C5 Replacement Shock Question
Race Director
Joined: Dec 2000
Posts: 19,304
Likes: 85
From: San Diego CA
From what I've read, GM is going with Bilstein shocks in the C7. I'll bet they're a step-up from the C6 Z06 shocks. Bilstein shocks are tough to beat, although I've read of good things about Konis.
Racer
Joined: Jul 2004
Posts: 474
Likes: 0
From: Pa
Honestly the Bilsteins are probably one of the best upgrades you can do that doesn't cost an arm and a leg. I think mine were $300 or $350, but the driving was night and day, both firm and soft when you want it. They will also last a very long time. I think that was probably the best 300 bucks I've spent were I noticed such an improvement. They also work very well if you choose to lower your car.
Burning Brakes
Joined: Oct 2013
Posts: 1,030
Likes: 72
From: Seminole, FL
Had the C5 on the lift this morning, aside from outter tie rod ends and stabilizer links, I'm seriously knowing that I need to do shocks. 108k on originals? yikes.
BUT
There's that "Active Suspension" question. (duh here)
Car's build sheet says FE1
Just suppose I want to keep the active suspension.
What is the way to go?
BUT
There's that "Active Suspension" question. (duh here)
Car's build sheet says FE1
Just suppose I want to keep the active suspension.
What is the way to go?
Burning Brakes
Joined: Dec 2003
Posts: 1,243
Likes: 5
From: Loveland CO
If you have the Magnetic ride control (electric shocks) then the only way to keep that system is to get OEM replacements. IF you have mangnetic ride control (switch in teh center for sport/Comf) and you dont want to spend the $$ for the OEM replacements then you can go to another shock ex. '04 Z06 Sachs shocks, Bilstein, C6Z06, ect.. then you can swap the shocks out and have to have a shop/dealer with a TECH II scanner disable the magnetic ride control option in the BCM. (search feature on here will lead you to where you turn it off in the TECH II menu).
S
S
Burning Brakes
Joined: Oct 2013
Posts: 1,030
Likes: 72
From: Seminole, FL
The shocks currently in the car are.
Front : P/N: 10279660 (large TGA also)
Rear : P/N: 10416668 (large TBB also)
Button on center console just says "Active Handling" with cutsey little icon of vehicle with curvey tire tracks behind it.
When I press it, dash says "Active Handling ON" or OFF
Shocks have wiring or hose connected to them.
Front : P/N: 10279660 (large TGA also)
Rear : P/N: 10416668 (large TBB also)
Button on center console just says "Active Handling" with cutsey little icon of vehicle with curvey tire tracks behind it.
When I press it, dash says "Active Handling ON" or OFF
Shocks have wiring or hose connected to them.
Burning Brakes
Joined: Aug 2007
Posts: 831
Likes: 2
From: Houston Texas
:will y::wi lly: I Need CPR !!Talk about a "firm" ride, OMG.
Last edited by NatB; Oct 12, 2013 at 06:05 PM.
Tech Contributor
Joined: Dec 1999
Posts: 32,910
Likes: 2,402
From: Anthony TX
CI 6,7,8,9,11 Vet
St. Jude Donor '08
Had the C5 on the lift this morning, aside from outter tie rod ends and stabilizer links, I'm seriously knowing that I need to do shocks. 108k on originals? yikes.
BUT
There's that "Active Suspension" question. (duh here)
Car's build sheet says FE1
Just suppose I want to keep the active suspension.
What is the way to go?
BUT
There's that "Active Suspension" question. (duh here)
Car's build sheet says FE1
Just suppose I want to keep the active suspension.
What is the way to go?
If it were me, I would install a complete Z51 or ZO6 suspension and use C6 ZO6 shocks. You will absolutely LOVE the improvement!!!
The C6 ZO6 shocks are only $250. for all four!You will need to find a GM Tech 2 and program the F45 RPO out of the BCM or use resistors and fool the ESC Computer before you replace the shocks.
You can find used ZO6 suspension parts in the for sale section all the time.
Bill
Corvette Stories
The Best of Corvette for Corvette Enthusiasts
Top 10 Most Explosive Corvettes Ever Made: Power-to-Weight Ratio Ranked!
Joe Kucinski
150 hp to 1,250 hp: Every Corvette Generation Compared by the Specs That Matter
Joe Kucinski
8 Coolest Corvette Pace Cars (and Replicas) of All Time
Verdad Gallardo
Top 10 Corvette Engines RANKED by Peak Torque (70+ Years of Muscle!)
Joe Kucinski
Corvette ZR1X Will Be Pacing the Indy 500, And Could Probably Race, Too!
Verdad Gallardo
Top 10 Corvettes Coming to Mecum Indy 2026!
Brett Foote
Top 10 C9 Corvette MUST-HAVES to Fix These C8 Generation Flaws!
Michael S. Palmer
10 Revolutionary 'Corvette Firsts' Most People Don't Know
Joe Kucinski
5 Reasons to Upgrade to an LS6-Powered Corvette; 5 Reasons to Stay LT2
Michael S. Palmer
Burning Brakes
Joined: Oct 2013
Posts: 1,030
Likes: 72
From: Seminole, FL
Thanks, Bill Curlee, I see that you're a 'Tech Contributor', so you might just be the man I want to talk to.
So you say "a complete Z51 or Z06 suspension and use C6 Z06 shocks. only $250.oo for all four!"
Question.
This means changing springs, stabilizer bars, "The Works"???
Not to include the steering rack though, right?
So you say "a complete Z51 or Z06 suspension and use C6 Z06 shocks. only $250.oo for all four!"
Question.
This means changing springs, stabilizer bars, "The Works"???
Not to include the steering rack though, right?
Tech Contributor
Joined: Dec 1999
Posts: 32,910
Likes: 2,402
From: Anthony TX
CI 6,7,8,9,11 Vet
St. Jude Donor '08
C6 ZO6 shocks all four new in the box $250
Find some:
ZO6 or Z51 springs
ZO6 or Z51 sway bars
Metal sway bar End Links
That will make you happy
www.gmpartshouse.com has the C6 shocks AND,,,, he has new C6 Z51 suspension parts that will fit you car.
Bill
Find some:
ZO6 or Z51 springs
ZO6 or Z51 sway bars
Metal sway bar End Links
That will make you happy
www.gmpartshouse.com has the C6 shocks AND,,,, he has new C6 Z51 suspension parts that will fit you car.
Bill
Melting Slicks
Joined: Mar 2008
Posts: 2,453
Likes: 346
From: SC
Honestly the Bilsteins are probably one of the best upgrades you can do that doesn't cost an arm and a leg. I think mine were $300 or $350, but the driving was night and day, both firm and soft when you want it. They will also last a very long time. I think that was probably the best 300 bucks I've spent were I noticed such an improvement. They also work very well if you choose to lower your car.
