Starter overheating problems
Safety Car
Joined: May 2001
Posts: 4,757
Likes: 1,647
From: Fairfax Virginia
I had the same issue with my high compression 427 and it's starter would get heat soaked and turned very slowly. I switched over to a small Hitachi Gear drive starter and it works great. I don't have any protective blanket over the starter, just my long tube headers.
The very best way to start an engine like this is to use a Ignition Box that offers the feature where startup timing that can be pulled back up to 20* only while cranking and then the timing returns after it starts up. I was amazed at the HUGE difference it makes on a Hot big block as after pulling the timing my car cranks like a Mopar slant six engine. It spins much faster with the timing pulled back and allows the engine to start easier. The new MSD Ignition boxes can do the timing retard while cranking, I have a MSD Digital Retard Box which performs the function for my C3 and the starting has never been easier and I have zero issues with Hot starts.
Yuck.....that is a toyota and that is Japanese *#@*. I won't own any car from Asia. I like pictures of nice Corvettes, not Asian cars.....
The very best way to start an engine like this is to use a Ignition Box that offers the feature where startup timing that can be pulled back up to 20* only while cranking and then the timing returns after it starts up. I was amazed at the HUGE difference it makes on a Hot big block as after pulling the timing my car cranks like a Mopar slant six engine. It spins much faster with the timing pulled back and allows the engine to start easier. The new MSD Ignition boxes can do the timing retard while cranking, I have a MSD Digital Retard Box which performs the function for my C3 and the starting has never been easier and I have zero issues with Hot starts.
Yuck.....that is a toyota and that is Japanese *#@*. I won't own any car from Asia. I like pictures of nice Corvettes, not Asian cars.....
Melting Slicks
Joined: Jun 2014
Posts: 2,236
Likes: 498
From: NJ
Insulating blankets are not as effective , they actually hold the heat in too. You need something to reflect the radiant heat like an aluminum shield with an air gap. But you have something else going on also, if it takes six hours to re-start.
Melting Slicks
Joined: May 2021
Posts: 2,271
Likes: 1,316
From: Fleming Island, FL
Le Mans Master
Joined: Aug 2017
Posts: 8,336
Likes: 2,810
From: Cool Northern Michigan
Just like dynamat under the carpet, it reflects.
The only way a starter wrap would hold heat is when a starter has been cranking & cranking for several minutes. That would be heat inside the blanket rather than outside the blanket.
Melting Slicks
Joined: Jun 2014
Posts: 2,236
Likes: 498
From: NJ
I disagree. Any of those blankets for starters or wraps for fuel lines or tubes for wiring have been proven effective in blocking / reflecting heat.
Just like dynamat under the carpet, it reflects.
The only way a starter wrap would hold heat is when a starter has been cranking & cranking for several minutes. That would be heat inside the blanket rather than outside the blanket.
Just like dynamat under the carpet, it reflects.
The only way a starter wrap would hold heat is when a starter has been cranking & cranking for several minutes. That would be heat inside the blanket rather than outside the blanket.
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Race Director
Joined: Mar 2017
Posts: 11,946
Likes: 4,506
From: Virginia
Thread Starter
Racer
Joined: Aug 2011
Posts: 429
Likes: 24
From: Charlotte NC
I did get it out by squeezing it past the headers. I checked the numbers for it and it is originally for a 2000 silverado 1500. And it is a mini starter so overheating was not the problem I believe. I'll have it tested tomorrow
Last edited by CiCiC3; Sep 13, 2024 at 11:14 PM.
Thread Starter
Racer
Joined: Aug 2011
Posts: 429
Likes: 24
From: Charlotte NC
So after testing the starter and solenoid and battery it all checks good! I put it all back together and now it has no electrical responses at all. Not even a click sound from the starter. Fuses on the floor board all look good. Haven't checked whether the headlights turn on but most likely not. I will start with looking for a voltage drop some where. hmm
Thread Starter
Racer
Joined: Aug 2011
Posts: 429
Likes: 24
From: Charlotte NC
Auto electrician says it's probably the battery to starter fusable link that has gone out. First you need to find out why it went out. And be careful you could burn your whole car up and your house if in the garage. I remember people telling me their old corvette burned to the ground and to be careful. I thought they were crazy but maybe not after all.?
Melting Slicks
Joined: Jun 2014
Posts: 2,236
Likes: 498
From: NJ
Standard Ignition Products aka Blue Streak makes a high Temp. Solenoid for these starters. It comes with a Teflon bobbin. It definitely helped my heat soak problems with headers.
Thread Starter
Racer
Joined: Aug 2011
Posts: 429
Likes: 24
From: Charlotte NC
[QUOTE=1Hotrodz;1608223771]Standard Ignition Products aka Blue Streak makes a high Temp. Solenoid for these starters. It comes with a Teflon bobbin. It definitely helped my heat soak problems with headers.[/QUOTe
I’ll have to check the price and fit but maybe a heat cover would work well too.
I’ll have to check the price and fit but maybe a heat cover would work well too.
Melting Slicks
Joined: Jun 2014
Posts: 2,236
Likes: 498
From: NJ
[QUOTE=CiCiC3;1608223881][QUOTE=1Hotrodz;1608223771]Standard Ignition Products aka Blue Streak makes a high Temp. Solenoid for these starters. It comes with a Teflon bobbin. It definitely helped my heat soak problems with headers.[/QUOTe
I’ll have to check the price and fit but maybe a heat cover would work well too.[/QUOTE
Yes, get the heat shield. This will reflect the radiant heat from the headers.
I’ll have to check the price and fit but maybe a heat cover would work well too.[/QUOTE
Yes, get the heat shield. This will reflect the radiant heat from the headers.
Le Mans Master
Joined: May 2007
Posts: 5,025
Likes: 1,120
From: North tonawanda NY
I had a kit car years ago and I fell into the same trap, it was the same issue, bad ground connection.
BTW I have sidepipes and a standard smaller s10 type starter, never an issue
Thread Starter
Racer
Joined: Aug 2011
Posts: 429
Likes: 24
From: Charlotte NC
It might be a clutch pedal height adjustment problem for starting. It could have slipped down too far?
Last edited by CiCiC3; Dec 31, 2024 at 11:52 AM.
