2018
Posts: 290
Likes: 343
going to pick up my car today after getting the track alignment. The service rep asked me if I knew the cost. I said no and he said its around 700.00 but would help me out. I was pretty shocked. We will see final outcome. It seems one thing after another is disheartening about this car . they jacked up the price of the car 5k when i bought it. Now 700 track alignments? Hope its just the first one and not everyone or there will be a pretty Elkhart blue c8 for sale.. ill follow up with the cost. If its a 3 hour job I can be ok with that if charged accordingly.
Last edited by z8ra; Jan 14, 2021 at 06:27 AM.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Race Director
Joined: Nov 2005
Posts: 14,553
Likes: 1,548
From: Supporting the Corvette Community at Abel Chevrolet in Rio Vista, CA 707-374-6317 Ext.123
St. Jude Donor '08
Post your alignment sheet and let us know what they actually did to get you the best alignment in Washington state.
Last edited by RichieRichZ06; Jan 14, 2021 at 11:45 AM.
Instructor
Joined: Feb 2013
Posts: 150
Likes: 102
Burning Brakes
Joined: Sep 2020
Posts: 956
Likes: 697
Cost for Track Alignment?
Just curious how many people have had track alignment completed. My car is at the dealer now. They called me to make sure I am tracking the car because they stated they have to take apart "half of the car" to complete the alignment. I realize the track prep guide states that "the upper control arm to body washers on all four corners will need to be relocated from between the body and the control arm to between the head of the bolt and the control arm." Apparently this is what taking "half of the car apart" means.
They quoted $900 to do the track alignment.
What have others paid for the track alignment procedure?
They quoted $900 to do the track alignment.
What have others paid for the track alignment procedure?
Racer
Joined: Aug 2020
Posts: 412
Likes: 219
From: San Diego, CA
Just curious how many people have had track alignment completed. My car is at the dealer now. They called me to make sure I am tracking the car because they stated they have to take apart "half of the car" to complete the alignment. I realize the track prep guide states that "the upper control arm to body washers on all four corners will need to be relocated from between the body and the control arm to between the head of the bolt and the control arm." Apparently this is what taking "half of the car apart" means.
They quoted $900 to do the track alignment.
What have others paid for the track alignment procedure?
They quoted $900 to do the track alignment.
What have others paid for the track alignment procedure?
Though I must happily add that my Corvette servicing is costing much less money than the equivalent work on my 911.
Last edited by Jacques Albrecht; Jul 9, 2021 at 02:23 AM.
Burning Brakes
Joined: Sep 2020
Posts: 956
Likes: 697
You received a great deal at $400. I picked up my car yesterday and they did charge $900 for the alignment with the explanation that they had to remove all four upper control arms and moved the washer to the outside near the head of the bolt. It also cost me $325 to add two quarts of transmission fluid which included 2 quarts of tranny fluid at $129 just for the fluid. They also did a brake fluid flush for $110 and added the high temp racing fluid that I provided to the dealer.
Another dealer provided a price of $230 for the alignment but I was not convinced he knew that they had to do the extra work of detaching the upper control arm (Just FYI).
Another dealer provided a price of $230 for the alignment but I was not convinced he knew that they had to do the extra work of detaching the upper control arm (Just FYI).
FYI - My dealer eventually charged me ~$400 after they came to realize the scope of the work involved in setting a proper track alignment on a 2020 C8 Z51 w/mag. Originally, the service manager had given me a written estimate of ~$100 to perform an 'alignment'....
Though I must happily add that my Corvette servicing is costing much less money than the equivalent work on my 911.
Though I must happily add that my Corvette servicing is costing much less money than the equivalent work on my 911.
Instructor
Joined: Feb 2021
Posts: 214
Likes: 90
From: Maryland
$275.00 at dealership but I did the control arms and lowered the collars which took about an hour . It’s a great time to get rid of those useless pagid pads the car comes with. I find them useless for the track so many better options . After the control arms are moved they really are only tweaking the toe I believe . Nothing crazy I will be going much more aggressive than the factory track speed but I needed to start with some kind of reference point .
Burning Brakes
Joined: Sep 2020
Posts: 956
Likes: 697
It looks like the standard price for track alignment (if the dealer knows what they are doing and price the work appropriately) with the removal and replacement of the upper control arm washers is between $875 to $900. I see in another thread that other people were quoted $875 and I just paid $900. I was just very surprised at $900.
$275.00 at dealership but I did the control arms and lowered the collars which took about an hour . It’s a great time to get rid of those useless pagid pads the car comes with. I find them useless for the track so many better options . After the control arms are moved they really are only tweaking the toe I believe . Nothing crazy I will be going much more aggressive than the factory track speed but I needed to start with some kind of reference point .
