So this is a decent 28-pin substitute till my HDR1 adapter shows up? Thanks stew for the latching header picture to jog my mind.

Went

Last edited by Went; Jun 10, 2021 at 09:04 PM.

Jun 10, 2021 | 09:45 PM

#22

Nomake Wan

Drifting

Joined: Apr 2020

Posts: 1,925

Likes: 610

From: Orange, CA

Quote:

Originally Posted by Went

So this is a decent 28-pin substitute till my HDR1 adapter shows up? Thanks stew for the latching header picture to jog my mind.

Went

Yep, that should work! If the pin spacing is too narrow to fit in the BURN2, time to plug some wires in. It'll look totally ridiculous, but sometimes ridiculous things are necessary to accomplish our goals...

Jun 10, 2021 | 10:11 PM

#23

Went

Thread Starter

Burning Brakes

Joined: Dec 2012

Posts: 788

Likes: 160

From: Rio Rico, AZ

Yeah, where I worked till retirement I saw some pretty wild bread board setups for different circuits. I'll check the spacing...

Went

**Well my double row header strip is too narrow. I have some single and double row header strips and some nice quality perf board. Maybe I'll cobble something together Saturday with that and some short lengths of wire soldered in as jumper wires.

Last edited by Went; Jun 10, 2021 at 11:17 PM.

Jun 11, 2021 | 03:54 PM

#24

stew86MCSS396

Pro

Joined: Aug 2020

Posts: 647

Likes: 126

From: Liliha Bakery stuffing my face with coco puffs!

Quote:

Originally Posted by Went

Yup...I think that's the reason given when I purchased the header with the long pins many moons ago. Longer pins can be spread out to fit the burner. Speaking of burner...this seems to be another gotcha, not only the orientation is important but the positioning in the ZIF occupying all the bottom spaces. Look at item #3 for clarification...http://support.moates.net/beginners-programming-chips/

...and this is a good read that initially will sound like a foreign language.

*Word doc warning*: Mass Air Flow tuned port injection programming and tuning doc

Jun 11, 2021 | 11:42 PM

#25

Went

Thread Starter

Burning Brakes

Joined: Dec 2012

Posts: 788

Likes: 160

From: Rio Rico, AZ

Stew, I downloaded the doc on MAF programming and tuning. This is going to be a SLOW read for me. A foreign language is right.

Thanks, Went

Last edited by Went; Jun 16, 2021 at 10:49 PM.

Jun 16, 2021 | 10:50 PM

#26

Went

Thread Starter

Burning Brakes

Joined: Dec 2012

Posts: 788

Likes: 160

From: Rio Rico, AZ

stew86MCSS396, I bought a latching header strip, bent the pins to go into my Burn2 module. I was able to read and save my .bin file. Thank you for the picture/suggestion!

Went
