Z06 Drip Rails
Thread Starter
Heel & Toe
Joined: Jan 2017
Posts: 15
Likes: 0
Z06 Drip Rails
I know this has been covered a lot, but I need some help. My Z06 leaks in the rain, just above the A-pillar. I have narrowed it down to the broken plastic "drip rail". I found a couple different part numbers and I am just wondering which one is correct 10331563 or 10331559? This will be for the left side on my Z06. Also, if anyone knows of a cheap source recommendations would be helpful. TIA
Instructor
Joined: May 2017
Posts: 228
Likes: 35
I know this has been covered a lot, but I need some help. My Z06 leaks in the rain, just above the A-pillar. I have narrowed it down to the broken plastic "drip rail". I found a couple different part numbers and I am just wondering which one is correct 10331563 or 10331559? This will be for the left side on my Z06. Also, if anyone knows of a cheap source recommendations would be helpful. TIA
Thread Starter
Heel & Toe
Joined: Jan 2017
Posts: 15
Likes: 0
Here is a thread with some part numbers, https://www.corvetteforum.com/forums...-moldings.html
Drifting
Joined: Mar 2013
Posts: 1,496
Likes: 353
From: Little Rock Arkansas
The part #s for the later style revised Z06/FRC drip rails are 10331562 &
10331563. They supersede 10422996 & 10422997 respectively
It was my understanding however that these have been discontinued though?... Maybe something has changed recently, but I seem to remember Z06/FRC owners going through issues of having to source good used non-cracked rails. Even when new prices were in the hundreds for each side.
10331563. They supersede 10422996 & 10422997 respectively
It was my understanding however that these have been discontinued though?... Maybe something has changed recently, but I seem to remember Z06/FRC owners going through issues of having to source good used non-cracked rails. Even when new prices were in the hundreds for each side.
Thread Starter
Heel & Toe
Joined: Jan 2017
Posts: 15
Likes: 0
The part #s for the later style revised Z06/FRC drip rails are 10331562 &
10331563. They supersede 10422996 & 10422997 respectively
It was my understanding however that these have been discontinued though?... Maybe something has changed recently, but I seem to remember Z06/FRC owners going through issues of having to source good used non-cracked rails. Even when new prices were in the hundreds for each side.
10331563. They supersede 10422996 & 10422997 respectively
It was my understanding however that these have been discontinued though?... Maybe something has changed recently, but I seem to remember Z06/FRC owners going through issues of having to source good used non-cracked rails. Even when new prices were in the hundreds for each side.
They are still available, $295 each through the dealer, cheapest I found online was $190. Seems a bit much for just a bit of plastic, but I have to replace my driver's side since it leaks.
Instructor
Joined: May 2017
Posts: 228
Likes: 35
I know this has been covered a lot, but I need some help. My Z06 leaks in the rain, just above the A-pillar. I have narrowed it down to the broken plastic "drip rail". I found a couple different part numbers and I am just wondering which one is correct 10331563 or 10331559? This will be for the left side on my Z06. Also, if anyone knows of a cheap source recommendations would be helpful. TIA
Tech Contributor
Joined: Dec 1999
Posts: 32,910
Likes: 2,402
From: Anthony TX
CI 6,7,8,9,11 Vet
St. Jude Donor '08
If you have a leak from the roof/drip rail area, its most likely NOT because of the cracked drip rail.
The SEALANT that the factory installed between the roof/windshield header and the A Pillar, shrinks and cracks. You usually have to remove the seal, drip rail and get all the OLD SEALANT out and replace it with new sealant.
Bill
The SEALANT that the factory installed between the roof/windshield header and the A Pillar, shrinks and cracks. You usually have to remove the seal, drip rail and get all the OLD SEALANT out and replace it with new sealant.
Bill
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Expensive Corvettes Ever Sold on Bring A Trailer
Brett Foote
10 Things Every Corvette Owner Needs (2026 Edition)
Michael S. Palmer
8 Most "Only Corvette Owners Understand" Quirks and Problems
Pouria Savadkouei
10 Reasons the C6 Z06 is Still A Performance Benchmark After 20 Years
Joe Kucinski
How Much Horsepower Every Corvette Engine "LOST" in 1972
Joe Kucinski
Top 10 DOs and DON'Ts for Protecting Your Convertible Top!
Michael S. Palmer
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Instructor
Joined: May 2017
Posts: 228
Likes: 35
If you have a leak from the roof/drip rail area, its most likely NOT because of the cracked drip rail.
The SEALANT that the factory installed between the roof/windshield header and the A Pillar, shrinks and cracks. You usually have to remove the seal, drip rail and get all the OLD SEALANT out and replace it with new sealant.
Bill
The SEALANT that the factory installed between the roof/windshield header and the A Pillar, shrinks and cracks. You usually have to remove the seal, drip rail and get all the OLD SEALANT out and replace it with new sealant.
Bill
Tech Contributor
Joined: Dec 1999
Posts: 32,910
Likes: 2,402
From: Anthony TX
CI 6,7,8,9,11 Vet
St. Jude Donor '08
I do not think GM stocks the drip rail any more. I believe its an obsolete part. Call Gene Culley and see if he has any. I ordered my passengers side drip rail from him a LONG LONG time ago.
Bill
Bill
Cruising
Joined: Oct 2018
Posts: 10
Likes: 1
From: RI
Conflicting info on Z06 drip rails
The part #s for the later style revised Z06/FRC drip rails are 10331562 &
10331563. They supersede 10422996 & 10422997 respectively
It was my understanding however that these have been discontinued though?... Maybe something has changed recently, but I seem to remember Z06/FRC owners going through issues of having to source good used non-cracked rails. Even when new prices were in the hundreds for each side.
10331563. They supersede 10422996 & 10422997 respectively
It was my understanding however that these have been discontinued though?... Maybe something has changed recently, but I seem to remember Z06/FRC owners going through issues of having to source good used non-cracked rails. Even when new prices were in the hundreds for each side.
Cruising
Joined: Oct 2018
Posts: 10
Likes: 1
From: RI
Bill, I put a call in to Gene and waiting for a call back as the website that shows the part number 10331562 & 10331563 says that this is not compatible with the Z06 model. I've been searching online for hours and cannot find any drip rails for the 2002 Z06. Mine are leaking like a sieve. You mentioned in a post that the actual Plastic trim/rail is not the issue but the underlaying sealant. Both sides of my trim have a 1/8" space at the top of the windshield just before it curves along to the horizontal roof line. Do you think if I carefully remove the trim and use 3m caulk rope (dum dum rope) that this will be the solution? I'm hesitant to use a permatex type sealant as this would give me one shot at it. (Probably impossible to separate the plastic trim from the sealant a 2nd time). Have you done a successful repair in this regard?
