new frame 71, do I shim it?
Thread Starter
Racer
Joined: Jan 2016
Posts: 419
Likes: 58
From: montreal quebec
new frame 71, do I shim it?
Folks, ready to drop newer repaired bird cage onto replacement frame, so do I use any old shims? I kind of wonder why the even used them, I would have thought gm would have made both sides the same, whatever, where do I shim and how many? I have about 10 left over when car was taken apart. Thanks Mike.
Race Director
Joined: Jul 2015
Posts: 13,082
Likes: 3,399
From: SW Florida.
These have been described as kit cars assembled by chevy. The body's weren't clamped into fixtures and spot-welded together like just about every car since the Model A. Will you need shims? Most likely. Where you gonna need em? You tell us. Put car on frame with shims where they were and start measuring to see what is too high and what is too low...
Melting Slicks
Joined: Mar 2008
Posts: 2,666
Likes: 289
From: Spring Park MN
My 75 Vert didn't seem to sit correctly on the frame when I got it. After I finished the chassis and put the body back on, I just played with the shims at each mount. I would see how hard it sat down on each spot and how square the body was with the frame. The frame was sitting square with the floor and measuring the same height side to side. I got the body to do the same. It is a lot better than it was from the factory.
Mike
Mike
Last edited by v2racing; May 29, 2018 at 11:15 AM.
Safety Car
Joined: Oct 2007
Posts: 3,729
Likes: 267
From: Austin Texas
Corvette of the Year Winner 2017
2016 C3 of Year Finalist
When starting with an unknown frame,
I start with 2 shims under each of the 4 cabin corners, Not accessible with body on.
then add shims as needed to the exposed mounts you can reach.
Ideally you want even body pressure on all mount points.
I start with 2 shims under each of the 4 cabin corners, Not accessible with body on.
then add shims as needed to the exposed mounts you can reach.
Ideally you want even body pressure on all mount points.
Team Owner
Joined: Jun 2000
Posts: 38,923
Likes: 1,482
From: Southbound
Cruise-In II Veteran
Race Director
Joined: Nov 2006
Posts: 19,445
Likes: 353
From: Athens GA
St. Jude Donor '12-'13, '15- '16-'17-'18-'19, '21
Hope I remember that in a couple of months.
Bman
2026 Loser of the Year
Joined: Sep 2013
Posts: 36,601
Likes: 7,048
From: New Or-leens Loo-z-anna
Race Director
Joined: Sep 1999
Posts: 11,361
Likes: 383
From: Plano TX
Years ago I talked to a guy that worked in the St Louis plant during the C3 era. He said they did use jigs for the birdcage and body but the jigs would go out of spec after a number of cars and no one cared enough to check the jig until someone came running down the line telling them the doors didn't fit anymore. Quality control back in the day was terrible. Didn't help that many of the line workers got stoned on their lunch breaks.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Melting Slicks
Joined: Mar 2008
Posts: 2,666
Likes: 289
From: Spring Park MN
Years ago I talked to a guy that worked in the St Louis plant during the C3 era. He said they did use jigs for the birdcage and body but the jigs would go out of spec after a number of cars and no one cared enough to check the jig until someone came running down the line telling them the doors didn't fit anymore. Quality control back in the day was terrible. Didn't help that many of the line workers got stoned on their lunch breaks.
It sits level now.
Mike
