Air Shocks on front?

Thread Tools

Search this Thread

Old Jan 30, 2018 | 11:49 PM
  #1
CHEXXX's Avatar
CHEXXX
Thread Starter
Intermediate

Joined: Oct 2017
Posts: 26
Likes: 27
Default Air Shocks on front?

Hi there. I was wondering if it makes sense to put air shocks on the front. (NOT Air Ride). Just air shocks. I actually have them on the rear but since I'm going into the suspension, I was wondering if it is possible. Also which ones? I need definitive answers. Thanks Much!!!
Reply
Old Jan 31, 2018 | 08:16 AM
  #2
resdoggie's Avatar
resdoggie
Had a 1976 L-82, 4-sp
Supporting Lifetime
10 Year Member
Veteran: Navy

Joined: Mar 2011
Posts: 5,338
Likes: 1,210
From: Some days your the dog and some days your the hydrant.
Royal Canadian Navy
Default

Air shocks are used to adjust for varying loads and maintaining ride height such as loading up your trunk with bricks or compensating for tongue loads when hauling a trailer. Ask yourself what loads are changing on the front end? I think you'll find out they are not needed.
Reply
Old Jan 31, 2018 | 10:20 AM
  #3
7T1vette's Avatar
7T1vette
Team Owner
15 Year Member
Community Builder
Community Influencer
Top Answer: 5

Joined: Jan 2006
Posts: 37,637
Likes: 3,113
From: Crossville TN
Default

No. If your front springs have sagged/weakened, just spend the money on new springs...
Reply
Old Jan 31, 2018 | 11:04 AM
  #4
Big2Bird's Avatar
Big2Bird
Le Mans Master
15 Year Member
Liked
Loved
Top Answer: 1

Joined: Dec 2006
Posts: 8,837
Likes: 1,027
Default

Originally Posted by CHEXXX
Hi there. I was wondering if it makes sense to put air shocks on the front. (NOT Air Ride). Just air shocks. I actually have them on the rear but since I'm going into the suspension, I was wondering if it is possible. Also which ones? I need definitive answers. Thanks Much!!!
It makes no sense to have them at all. Front or rear.
Reply
Old Jan 31, 2018 | 11:19 AM
  #5
calwldlife's Avatar
calwldlife
Team Owner
15 Year Member
Loved
Community Favorite
Top Answer: 1

Joined: Jan 2007
Posts: 53,648
Likes: 878
From: Southern Cal Ca
St. Jude Donor '22
Default

do they even make air shocks skinny enough to fit in the coils?
and yup, air shocks are not for performance
Reply
Old Jan 31, 2018 | 12:35 PM
  #6
CHEXXX's Avatar
CHEXXX
Thread Starter
Intermediate

Joined: Oct 2017
Posts: 26
Likes: 27
Default

I want an adjustable ride height for the front- for major speed bumps and whatnot. I figured a little air pump with air shocks would be a cool compromise. I already have new springs.
Reply
Old Jan 31, 2018 | 03:01 PM
  #7
cv67's Avatar
cv67
Team Owner
15 Year Member

Joined: Oct 2004
Posts: 81,241
Likes: 3,062
From: altered state
St. Jude Donor '05
Default

poor mans coil over bet there is a market for that!
As said they may not fit your coil springs. Want to raise mine 3/8 in so I can run wide meats again but dont wanna spend for coilovers.
Reply
Old Jan 31, 2018 | 06:03 PM
  #8
Dusky's Avatar
Dusky
Pro
Liked
Loved
Community Favorite

Joined: Nov 2017
Posts: 587
Likes: 49
From: Belgium
Default

Unless its one of those engine/motor or Hood/bonnet differences between british and american, shocks wont change your rideheight. Theyre shock breakers, breaking the shock of the suspension spring. They dont cary weight, so dont raise the suspension height.

Last edited by Dusky; Jan 31, 2018 at 06:09 PM.
Reply
Corvette Stories

The Best of Corvette for Corvette Enthusiasts

story-0

Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!

 Michael S. Palmer
story-1

10 Revolutionary 'Corvette Firsts' Most People Don't Know

 Joe Kucinski
story-2

5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2

 Michael S. Palmer
story-3

2027 Corvette vs The World: Every C8 vs Its Closest Competitor

 Joe Kucinski
story-4

10 Most Common Corvette Problems of the Last 20 Years!

 Joe Kucinski
story-5

5 MOST and 5 LEAST Popular Corvette Model Years in History!

 Joe Kucinski
story-6

2027 Corvette Buyer's Guide: Everything You Need to Know!

 Joe Kucinski
story-7

10 Things C8 Corvette Owners Hate (But Won't Tell You)

 Joe Kucinski
story-8

10 Best Corvettes Coming to Barrett-Jackson Palm Beach 2026!

 Brett Foote
story-9

Every Corvette Grand Sport Explained! (C2, C4, C6, C7, & C8)

 Joe Kucinski
Old Jan 31, 2018 | 09:31 PM
  #9
C3 Stroker's Avatar
C3 Stroker
Safety Car
20 Year Member
Liked
Loved
Community Favorite

Joined: Oct 2004
Posts: 3,920
Likes: 731
From: Youngstown Ohio
Default

Originally Posted by Dusky
Unless its one of those engine/motor or Hood/bonnet differences between british and american, shocks wont change your rideheight. Theyre shock breakers, breaking the shock of the suspension spring. They dont cary weight, so dont raise the suspension height.
Air shocks will raise vehicle height. Ever lift your car and watch the shocks stretch out? Air shocks will maintain that stretched height, either front or rear. Harsh ride, yes, and they do carry the weight. Hot rodders here in the U.S. used them a lot to jack up their cars for that "pro stock" look back in the 1970's.
Reply
Old Jan 31, 2018 | 09:34 PM
  #10
Alwyn678's Avatar
Alwyn678
Team Owner

Joined: Jun 2001
Posts: 43,136
Likes: 155
From: Thomson Georgia
Default

:
Originally Posted by Big2Bird
It makes no sense to have them at all. Front or rear.

Reply
Old Jan 31, 2018 | 09:50 PM
  #11
GUSTO14's Avatar
GUSTO14
Le Mans Master
20 Year Member
Liked
Loved
Community Favorite

Joined: Sep 2003
Posts: 8,812
Likes: 2,028
From: eastern NC
Default

Actually it has become quite the rage here abouts...





Reply
Old Jan 31, 2018 | 09:54 PM
  #12
C3 Stroker's Avatar
C3 Stroker
Safety Car
20 Year Member
Liked
Loved
Community Favorite

Joined: Oct 2004
Posts: 3,920
Likes: 731
From: Youngstown Ohio
Default Air Shocked

....here ya go....


Reply
Old Jan 31, 2018 | 11:22 PM
  #13
lars's Avatar
lars
Tech Contributor
Supporting Lifetime Gold
25 Year Member
Conversation Starter
Photogenic
Top Answer: 3

Joined: Aug 1999
Posts: 14,356
Likes: 6,332
From: At my Bar drinking and wrenching in Lafayette Colorado
Default

Originally Posted by CHEXXX
Hi there. I was wondering if it makes sense to put air shocks on the front. (NOT Air Ride). Just air shocks. I actually have them on the rear but since I'm going into the suspension, I was wondering if it is possible. Also which ones? I need definitive answers. Thanks Much!!!
There aren't any front air shocks made for passenger cars (because there is no need or demand for them - there would be a huge liability in offering a front air shock as an intended direct bolt-in, since changing the front ride height on a Vette or GM passenger car changes the front end alignment dramatically, creating an inherently unsafe condition). Current makers of front air shocks only offer them for trucks, and none of the truck shocks will fit your Corvette. Problem with trying to adapt an air shock for the front of a passenger car is that the shock fits tight enough up through the lower control arm that you'd never be able to get the air fill fitting/nipple to fit.

Lars

Last edited by lars; Jan 31, 2018 at 11:29 PM.
Reply
Old Jan 31, 2018 | 11:47 PM
  #14
lvmyvt76's Avatar
lvmyvt76
Melting Slicks

Joined: May 2011
Posts: 2,753
Likes: 119
From: Springfield Missouri
Default

Reply
Old Feb 3, 2018 | 07:33 AM
  #15
fishslayer143's Avatar
fishslayer143
Drifting

Joined: Aug 2009
Posts: 1,346
Likes: 160
From: new iberia la
Default

Originally Posted by Dusky
Unless its one of those engine/motor or Hood/bonnet differences between british and american, shocks wont change your rideheight. Theyre shock breakers, breaking the shock of the suspension spring. They dont cary weight, so dont raise the suspension height.
Partly True, Shock Absorbers don't ..but AIR Shocks absolutely do raise the ride height and carry additional load..depending on how much PSI you load into them.. the ones on my old Van max out at 240psi.... it lifts a good 4 inches . that's their purpose
Reply
